- Page 1 AM/FM RADIO WITH RDS DETACHABLE FRONT PANEL DIVX/MP4/MP3/WMA PLAYBACK REMOTE CONTROL INCLUDED gmV300BT USB & SD CONTROL BLUETOOTH FUNCTION RCA output FRONT AUX-IN 3inch colour display HIGH POWER 4X50 WATTS media receiver WITH BLUETOOTH NO CD MECHANISM...
-
Page 2: Table Of Contents
CONTENTS Safety Precautions.......................2-3 Installation....................4-6 Wiring Connections......................7 Basic Operation......................8-9 Radio Operation......................10-11 USB/SD Operation....................12 Other Operations......................13 Maintenance....................13 Infra Red Remote Control...................14 Simple Troubleshooting Guide..................15 Specifications.....................15... -
Page 3: Safety Precautions
SAFETY PRECAUTIONS Important Warnings to Take Note of BEFORE Commencing Installation Damage Caused By Incorrect Installation or Usage is NOT Covered By Warranty. PLEASE Take the Time to Read the Installation Notes Carefully. To Validate the Warranty Please Ensure That the Unit is Installed by a Professional, VAT registered Car Audio Installation Company. - Page 4 SAFETY PRECAUTIONS Secure the wiring with cable clamps or adhesive tape. To protect the wiring, wrap adhesive tape around them where they lie against metal parts. To avoid short-circuiting, cover all disconnected lead with insulating tape. There is a possibility of short-circuiting if the leads are not insulated.
-
Page 5: Installation
INSTALLATION Tools for Installation 2 removal wrenches are supplied for taking out the old unit and place with this brand name car radio. The following tools and supplies may also be needed for the installation: Tools for Installation: Philips Screw-drivers /Machine Screws /Wire Stripper /Wire Cutter /Hammer /Pencil /Electrical Tape /Electric Drill Supplies for Installation: Machine Screws /Crimp Connectors /14 Gauge Wire for Power Connections /14-16 Gauge Speaker Wires The above are not supplied. - Page 6 INSTALLATION WARNING! Disconnect negative battery terminal from battery before starting installation. Consult the vehicle’s owner’s manual for proper instructions. NOTE: Mark the polarity of the existing speaker wires before disconnecting battery. NOTE: Remove the two transport screws from the top of the unit before installing. DIN Front Mount...
- Page 7 INSTALLATION DIN Rear Mount NOTE: Outer trim frame, hook, and mounting sleeve are not used for this installation This is only intended as a general guide; contact the vehicle’s manufacturer for specific instructions. This menthod of installation uses the screw holes at the sides of the unit and the holes of the existing vehicle mounting bracket.
-
Page 8: Wiring Connections
WIRING DIAGRAM Make sure You have a good chassis ground. Good ground connection will eliminate most electrical noise problems. A good chassis ground requires a tight connection to the vehicle’s metal chassis. The area around the ground connection should be clean, bare metal without rust, paint, plastic, dust, or dirt for a good ground connection. -
Page 9: Basic Operation
Basic Operation 1. Turning the unit On / Off Press the Power Button to turn the unit on. When the unit is on, press the Power Button once to turn the TFT off. During TFT off, the video out signal will be available so that the connected monitor will show the screen of the unit. - Page 10 Basic Operation 6. SETUP Enter the setup menu in the home screen by turning and pressing the volume knob. Turn the volume knob to each item you would like to set. Press the volume knob in each of the item, followed by turning the volume knob to adjust settings. After adjusting, press the volume knob to confirm. Repeat these steps to finish the setting of other items.
-
Page 11: Radio Operation
Radio Operation 1. Choose Radio Band Press the MOD Button to access the radio function. Then press the BND button to choose among the five radio bands - three FM Bands (FM1, FM2, and FM3) and two AM Bands (AM1, and AM2). Each of the five bands can store up to six preset stations, for a total of 30 preset memory stations. - Page 12 Radio Operation (Con’d) 6. Mono/Stereo Reception Control After choosing ST in the list, you can turn ST on or off to select stereo or mono reception. Improvement of reception of weak stations can be done by selecting ST OFF operation which may cut down some reception noise. 7.
-
Page 13: Usb/Sd Operation
USB/SD Operation Plug the USB/SD card into the USB/SD port. The unit will play the contents automatically. 1. Advance / Go Back Advance to the next track or go back to the previous track by pressing the forward or rewind buttons. Press and hold the same button for fast forward/rewind the song/video, you may stop anytime by pressing the play/pause button. -
Page 14: Other Operations
Other Operations 1. AUX Input The AUX Input Jack is a 3.5mm stereo jack on the front panel of the unit. Press the Mode button to choose AUX. Connect any portable audio device such as a MP3 player to unit. Use the volume control to adjust volume. 2. -
Page 15: Infra Red Remote Control
Infra Red Remote Control (Optional) 1. Power On/off 13. Time Clock Display/Statistical Disc 2. Mode Switch Button Information Display Button 3. Stop Playback 14. VOL + 4. Navigation Up 15. Play/Pause Function 5. Navigation Left 16. Sound Select Button 6. Enter Button 17. -
Page 16: Simple Troubleshooting Guide
Simple Troubleshooting Guide PROBLEM CAUSE / SOLUTION No Power Check whether the fuse is blown, replace with fuse of proper value if necessary. Unit stops responding or shows error in display Press the RESET button. Unable to receive radio stations Check whether the antenna is inserted or the antenna is properly connected;...
