Model Number
354C10
Performance
Sensitivity(± 15 %)
Measurement Range
Frequency Range(± 5)
Resonant Frequency
Broadband Resolution(1 to 10,000 Hz)
Non-Linearity
Transverse Sensitivity
Environmental
Overload Limit(Shock)
Temperature Range
Temperature Response
Electrical
Excitation Voltage
Constant Current Excitation
Output Impedance
Output Bias Voltage
Discharge Time Constant
Settling Time(within 10% of bias)
Spectral Noise(1 Hz)
Spectral Noise(10 Hz)
Spectral Noise(100 Hz)
Spectral Noise(1 kHz)
Electrical Isolation
Physical
Sensing Element
Sensing Geometry
Housing Material
Sealing
Size (Height x Length x Width)
Weight(without cable)
Electrical Connector
Electrical Connection Position
Cable Length
Cable Type
Mounting
[4]
All specifications are at room temperature unless otherwise specified.
In the interest of constant product improvement, we reserve the right to change specifications without notice.
®
ICP is a registered trademark of PCB Group, Inc.
TRIAXIAL ICP® ACCELEROMETER
ENGLISH SI
10 mV/g 1.02 mV/(m/s²)
± 500 g pk ± 4905 m/s² pk
2 to 8000 Hz 2 to 8000 Hz
≥ 40 kHz ≥ 40 kHz
0.003 g rms 0.03 m/s² rms
≤ 1 % ≤ 1 %
≤ 5 % ≤ 5 %
± 10,000 g pk ± 98,100 m/s² pk
-65 to +250 °F -54 to +121 °C
See Graph See Graph
18 to 30 VDC 18 to 30 VDC
2 to 20 mA 2 to 20 mA
≤ 200 Ohm ≤ 200 Ohm
7 to 12 VDC 7 to 12 VDC
0.3 to 1.0 sec 0.3 to 1.0 sec
<3 sec <3 sec
1000 µg/√Hz
9810 (µm/sec
300 µg/√Hz
2943 (µm/sec
80 µg/√Hz
785 (µm/sec
25 µg/√Hz 308 (µm/sec
8 8
>10 Ohm >10
Ceramic Ceramic
Shear Shear
Titanium Titanium
Hermetic Hermetic
0.30 in x 0.55 in x 0.55 in 7.6 mm x 14.0 mm x 14.0 mm
0.18 oz 5.0 gm
1/4-28 4-Pin 1/4-28 4-Pin
Side Side
5 ft 1.5 m
034 4-cond Shielded 034 4-cond Shielded
Through Hole Through Hole
Optional versions have identical specifications and accessories as listed for the standard model
except where noted below. More than one option may be used.
HT
- High temperature, extends normal operation temperatures
[1]
Temperature Range(Operating)
[3]
M
- Metric Mount
Supplied Accessory : Model M039A22 Allen wrench for use with M3 thread (1) replaces Model
039A21
Supplied Accessory : Model M081B93 Insulated cap screw, M3x0.5 thd x 1/2" long (for Model
[2]
M354C10) (1) replaces Model 081B93
2 [1]
)/√Hz
2
[1]
)/√Hz
NOTES:
2 [1]
)/√Hz
[1] Typical.
2 [1]
)/√Hz [2] 250° F to 325° F data valid with HT option only.
[3] Zero-based, least-squares, straight line method.
Ohm
[4] See PCB Declaration of Conformance PS023 for details.
[1]
SUPPLIED ACCESSORIES:
Model 034G05 4-cond. shielded cable, 5 ft (1.5M), 4-pin plug to (3) BNC plugs (1)
Model 039A21 Allen wrench, 3/32" hex (1)
Model 081B93 Insulated cap screw, 5-40 thd x 1/2" long (for Model 354C10) (1)
Model ACS-1T NIST traceable triaxial amplitude response, 10 Hz to upper 5% frequency. (1)
Entered: AP Engineer: JJB
Date: 11/8/2013 Date: 11/8/2013
3425 Walden Avenue, Depew, NY 14043
Revision: G
ECN #: 42197
OPTIONAL VERSIONS
-65 to 325 °F -54 to 163 °C
Sales: WDC Approved: JJB
Date: 11/8/2013 Date: 11/8/2013
Phone: 716-684-0001
Fax: 716-684-0987
E-Mail: info@pcb.com
Spec Number:
17387
