Summary of Contents for SanDisk Sansa SDMX1 1GB
-
Page 1: Table Of Contents
1. Quick Start 1 Features 1 What You Need to Begin 2 Installing the Battery 2 The Basic Controls 4 Play Music 5 Listen to the FM Radio 7 Record Notes and Meetings 8 2. Playing Music 9 Connecting and Disconnecting 9 Using the Music Controls 9 Listening to Music 10 Organizing and Transferring Music 11... -
Page 2: Quick Start
FM radio, and voice recording with your SanDisk Digital Audio Player. Quick Start Congratulations on your purchase of a SanDisk Digital Audio Player! This chapter will help you to become familiar with your new purchase as quickly as possible. Features Your Digital Audio Player is a full-featured music and recording device that can be carried with you anywhere. -
Page 3: What You Need To Begin
Handles MP3, WMA, and WMA DRM music files. CD-ROM drive. USB 2.0 port. In addition, confirm that you have these items in the product packaging that contained your SanDisk Digital Audio Player: Your new Digital Audio Player Earphones Armband AAA battery USB 2.0 cable... - Page 4 5. Swing the battery cover over the battery, and then push the cover towards the center of the player until you hear a snap and the cover closes tight. Step 1 Step 2 Step 3 Figure 1. Installing the AAA Battery Quick Start...
-
Page 5: The Basic Controls
The Basic Controls Your player has a small set of controls that provide a wide range of functionality. To get started, however, you only need to understand the basic controls shown in Figure 2. Figure 2: The Basic Controls The control names and their functions are described in Table 1. Table 1: Control Names and Functions Control Name... -
Page 6: Play Music
Control Name Record Button Change Mode Button Hold Lock/Unlock Button USB Port Microphone Built-in Microphone Earphone Earphone Port To learn advanced information about what onscreen menus appear when you select these controls, see the Navigating the Software Menus chapter that begins on Page 21. Play Music To play music files in MP3 and WMA formats, you need to upload music to your player then use the controls to play your music files. - Page 7 1. Press the Play/Stop button for two seconds. The SanDisk Welcome message will appear onscreen for a moment then disappear. (Can’t find the Play/Stop button on your player? See The Basic Controls section on page 4.) WARNING: If the onscreen message says “Key Hold” and then shuts off, you need to locate the Hold button on the side of your player.
-
Page 8: Listen To The Fm Radio
Listen to the FM Radio Follow these steps: 1. Press the Play/Stop button for two seconds. The SanDisk Welcome message will appear onscreen for a moment and then disappear. (Can’t find the Play/Stop button on your player? See The Basic Controls section on page 4.) WARNING: If the onscreen message says “Key Hold”... -
Page 9: Record Notes And Meetings
Record Notes and Meetings Follow these steps: 1. Press the Play/Stop button for two seconds. The SanDisk Welcome message will appear onscreen for a moment then disappear WARNING: If the onscreen message says “Key Hold” and then shuts off, you need to locate the Hold button on the side of your player. -
Page 10: Playing Music
Record to record notes and meetings. To play your MP3 and WMA files, you need to be in Audio Play mode. Follow these steps: 1. Press the Play/Stop button for two seconds. The SanDisk Welcome message will appear onscreen for a moment then disappear. See The Basic Controls section on page 4 to find the Play/Stop button. -
Page 11: Listening To Music
WARNING: If the onscreen message says “Key Hold” and then shuts off, you need to locate the Hold button on the side of your player. Slide that button towards the Play/Stop button to unlock your device. Then repeat Step 1 above. See The Basic Controls section on page 4 if you cannot find the Hold button. -
Page 12: Organizing And Transferring Music
6. To stop playing music, you have three choices: Press the Play/Stop button until the SanDisk Goodbye screen appears Navigate to another song, select it, then start to play that song Press the A-B Change Mode button to switch to FM Radio or Record mode. -
Page 13: Adjusting Settings
Deleting Music Files from Your Player Follow these steps: 1. Put your player in Audio Play mode. See Using the Music Controls on Page 9 if you need help with this step. 2. Press the Select button to access the browser menu onscreen. See The Basic Controls section on page 4 if you cannot find the Select button. - Page 14 7. Press the Select button to save your new equalizer settings. All music played will use these settings until you change to another equalizer setting. Set Repeat Modes Your player allows you to repeat all or part of a music or audio file. Follow these steps: 1.
-
Page 15: Listening To The Fm Radio
Record to record notes and meetings. To play your FM radio, you need to be in FM Radio mode. Follow these steps: 1. Press the Play/Stop button for two seconds. The SanDisk Welcome message will appear onscreen for a moment then disappear. See The Basic Controls section on page 4 to find the Play/Stop button. -
Page 16: Finding A Radio Station
3. To raise or lower the volume of the radio, press the Up or Down buttons. 4. To stop playing the FM radio, you have two choices: Press the Play/Stop button until the SanDisk Goodbye screen appears. Press the A-B Change Mode button to switch to Audio Play or Record mode. -
Page 17: Setting Preset Stations Automatically
1. Put your player in FM Radio mode. See Using the FM Radio Controls on Page 14 if you need help with this step. 2. Press the Select button to switch between Normal and Preset modes. If the word Empty appears onscreen, no radio station frequencies have been saved as presets. See Save a Radio Station on Page 16 to save a radio station as a preset station. -
Page 18: Delete A Preset Radio Station
3. Press the Record button for two seconds. The Memory icon will appear onscreen. A number will appear to the right of the text. This is the next currently available preset. 4. Use the Left and Right buttons if you want to use a different preset number than the number displayed onscreen. -
Page 19: Recording Notes And Meetings
Radio for radio, and Audio Play for music. To record, you need to be in Voice Record mode. Follow these steps: 1. Press the Play/Stop button for two seconds. The SanDisk Welcome message will appear onscreen for a moment then disappear. See The Basic Controls section on page 4 to find the Play/Stop button. -
Page 20: Start A Recording
Figure 5: The Voice Record LCD screen The control buttons and ports for your player are described in The Basic Controls section on page 4. More detailed descriptions on how the controls work is included in the step-by-step instructions throughout this document. In addition, the Navigating the Software Menus chapter on Page 21 describes the onscreen menus that appear when you use these controls. -
Page 21: Delete A Recording
Delete a Recording Recordings stored on your player can be deleted from your computer or player by using the player controls. Deleting Recordings from Your Computer When your player is connected to your computer with the USB connector, you can use your computer file browser software to view all files and folders on your player. -
Page 22: Navigating The Software Menus
This chapter provides reference information to help you navigate the software menus within your SanDisk Digital Audio Player. Navigating the Software Menus In addition to the ability to play music, listen to FM radio, and record, your player provides you with the ability to customize features within the player. - Page 23 Access the Top Level Menus Follow these steps to access the top level menus: 1. Press the Play/Stop button for two seconds. The SanDisk Welcome message will appear onscreen for a moment then disappear. See The Basic Controls section on page 4 to find the Play/Stop button.
- Page 24 The following example shows how to use the player controls to navigate between menus, settings, and a parameter under the Audio top level menu. 1. Press the Play/Stop button for two seconds. The SanDisk Welcome message will appear onscreen for a moment then disappear. See The Basic Controls section on page 4 to find the Play/Stop button.
- Page 25 6. Press the Select button briefly to access the Play Speed parameter shown in Figure Figure 9: The Play Speed parameter 7. Press the Left and Right buttons to decrease or increase the Play Speed parameter. 8. To exit to the Audio, FM Radio, and Record mode, press the Play/Stop button. See The Basic Controls section on page 4 to find the Play/Stop button.
- Page 26 Submenu Setting Repeat Repeat Shuffle Intro Speed Play Speed Fast Skip File Search Control Resume Display Menus The Display menus control the visual display of your player, for example, the contrast level of the indigo graphic LCD display. The top level Display menu, its submenus, and settings are shown below in Table 3.
-
Page 27: System Menus
System Menus The System menus control the underlying features of your player, for example, the language used onscreen and regional FM radio settings. The top level System menu, its submenus, and settings are shown below in Table 4. Be sure to read The Basics on page 21 to learn how to navigate the menus, settings, and parameters described in this section. -
Page 28: Tips And Troubleshooting
This chapter provides tips and troubleshooting information to help you get the most from your SanDisk Digital Audio Player. Tips and Troubleshooting This chapter provides answers to common questions you may have about your player. Question: How do I copy files to the Digital Audio Player? Answer: You can copy files to the Digital Audio Player just like copying a file on your Hard Drive. -
Page 29: Learn More, Service, And Warranty Information
This will allow us to help you more quickly. Learn More You also can visit us on the web at http://www.sandisk.com to learn more about your player as well as other SanDisk products. Your Limited 1-Year SanDisk Warranty... - Page 30 SanDisk. You must obtain a tracking confirmation number, which you may be required to provide to SanDisk. SanDisk will, at its option, repair or replace the product with new or refurbished product of equal or greater capacity and functionality, or refund the purchase price.
-
Page 31: Safety Tips And Cleaning Instructions
This chapter provides safety tips and instructions to care for your SanDisk Digital Audio Player. Safety Tips and Cleaning Instructions Your player is an electronic device and, therefore, has to be protected from water and other hazards. Follow these tips to keep your player working well for a long time: Read all instructions in this manual carefully before you use your player to ensure proper usage.
