Scope of delivery.
The Radio remote control (RC) comes with 3 AA (1.5V) batteries.
Product description.
The Radio remote control (RC) is a transceiver, which is able to receive and transmit.
Therefore, it is called bi-directional radio remote control. It works in the frequency range of
2.4 GHz which is approved for world-wide use.
Five versions are available:
1) Standard RC, Code No.: 80-2436-01
2) HotSync RC HS-C for Canon cameras, Code No.: 80-8000-03
3) HotSync RC HS-N for Nikon cameras, Code No.: 80-8000-04
4) HotSync RC HS-P for Pentax cameras, Code No.: 80-8000-05
5) HotSync RC HS-S for Sony cameras, Code No.: 80-8000-06
Die Standard RC is designed for flash triggering and controlling of Priolite flash units using
synchronization times up to 1/200 sec.
The HotSync RCs are also suitable for all Priolite flash light units, however, combined with
PRIOLITE HotSync flash units they allow fast shutter speeds as offered by the camera, up
to 1/8000 sec to synchronize.
Four HotSync RCs are available for the use with Canon (C), Nikon (N), Pentax (P), and
Sony (S) cameras, respectively. Nikon cameras are required to have a FP mode available
which has to be selected from the camera drop down menu for HotSync flash triggering. All
HotSync RC versions can be distinguished by the side labeling: 'HS-C' stands for Canon,
'HS-N' for Nikon, 'HS-P' for Pentax, and 'HS-S' for Sony cameras.
The below described functions including the Quick Mask Function apply for all types of
Priolite RCs.
Intended use.
This radio remote control is intended for triggering and controlling all PRIOLITE flash light
units and controlling the LED continuous/video light. The unit may not be used for any
other purpose.
Initial operation.
Before starting up the provided batteries are to be inserted by sliding off the lid of the
battery compartment on the back of the unit. Three batteries type AA are put into place by
observing the polarity (see marks). Then close the battery compartment. A replacement of
batteries is necessary when the control LED 'LOW BAT' is lighting up.
Switching on the unit
The unit is switched on (LED lights up) and off by pressing the ON button. The device
automatically jumps to the single mode and logs usually with Team A / ID 1 with the
respective LEDs lighting up.
