BUTLER
8200 SOUTH CHICAGO AVE. CHICAGO, IL 60617
ITEM
DESCRIPTION
A
top
B1
front legs
B2
back legs
C
shelf
hardware
H1 x 10
bolts M6 x 45mm
SPECIALTY COMPANY
QUANTITY
1
2
2
1
H2 x 10
H3 x 10
spring washer
flat washers
B1
B1
H4 x 1
hex key #4
Assembly Instructions
9355295
END TABLE
B2
A
C
page 01 of 03
B2
Advertisement
Table of Contents
Related Manuals for Butler 9355295
Summary of Contents for Butler 9355295
- Page 1 BUTLER Assembly Instructions 9355295 END TABLE SPECIALTY COMPANY 8200 SOUTH CHICAGO AVE. CHICAGO, IL 60617 ITEM DESCRIPTION QUANTITY front legs back legs shelf hardware H1 x 10 H2 x 10 H3 x 10 H4 x 1 spring washer bolts M6 x 45mm...
- Page 2 step 1 Attach legs (B2) to the top of table (A), insert bolt (H1), flat washer (H2) and spring washer (H3) to the pre-drilled hole and tighten the using the hex key (H4), and repeat with other (B2) leg. step 2 Insert shelf (C) enter bolt (H1) , flat washer (H2) into holes that have been, drilled and tighten using the hex key (H4) page 02 of 03...
- Page 3 (*) Caution : DO NOT OVERTIGHTEN. In any correspondence regarding this product, please include the complete Butler identification number located on the underside of the product. We hope this product will be a useful and decorative addition to your home for years to came.
