Summary of Contents for Samsung MAX-DS9250
- Page 1 THREE-CD CHANGER DVD MINI-COMPACT SYSTEM MAX-DS9250 Instruction Manual...
-
Page 2: Safety Warnings
Safety Warnings CLASS 1 LASER PRODUCT KLASSE 1 LASER PRODUKT LUOKAN 1 LASER LAITE KLASS 1 LASER APPARAT PRODUCTO LASER CLASE 1 CAUTION RISK OF ELECTRIC SHOCK. DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE REAR COVER. NO USER SERVICEABLE PARTS INSIDE. -
Page 3: Table Of Contents
Selecting a Stored Station... 23 Improving Radio Reception ... 23 Press Thank you for buying this SAMSUNG mini-compact system. Please take time to read these instructions. They will allow you to operate your system with ease and take full advantage of its features. -
Page 4: Front Panel View
Front Panel View Standby/On Timer/Clock Timer On/Off Sleep Headphone Jack Connector Program button MIC Level (option) MIC Jack(option) CD Repeat 10. Reverse Mode 11. Deck 1/2 12. Cassette Deck 1 13. Record/Pause 14. TAPE Normal Dubbing 15. CD Synchro Recording 16. -
Page 5: Rear Panel View
Rear Panel View 1. SUB WOOFER PRE OUT 2. VIDEO OUT 3. S-VIDEO OUT 4. SW AERIAL CONNECTOR TERMINAL 5. DIGITAL OUT JACK 6. AM AERIAL CONNECTOR TERMINAL 7. FM AERIAL CONNECTOR TERMINAL 8. AUX INPUT 9. AUDIO OUT 10. LOUDSPEAKER CONNECTOR TERMINALS... -
Page 6: Remote Control
Remote Control Standby/On button TUNER(Band) button DVD button Timer On button MO/ST(mono/stereo) button Power Sound button 3D.Sound button Deck 1/2 button Counter Reset button Play/Pause button Stop button Tuning Preset/CD Skip button Tuning Up/Down/CD Search button TAPE Function buttons To open the cover of the remote control, push the top of the cover, then slide downward. - Page 7 Number(0~9) buttons Remain Remain button Angle Angle button Repeat Repeat button Zoom button Repeat A B button Program button Insert Remote Batteries Follow these precautions to avoid leaking or cracking cells: • Place batteries in the remote control so they match the polarity:(+) to (+)and (–)to (–).
-
Page 8: Where To Install Your Mini-Compact System
Where to Install Your Mini-Compact System To take full advantage of your new mini-compact system, fol- low these installation instructions before connecting the unit. Install the system on a flat, stable surface. Never place this unit on carpeting. Never place this unit in an outdoor area. Maintain an open space of approximately 6 inches (15 cm) on the sides and rear of the system, for ventilation purposes. -
Page 9: Connection Of The Tv Monitor And Vcr (Optional)
Connection of the TV monitor and VCR (optional) The following show examples of connections commonly used to connect the DVD player with a External Source. (Example : TV, VCR, DAT CD-RW, etc) TV monitor LINE IN Audio cord S-Video Composite video (Supplied) •... -
Page 10: Connection For Better Sound
Connection for better sound Connecting to an amplifier with Dolby Pro Logic support. DIGITAL OUT OPTICAL OPTICAL INPUT While playing a DTS disc, no sound is reproduced. In this case, connect to an external amplifier. -
Page 11: Connecting The Am (Mw) Aerial
Connecting the AM (MW) Aerial The AM aerial (for long and medium waves) can be: Placed on a stable surface Fixed to the wall (you must first remove the base) The AM aerial connector terminals are located on the rear of the system and are marked AM . To avoid noise interference, check that the loudspeaker wires do not run close to the aerial wires. -
Page 12: Demo/Dimmer Function
Demo/Dimmer function All functions available on the system can be viewed on the display and the display's brightness can be switched between "on" and "off". Press the Demo/Dimmer button. Result: All functions available on the system appear on the front panel display. -
Page 13: Playing A Disc
Playing a Disc Playback Press the Open/Close( ) button. Place a disc gently into the tray with the disc's label facing up. Press the Play/Pause( ) button or Open/Close( close the disc tray. Pausing Playback Press the Play/Pause ( ) button during playback. To resume, press the Play/Pause ( ) button again. -
Page 14: Forward/Reverse Searching
Forward/Reverse Searching During playback, you can search quickly through a chapter or track for a specific scene or tune. High-Speed Playback Press the button. Each time the button is pressed Each time the PLAY playback (reverse playback) is possible on DVDs. Skipping through a Chapter Press the button. -
Page 15: Slow Playback/Checking The Remaining Time
Slow Playback/Checking the Remaining Time Playing Slowly Press the Slow button. Each time the Slow button is pressed SLOW 1/2 The slow playback speed SLOW 1/4 changes and the selections (1/2X, 1/4X, 1/8X, 1/16X and normal play) are repeated. PLAY Checking the Remaining Time Press the Remain button. -
Page 16: Using Disc Menu/Title
Using Disc Menu/Title To Select the Disc Menu You can use the menus for the audio language, subtitle lan- guage, profile, etc. DVD menu contents differ from disc to disc. Press the Menu button during playback. The Menu Screen appears. When playing a VCD version 2.0, you can operate it using PBC On/Off function. -
Page 17: Selecting The Audio Language/Subtitle Language
Program Playback (Cont’d) To Change the Program Press the Up/Down ( ) button to select the track number to be changed. Press the Enter button to select the title or chapter to be changed. The cursor moves to the next number when the Enter button is pressed again. -
Page 18: Various Dvd Functions
Various DVD Functions To enlarge an image Press the Zoom button. Images can be enlarged 2x and 4x. Zoom During DVD playback, press the mal, in that order. Press ( ) to move the enlarged portion you want to watch. Selecting the desired Screen Angle Press the Angle button. - Page 19 MP3 Playback (Cont’d) To go off the on-screen bar Press the Display button. Each time you press the button, the on-screen bar appears in sequence. MP3 File Compatibility This system can only read MP3 files that are recorded in the format that is compliant with ISO 9660 Level 1 or Level 2.
-
Page 20: System Setup
MP3 Playback (Cont’d) Repeating Playback On an MP3 disc, Repeat A B cannot be used. You can enjoy only repeat play. Press the Repeat button. The indication corresponding to the selected mode appears on the TV screen. Each time you press the button, repeat mode changes as follows: REPEAT:RANDOM : All tracks recorded on the disc will be played once at REPEAT:ONE... - Page 21 System Setup (Cont’d) TV SCREEN(TV SCREEN RATIO) Select when you want to watch a 16:9 screen ratio DVD movie on a TV with a 4:3 ratio screen. LANGUAGES SYSTEM TV SCREEN 4:3 LB RATING LEVEL DIGITAL OUTPUT BITSTREAM : Move Setup : Exit 4:3LB You can see the full 16:9 picture, but black bars will...
-
Page 22: Setting Up The Language Features
Setting up the Language Features Using the DVD player's Setup function, you can customize the Menu Language, Subtitle Language, and Disc Menu Language. To set up the language feature Press the Setup button from the stop mode. LANGUAGES SYSTEM OSD LANGUAGE ENGLISH AUDIO CHINESE... -
Page 23: Selecting A Stored Station
Searching for and Storing the Radio Stations (continued) If you do not want to store the radio station found, revert to Step 4 and search for another station. Otherwise: a Press Memory. Result: The PRGM is displayed for a few seconds. b Press Tuning Down and Up to assign a programme number between 1 and 15. -
Page 25: Tape
Listening to a Cassette Always treat your cassettes with care; refer, if necessary, to the section entitled “Precautions When Using Audio Cassettes” on page 30. Switch the system on by pressing the On/Standby button. Select the TAPE function by pressing TAPE. Open either cassette deck 1 or 2 by pushing and releasing the deck cover where Push Eject ( ) is written. -
Page 26: Recording A Radio Programme
Recording a Radio Programme You can record a radio programme of your choice. You can only record on cassettes in Deck 2. You do not need to adjust the volume, as it has no effect on the recording. Switch the system on by pressing On/Standby. Insert a blank cassette in Deck 2. -
Page 27: Timer Function
Timer Function The timer enables you to switch the system on or off at spe- cific times. Example: You wish to wake up to music every morning. If you no longer want the system to be switched on or off auto- matically, you must cancel the timer. -
Page 28: Mute Function
Mute Function You can turn the sound off temporarily on your system. Example: You wish to answer a telephone call. Press Mute. To switch the sound back on (at the same volume as before), press Mute again or the Volume buttons. Power Sound Function Your mini-compact system is equipped with the function of Power Sound . -
Page 29: Setting The System To Switch Off Automatically
Setting the System to Switch off Automatically While listening to a compact disc or a cassette, you can set the system to switch off automatically Example: You wish to go to sleep to music. Press Sleep. Result: playback starts and the following indications are displayed: 90 MIN Press Sleep one or more times to indicate how long the system should continue playing before it switches off:... -
Page 30: Safety Precautions
Safety Precautions The following diagrams illustrate the precautions to be taken when using or moving your mini-compact system. Ambient operating conditions: Do not expose the unit to direct sun Ambient temperature 5°C-35°C radiation or other heat sources. Humidity 10-75% This could lead to overheating and malfunction of the unit. -
Page 31: Precautions When Using Audio Cassettes
If the above guidelines do not allow you to solve the problem, take a note of: The model and serial numbers, normally printed on the rear of the system Your warranty details A clear description of the problem Then contact your local dealer or SAMSUNG after-sales service. -
Page 32: Technical Specifications
Technical Specifications SAMSUNG strives to improve its products at all times. Both the design specifications and these user instructions are thus subject to change without notice. RADIO Usable sensitivity AM (MW) Signal/noise ratio Usable sensitivity Total harmonic distortion Signal/noise ratio... -
Page 33: Reference
Reference Recorded onto some DVD discs are scenes which have been simultaneously shot from a number ANGLE of different angles (the same scene is shot from the front, from the left , from the right , etc.). With such discs, the Angle button can be used to change the angle of view for specific scenes. These numbers are recorded on DVD discs. - Page 34 THIS APPLIANCE IS MANUFACTURED BY: ELECTRONICS AH68-01235C...
