TURF TANK One Quick Start Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
WELCOME TO
THANK YOU FOR ADDING TURF TANK ONE TO
Get ready to paint perfect lines while saving money and time.
Your Field Operations Engineer will schedule your onsite
installation and training to provide all the tools you'll need to
get up and running.
Right now, there are three things you can do to get ready:
1
Verify the contents of the crate against the crate checklist.
2
Charge up your Turf Tank Tablet, Robot, and Base Station
batteries.
3
Relax. We got you.
Questions? Get help from a Robot Expert. Call or text: 770-818-6020
YOUR STARTING LINEUP!
That's it!

Advertisement

loading
Need help?

Need help?

Do you have a question about the One and is the answer not in the manual?

Questions and answers

Manny Ramirez
March 11, 2025

How can you move a layout to another area?

0
1 comments:
Mr. Anderson
May 14, 2025

To move a layout with TURF TANK One, you must create a new Saved Position using the Base Station. This involves:

1. Turning on the Base Station by pressing the Power button.
2. Pressing and holding the Position button until you hear a short beep.
3. Raising the Base Station on a prism pole to 10–12 feet height.
4. Once the Saved Position is created, turn the Base Station off and then on again (power cycle).
5. Ensure at least 30 yards between multiple Saved Positions.

This process repositions the layout based on the new GPS coordinates.

This answer is automatically generated

-1
Tim Sulaski
February 16, 2025

I need a replacement parts link for the turf tank. My link isn’t working any more

0

Summary of Contents for TURF TANK One

  • Page 1 Right now, there are three things you can do to get ready: Verify the contents of the crate against the crate checklist. Charge up your Turf Tank Tablet, Robot, and Base Station batteries. Relax. We got you.

  • Page 2: Get To Know

    GET TO KNOW Rover Indicator Light On/Off Switch Rear Wheel Emergency Stop Front Wheel Front Bumper Disc-Width Adjustment Knob Rover Sprayer-Height Battery/Paint Adjustment Knob Compartment Spray Discs Sprayer Assembly Shields (Pair) (Solenoid) Robot Antenna Back Bumper Something not right? Questions? GO TO SUPPORT.TURFTANK.COM PRODUCT MANUALS AND MORE HELP...
  • Page 3 GET TO KNOW PAINT SYSTEM Solenoid Power Wire Paint Tube Front Bumper Disc-Width Adjustment Knob Spray Shield Adjustment Knob Spray Shield Sprayer Assembly Quick Fan Cap Spray Nozzle Spray Discs Something not right? Questions? GO TO SUPPORT.TURFTANK.COM PRODUCT MANUALS AND MORE HELP Get help from a Robot Expert.

  • Page 4: Base Station

    GET TO KNOW BASE STATION Pole Battery 8 to 10 hours battery life. Base Station Power Indicator Lights View Capacity Button Power Cable Base Station Prism Antenna Pole Power Port Pole Battery Something not right? Questions? GO TO SUPPORT.TURFTANK.COM PRODUCT MANUALS AND MORE HELP Get help from a Robot Expert.
  • Page 5 GET TO KNOW BASE STATION LP-E6 Battery 1½ hours battery life each. LP-E6 Battery in compartment lid. Battery Compartment B Battery Compartment A LP-E6 Batteries Match battery polarity to lid. Something not right? Questions? GO TO SUPPORT.TURFTANK.COM PRODUCT MANUALS AND MORE HELP Get help from a Robot Expert.
  • Page 6 GET TO KNOW BASE STATION ComNav Position Button Information Panel Position Light Power Button Key to Information Panel Symbols Serial Number Serial Number and QR Code Product Number Antenna Port Prism Pole/ Pole Battery Attachment Port Battery Cover B Battery Cover A Charging Port Match red dot on cable to red line on charging port.
  • Page 7 Determine where to place your Base Station. You will place the Base Station in this spot every time you paint. Install a Turf Tank Ground Spike (or other semi-permanent marker) in the selected spot. Place the Tripod so that the Prism Pole (center pole of Tripod) rests in the installed Ground Spike.
  • Page 8 USE AN EXISTING BASE STATION POSITION Turn on the Base Station by pressing the Power button. On startup, the Base Station Pole Battery automatically searches for Saved Position. The orange Position light flashes to Height indicate the search. Markings When the Base Station has Prism Pole 8 to 12 ft found a Saved Position, it will:...
  • Page 9 CREATE A BASE STATION POSITION Once a Saved Position has LEAVE AT LEAST 30 YARDS been successfully created, you BETWEEN MULTIPLE SAVED must turn the Base Station POSITIONS. power off and turn it on again. The Base Station is now ready to use.
  • Page 10 PAINT: CONCENTRATE Best Practices for Mixing Robot Paint: These are general guidelines. Contact Turf Tank Support or your Field Operations Engineer for brand-specific instructions. Pour water into an empty 5.5 gallon jug: For a mix ratio of 4:1 (bright) use four gallons of water.
  • Page 11 PAINT: (READY TO SPRAY) Instructions: SHAKE AND GO! Shake vigorously or use drill mixer bit for 30 seconds and you’re ready to paint! Cone Nozzle Flat Fan Nozzle USE LESS PAINT! CUSTOM RESULTS! Ideal for: General purpose Ideal for: Football hashes, sports, rounded edges logos, sharp edges Something not right? Questions?

  • Page 12: Troubleshooting

    BASIC TROUBLESHOOTING Robot, Tablet, or Base Station not working as they should? Check the following first: Are the batteries in the Tablet, the Robot, and for the Base Station fully charged? Is the Robot’s battery seated properly in its compartment? Is the compartment latch locked? Are the antennas attached to the Base Station and the Robot?

  • Page 13: Daily Tasks

    IMPORTANT DAILY TASKS Charge batteries EVERY DAY. Charge Robot Batteries. Charge the Tablet. Charge the Base Station batteries (Pole Battery or LP-E6 batteries). Monitor battery life on the Tablet, Robot, and Base Station. If you paint multiple fields a day, consider upgrading to a Pole Battery or buying additional LP-E6 batteries.
