Page 1 Shargeek GaN Charger SG-065 User Manual...
Page 2 Description SG-065 is a 65W travel charger adopting industry leading GaN (Gallium Nitride) technology. Though SG-065 is designed to be ultra-compact and travel-friendly, it is able to provide 65W Power Delivery output.SG-065 equips with USB-C ports and a USB-A port, each port supports a wide range of fast-charging protocols such as QC4+, PD3.0, QC3.0, SCP, FCP,...
Page 3 Model: SG-065 Interface type: USB-A×1, USB-C×1 Input: AC 100-240V~50/60Hz,1.5A Max USB-C Output: 5V/9V/12V/15V 3A,20V 3.25A(65W Max) ⎓ ⎓ USB-A Output: 5V 3A， 9V 2A,12V 1.5A （18W Max） ⎓ ⎓ ⎓ USB-C+USB-A Total Output: 45W+18W （63W Max） Package contains: Charger×1, Instructions×1, Conversion plug×1...
Page 4 DO NOT use at altitudes more than 2000m above sea level. DO NOT use outdoors. 05. DO NOT use power cables with poor quality for charging. According to USB Power Delivery Speciﬁcation, if the charging current is larger than 3A, you must use USB-C E-Marker cables to guarantee the charging safety. If a new device is plugged into the charger during the charging process, the charger will turn oﬀ...
Page 5 Deﬁnition of Product Defect Product Name Defects covered under warranty • Flaws in product structure or material resulting in cracks Shargeek GaN Charger • Plug is loose and cannot be inserted into the socket SG-065 • Unable to charge Warranty Terms...
Page 6 If any kinds of liquid gets into your charger, allow it to dry naturally before using it. Improper use may cause injury, property damage, and may harm yourself. Shargeek is not responsible or liable for any damage or harm incurred because of user’s failure to follow the instructions list in this manual. Support Visit our website at https://www.shargeek.com...
Page 7 Declaration of Hazardous Substances This table is complied according to Standard SJ/T 11364 . The information contained in the table below is based on testing data provided The amount of this hazardous substance in all the homogenous materials used for this part is below the limit. The amount of this hazardous substance in at least one of the homogeneous materials used for this part is above the limit.
