Commissioning, Operation - Cleanfix SW 20 plus Manual

Commissioning / Operation
SW 20 with paper filter bag
The Wet and dry vacuum cleaner SW 20 is not suitable for cleaning surfaces, from which any type of dust or
substances which are flammable, poisonous, caustic, irritating are remove that represent a health hazard.
6
3
A
o
C
SW 21 Combi / SW 21 Aqua with paper filter bag
The Wet and dry vacuum cleaner SW 21 Combi and SW 21 Aqua is not suitable for cleaning surfaces, from which any
type of dust or substances which are flammable, poisonous, caustic, irritating are remove that represent a health hazard.
6
3
A
o
C
SW 20 / SW 21 Combi / SW 21 Aqua
e
8
f
o
A B
6
f
8
D E
8
A B
6
f
8
D E
Changing the paper dustbag
A
The wet and dry vacuum cleaner is equipped with a
two-layer, double-layer unbleached paper filter bag
(o). The two-ply paper filter bag guarantees a
constant high suction.Vacuum switch (3). Locking
handle (6) Press up and suction head (8) decrease.
B Filter basket with cotton cloth (f) Take out. Filled
paper bag (o) disposed of. Make that the motor
protection filter (e) is used.
C Open the new dustbag entirely and place the rubber
ring of the dustbag carefully over the inner part of the
hose connector.
D Filter basket with cotton cloth (f) and clean if neces-
sary. tree cotton cloth or vacuum cleaner for a
thorough cleaning supply and remove the filter
basket with 30 ° with substance. Cotton cloth to dry
and re-insert.
E Place the motor housing (8) back into position and
adjust by pressing the latch (6) back into the
securing position.
Unwind the mains cable (7) completely from the motor
housing. Attached required accessories.
Now you may proceed with vacuum cleaning by pressing
the main switch (3) on.
Changing the paper dustbag
A
The wet and dry vacuum cleaner is equipped with a
two-layer, double-layer unbleached paper filter bag
(o). The two-ply paper filter bag guarantees a
constant high suction.Vacuum switch (3). Locking
handle (6) Press up and suction head (8) decrease.
B
Filter basket with cotton cloth (f) Take out. Filled
paper bag (o) disposed of. Make that the motor
protection filter (e) is used.
C
Open the new dustbag entirely and place the rubber
ring of the dustbag carefully over the inner part of the
hose connector.
D
Filter basket with cotton cloth (f) and clean if neces-
sary. tree cotton cloth or vacuum cleaner for a
thorough cleaning supply and remove the filter
basket with 30 ° with substance. Cotton cloth to dry
and re-insert.
E
Place the motor housing (8) back into position and
adjust by pressing the latch (6) back into the
securing position.
Unwind the mains cable (7) completely from the motor
housing. Attached required accessories.
Now you may proceed with vacuum cleaning by pressing
the main switch (3) on.
Englisch 12
