Glen Dimplex SIDW15 User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

EN Semi-Integrated Dishwasher / User Manual
SIDW15

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SIDW15 and is the answer not in the manual?

Questions and answers

Keith Rogers
May 19, 2025

have error code h17, can't operate dishwasher

0

Subscribe to Our Youtube Channel

Related Manuals for Glen Dimplex SIDW15

Summary of Contents for Glen Dimplex SIDW15

  • Page 1 EN Semi-Integrated Dishwasher / User Manual SIDW15...
  • Page 2 Thank you for choosing this product. This User Manual contains important information on safety and instructions intended to assist you in the operation and maintenance of your appliance. Please take the time to read this User Manual before using your appliance and keep this book for future reference.

  • Page 3: Table Of Contents

    CONTENTS 1.SAFETY INSTRUCTIONS ....................1 1.1. General Safety Warnings ....................1 1.2. Installation Warnings .....................1 1.3. During Use........................2 2.INSTALLATION ......................... 6 2.1. Machine Positioning .....................6 2.2. Water Connection ......................6 2.3. Water Inlet Hose ......................6 2.4. Drain Hose........................6 2.5. Electrical Connection ....................7 2.6.

  • Page 4: Safety Instructions

    1. SAFETY INSTRUCTIONS 1.1. General Safety Warnings • Read these instructions carefully before using your appliance and keep this manual for future reference. Please check the packaging of your machine before installation and the outer surface of the machine once the packaging has been removed. Do not operate the machine if it appears damaged or if the packaging has been opened.

  • Page 5: Installation Warnings

    1.2. Installation Warnings • Choose a suitable and safe place to install your machine. • Only original spare parts should be used with the machine. Unplug the machine before installation. Your machine must only be installed by an authorised service agent. Installation by anyone other than an authorised agent may cause your warranty to be void.
  • Page 6 • it for other purposes. Commercial use will void the guarantee. Do not stand, sit or place loads on the open door of the dishwasher. Only use detergents and rinse aids produced specifically for dishwashers. Our company is not responsible for any damage that may occur due to misuse.
  • Page 7 be performed by an authorised service company, otherwise the warranty will be void. Before repair work, the machine should be disconnected from the mains. Do not pull the cable to unplug the machine. Switch off the water tap. Operation at a low voltage will cause a decline in performance levels.
  • Page 8 CE Declaration of Conformity We declare that our products meet the applicable European Directives, Decisions and Regulations and the requirements listed in the standards referenced. Disposal of your old machine The symbol on the product or on its packaging indicates that this product may not be treated as household waste.

  • Page 9: Installation

    2. INSTALLATION WARNING: Run water through the new hose before connecting. 2.1. Machine positioning When positioning the machine, place it in WARNING: Connect the hose directly an area where dishes can be easily loaded to the water inlet tap. The pressure and unloaded.

  • Page 10: Electrical Connection

    2.5. Electrical connection WARNING: Your machine is set to operate at 220-240 V. If the mains voltage supply to your machine is 110 V, connect a transformer of 110/220 V and 3000 W between the electrical connection. The earthed plug of the machine must be connected to an earthed outlet supplied by suitable voltage and current.

  • Page 11: Technical Specifications

    3. TECHNICAL SPECIFICATIONS 3.2. Technical specifications 3.2. Technical specifications 15 place Capacity settings Dimensions Height 820-870(mm) Width 598(mm) Depth 570(mm Net weight 41 kg Operating 220-240V 50 voltage / (Hz) frequency Total 10(A) current 3.1. General appearance 1. Upper basket with racks Total power 1900(W) 2.

  • Page 12: Before Using The Appliance

    When you stop using combined detergents, 4. BEFORE USING THE make sure that rinse aid settings are set to APPLIANCE correct level. 4.4. Rinse-aid usage 4.1. Detergent usage Rinse-aid makes dishes sparkle and helps Only use detergents specifically them to dry without spotting. Rinse-aid is required for stain-free utensils and clear designed for domestic dishwashers.

  • Page 13: Loading Your Dishwasher

    5. LOADING YOUR In order to change the rinse aid level, follow the below steps before turning on DISHWASHER the machine: For best results, follow these loading • Push the programme button and hold it guidelines. down. We recommend that you place large items •...
  • Page 14 Upper Basket The upper basket includes a mechanism which enables the height of the basket to be adjusted up (1) or down (2) without having to remove the basket. Hold the basket on both sides and pull it up or push it down, ensuring both sides of the upper basket are in the same position.
  • Page 15 Four Folding Racks basket, after washing. (15 pc) The folding racks allow easier placement of larger items, such as pots and pans. Each section can be folded separately. The racks can be raised up, or folded down, as shown in the images. The upper cutlery basket is composed of two pieces that can be separately removed.

  • Page 16: Alternative Basket Loads

    5.2. Alternative Basket Loads Lower Basket Top basket Incorrect loads EN - 13...

  • Page 17: Programme Table

    6. PROGRAMME TABLE Duration Programme Description (min) Fast programme intended for recently used dishes which are lightly soiled. Mini 14’ Suitable for 4 place settings. Quick 30’ Quick wash programme for lightly soiled dishes. Standard programme for dishes which are used daily but are not heavily soiled.

  • Page 18: The Control Panel

    7. THE CONTROL PANEL Starting the Machine and Selecting a Programme 3 4 5 6 7 8 Press the Power On/Off button (1), the display (9) will show the most recently selected programme. Select the programme most suitable for P P P P P P P P your dishes using the Programme button (4).

  • Page 19: Changing A Programme

    corresponding to the status of the • The display will count down from 3 to 1. programme in operation. While the When it finishes, the time remaining for Drying symbol is displayed, the machine cancellation will show on the display. will remain silent for 45 to 50 minutes.

  • Page 20: Cleaning And Maintenance

    8. CLEANING AND the filters. Replace the filter insert, and MAINTENANCE rotate it clockwise (4). • Never use your Dishwasher without a Cleaning your Dishwasher is important filter. to maintain the machine’s service life. • Incorrect fitting of the filter will reduce Oil and lime may build up in your the washing effectiveness.

  • Page 21: Troubleshooting

    9. TROUBLESHOOTING FAULT POSSIBLE CAUSE TROUBLESHOOTING Your Dishwasher is not plugged in. Plug your Dishwasher in. Switch your Dishwasher on by pressing the Your Dishwasher is not switched on. On/Off button. Fuse blown. Check your indoor fuses. The programme does not start.
  • Page 22 FAULT POSSIBLE CAUSE TROUBLESHOOTING Use the correct amount of detergent, as Not enough detergent used. instructed in the programme table. Whitish stains remains Rinse aid dosage and/or water Increase rinse aid and/or water softener on dishes. softener setting set too low. level.

  • Page 23: Practical Information

    AUTOMATIC FAULT WARNINGS AND WHAT TO DO TROUBLE POSSIBLE FAULT WHAT TO DO CODE Make sure the water inlet tap is open and water is flowing Separate the inlet hose from the tap and clean the filter of Insufficient water the hose.
  • Page 24 MANUFACTURER GUARANTEE This warranty is provided in Australia by Glen Dimplex Australia Pty Limited ABN 69 118 275 460 (Phone number 1300 556 816) and in New Zealand by Glen Dimplex New Zealand Limited NZBN 9429000069823 (Phone number 09 274 8265) in respect of the Glen Dimplex product.
  • Page 25 4. How to make a claim You may make a claim under this warranty through our website, contacting our customer care line or via email. Contact details for Glen Dimplex Australia and New Zealand can be found at the end of this document...
  • Page 26 Refurbished parts may be used to repair the goods. Products are designed and supplied for normal domestic use. We will not be liable to you under this warranty for business loss or damage of any kind whatsoever. Glen Dimplex Australia Pty Ltd Glen Dimplex New Zealand Ltd www.glendimplex.com.au www.glendimplex.co.nz...
  • Page 27 All Glen Dimplex appliances are for Domestic use only, and must be installed by a licence installer into Domestic Applications only, without exception and to the required Authorities guidelines. Any installation outside of this will VOID warranty.
