- Page 1 Thermoelectric Air conditioner installation and operation manual FOR 800 Btu MODEL #’S AAC-141-T-E AAC-141-4XT-E AAC-141-T-E-HC AAC-141-4XT-E-HC AAC-141-XXXXX Quality enclosures and cooling solutions for every environment...
- Page 2 TABLE OF CONTENTS 1. GENERAL INFORMATION PRINCIPLES OF OPERATION ................... 2. INSTALLATION CHOOSING A LOCATION ................ORIENTATION ..................... PREPARING THE ENCLOSURE ..............INSTALLING THE AIR CONDITIONER ............. INSTALL THE DRIP PAN ................APPLY POWER .................... 3. OPERATION THERMOSTAT SET POINTS AND HEATING COOLING UNITS ... MAINTENANCE ..................
-
Page 3: General Information
See Figure 1.1. ISC uses only the highest quality components in our air conditioners and you can expect years of trouble free cooling from these solid-state devices. Every unit we sell is backed by our one year parts and labor warranty. -
Page 4: Installation
Mounting the unit with the fins pointing to either side or straight up will cause condensate to drip in an uncontrolled manner, possibly damaging electronic equipment within the enclosure. If one of these orientations is the only possible configuration, contact the Engineering Dept. at ISC for a custom solution. - Page 5 FIGURE 2.1 FIGURE 2.2...
-
Page 6: Preparing The Enclosure
2.3 PREPARING THE ENCLOSURE To mount the 800 Btu unit you will need to cut an opening in your enclosure and drill mounting holes. A cut-out drawing (Fig. 2.3) showing the cut-out size and hole locations has been included in this manual (see Fig. 2.3). The instructions for installing the air conditioner are printed below. - Page 7 b. If this is an indoor installation with no chance of exposure to water or other liquids, you can use 8 screws per the NEMA 12 pattern in Fig. 2.3. c. If this is a NEMA 4X installation (outdoors or chance of exposure to liquids) use all 16 screws provided.
- Page 8 2. There are three mounting holes in the drip pan, match these with the long mounting screws protruding into the enclosure at the bottom of the AC unit. Push the drip pan onto these screws. 3. Using the three 8-32 keps nuts provided, attach the drip pan to the air conditioner. 4.
- Page 9 DC voltage units – this unit will not have a plug on the end. Connect the wires to an appropriate power source using standard safe wiring methods. Wire colors are as follows: Red - Positive Black - Negative Green – ground A wiring diagram is shown in Fig.
-
Page 10: Operation
EXPOSED TO WATER AND SHOULD NEVER BE WASHED DOWN. NEVER EXPOSE THE COLD SIDE OF ANY AIR CONDITIONER (INSIDE THE ENCLOSURE) TO WATER. If you have any questions about any aspect of your ISC air conditioner, don’t hesitate to call us at the numbers listed below.
