- Page 1 TABOR 12S4P/12S6P/12S8P HP1 and HR1 Controller OWNER’S MANUAL...
- Page 2 Appropriate precautions naturally mitigate these risks. NEVER CHARGE your board UNATTENDED! AVOID WATER ! Your Hoyt St board is water resistant, not waterproof. The electronics and other components are susceptible to water damage.
- Page 3 READ BEFORE YOU RIDE ! ALWAYS WEAR A HELMET when riding the board. Other protective gear like wrist guards, gloves, elbow and knee pads are also strongly recommended. THE BOARD MAY LOSE POWER OR BRAKES due to low batteries or regenerative braking overcharge.
- Page 4 Maximum grade in mode 3 on a full charge is >40% while mode 2 is 25% and mode 1 is 15%. WEIGHT Your Hoyt St Tabor weighs in at 38 to 42 pounds. The ranges, speeds and grades noted above are assuming a 180 pound rider.
-
Page 5: Remote Control
GLOSSARY REMOTE CONTROL RC POWER THROTTLE MODE TIME TRAVEL REVERSE (LEFTIES) LANYARD THROTTLE USB CHARGING PORT TOP VIEW BOTTOM VIEW... -
Page 6: External Components
EXTERNAL COMPONENTS BATTERY INDICATOR KINGPIN & BUSHING TRUCK UNDERCARRIAGE DECK FASTENERS POWER BUTTON CHARGE PORT TIRES BELT BELT TRUCK WHEEL PULLEY MOTOR MOUNT BRUSHLESS BASHGUARD MOTORS MOTOR GEAR CAUTION: KEEP FINGERS, COVER HAIR & LOOSE CLOTHING AWAY FROM MOVING PARTS. - Page 7 CHARGER Hoyt St chargers are UL certified and built with the highest level of quality and safety. To charge your board, plug in the charger to the port located on the rear left side of the enclosure. Lift open the charging hatch and insert the charger.
-
Page 8: Operation
OPERATION GETTING STARTED CHARGE THE DECK Full charge Charger light turns green 12s4p = 2½ hours when deck is fully charged. 12s6p = 3½ hours 12s8p = 4½ hours CHARGE THE REMOTE Full charge = 6-8 hours of use with a 30-60 minute charge. LEDs glow green when full charge reached. - Page 9 OPERATION LET’S RIDE! SAFETY FIRST ALWAYS WEAR A HELMET and consider other protective equipment. Verify the board is functioning (without rider) in a flat, open area clear of obstructions. If this is your first ride, we urge you to get a feel for the power and nuance of the board in beginner mode.
- Page 10 POWER THE REMOTE ON AND OFF Press and hold the power button until it vibrates. ON: hold 1½ seconds (short vibration) OFF: hold 1½ seconds (long vibration) AUTO-OFF: after 5 minutes of inactivity. POWER THE DECK ON AND OFF ON: hold for 0.5 seconds. LED light will illuminate.
- Page 11 Double click again to unlock. Throttle Lock: double click to lock/unlock. Blue light will glow when locked. MODE : Hoyt St remote control comes with three modes: Click once to toggle between modes., each mode vibrating (once, twice or thrice) to indicate mode.
- Page 12 Remote Control (Re-)Pairing: P airing is the process of wirelessly coupling your remote control transmitter with the receiver built into the board so other transmitters cannot interfere with data transmission. To re-pair the remote: • Turn off skateboard and remote control. •...
- Page 13 • Be sure to use blue Loctite on the screws when reinstalling pulleys.. Hoyt St will transfer your wheel pulleys to new wheels free charge when wheels purchased from Hoytskate.com.
- Page 14 • If necessary, manually adjust the belt and motor mount for proper alignment and re-tighten the bolts. Belt maintenance: Hoyt St belts have been built to last hundreds of miles without replacement. nspect belts and pulleys periodically by manually rotating the wheels.
-
Page 15: Limited Warranty
LIMITED WARRANTY Your Hoyt St electric skateboard is covered by a 6..month manufacturer’s warranty, covering defects in craftsmanship and materials. Not covered is damage as a result of abuse, misuse, neglect, negligence, accident or exposure to water. Modification of components and/or tampering with the electronics voids the warranty. - Page 16 922 NW 11 AVE 104, PORTLAND, OREGON 97209 www.hoytskate.com © Hoyt PDX Electric, LLC 2018...
