Cleaning
Warning: Before cleaning, disconnect from
mains supply and allow luminaire to cool.
1
2
Disposal
Ensure correct disposal of this
product (waste electrical and
electronic equipment).
Edition 23.11.21 | Product design and technical data may be subject to change
All manuals and user guides at all-guidesbox.com
unios.com
Page 4/4
Corrosion Protection
It is important to note that care must be taken
during installation or maintenance to ensure that
the surface of the luminaire is not damaged. Any
damage, which is exposed to moisture will result
in corrosion occurring.
Please also note that any chemical applications on
the luminaire or chemical contact via installation will
cause corrosion of the surface of the luminaire and will
void the warranty.
Ambient Conditions
Recommended to install in an
ambient temperature <35°C.
Astro Fixed Two
Base
Fixed Two
Codes
ASTW0007
Class I
IP Rating
Material
220–240V ~ 50/60Hz
65
Aluminium
CAUTION – This product must be installed by a qualified installer
Please read instruction manual carefully before installing luminaire
Surge Protection
For comprehensive protection of a luminaire against electrical surges, surge protection shall be installed
on the mains supply where required to protect luminaires and drivers from transient voltage damage.
For warranty information visit unios.com/warranty
Please read these installation instructions carefully before installing this product. This product must be installed and
maintained by a suitably qualified person/s in compliance with the latest applicable regulations and relevant legislation.
Unios does not warrant any claim based on defects or damage caused by misuse, improper installation, improper
operation and/or modifications carried out by the purchaser or third parties. This product shall not be used as a
'working light' during construction. This will result in the warranty of the product to be void. For warranty duration,
please refer to the data sheet.
B
Edition 23.11.21 | Product design and technical data may be subject to change
unios.com
Page 1/4
WALL LIGHT
Power
7 Watts
Install Person/s
1x
Sizing Variations
Product Code
A
B
C
ASTW0007
110
90
25
All measurements are in millimetres.
Parts
1x Allen Key
2x Wall Plugs
2x Wall Screws
2x Seal Washers
3x Heatshrink
Solder Joiners
