- Page 1 SenseCAP Quick Start for SenseCAP M2 Multi Platform Gateway & SenseCAP Sensors This tutorial will guide you to use the SenseCAP M2 Multi Platform gateway connect to SenseCAP LoRaWAN® sensors.
-
Page 2: Table Of Contents
SenseCAP T ableofContents 1.Gateway Network Configuration ......................1 1.1 Connect to Ethernet Cable ......................1 1.2 Connect to WIFI via Luci........................2 1.3 POE connection............................7 1.4 Checking the Gateway Connection Status..............8 2. Bind the gateway..............................9 3. Connect the SenseCAP Sensors......................11 4. SenseCAP Portal and Mate APP ......................13 4.1 Gateway Info............................13 4.2 Sensor data ............................ -
Page 3: Gateway Network Configuration
SenseCAP 1.Gateway Network Configuration Connect the antenna and power adaptor to the gateway. The power LED will show in red, and in about 15s, the indicator on the top will flash green, indicating that the gateway is booting. There are two ways to connect to the Internet. Choose the one that works for you. -
Page 4: Connect To Wifi Via Luci
SenseCAP 1.2 Connect to WIFI via Luci There are two ways for users to login Luci configuration page. 1.2.1 Access via router Step 1: Connect your device to a Ethernet cable, and connect your PC to the same router. Note: Your PC and device should be connected to the same router/network. - Page 5 SenseCAP Step 4: Login Luci Input the IP Address of your device in a browser to enter the Luci page. Then input your device username and password to login. 1.2.2 Access via device AP hotspot Step 1: Turn on the device AP hotspot. ...
- Page 6 SenseCAP Step 3: Get your device Username and Password You can find the Username and Password on your device label. Step 4: Log in to the Local Console Input the IP Address (192.168.168.1) in your browser to enter the Local Console.
- Page 7 SenseCAP Step 5: Connect to a WIFI Click on Network - Wireless Click on the Scan button to scan the WIFI. Select your WI-FI to join the network.
- Page 8 SenseCAP Submit the Wi-Fi password, and then click “Submit” and “Save”. The indicator on the top will show solid green if the gateway is successfully connected to the WIFI.
-
Page 9: Poe Connection
SenseCAP 1.3 POE connection SenseCAP M2 supports PoE ( Power on Ethernet) and is compatible with IEEE 8 0 2 . 3 af standard. Note: You will need to have an extra PoE switch that provides 40V-57V DC power as a PSE (Power Sourcing Equipment) if your modem/router does not support PoE. -
Page 10: Checking The Gateway Connection Status
SenseCAP 1.4 Checking the Gateway Connection Status After powering on the gateway, there are two ways for you to check the gateway working status:: 1) LED Indicator Mode Description Gateway is healthy and the internet is well connected. Solid Green Gateway is booting, please wait. -
Page 11: Bind The Gateway
SenseCAP 2. Bind the gateway SenseCAP Mate APP supports device configuration and remote management. Step 1: Download the SenseCAP Mate APP SenseCAP Mate APP for iOS on App Store SenseCAP Mate APP for Android on the Google Play Store You can also download App from App Center Step 2: Login the APP... - Page 12 SenseCAP Step 3: Add device Click the + in the upper right corner and select Add device Then scan the QR code on your gateway label. Set up your device name and location. Then confirm your settings. After successful binding, you will see your gateway in the Device directory.
-
Page 13: Connect The Sensecap Sensors
SenseCAP 3. Connect the SenseCAP Sensors Step 1: Add device Click the + in the upper right corner and select Add device Then scan the QR code on your gateway label. - Page 14 If your gateway is US915 version , then you need to set your sensor to US915 frequency. Note : SenseCAP M2 Multi-Platform Gateway can’t connect to Helium network. For more configurations about SenseCAP sensors, please refer to:...
-
Page 15: Sensecap Portal And Mate App
SenseCAP 4. SenseCAP Portal and Mate APP SenseCAP Mate APP and SenseCAP Portal can be used to check your device status and device management. SenseCAP Mate APP for iOS on App Store SenseCAP Mate APP for Android on the Google Play Store ... -
Page 16: Sensor Data
SenseCAP 4.2 Sensor data Check the sensor data on the SenseCAP Portal and SenseCAP Mate APP SenseCAP Portal SenseCAP Mate APP...
