- Page 1 Take charge of your world. User Manual and Installation Guide Pure Sine Wave SX Series Hybrid Solar Inverter 2yrs 800W-5000W 12V-48V PWM/MPPT Warranty Built-in PWM/MPPT Controller. Smart battery management system. Multiple protection systems.
- Page 2 Applications Ideal for integration with PV solar systems, battery backup, and hybrid sytems. Can be used with Lithium, AGM, Lead-Acid batteries to provide backup power when an electricity grid blackout occurs. Pure Sine Wave SX-S Hybrid Solar Inverter 800W-5000W 12-48V PSX-0800012/160012/320024/500048 Scan to download manual.
-
Page 3: Table Of Contents
Table of Contents Safety Instructions Illustrations LED Panel Operation Error Codes for Reference Installation Battery Configurations Parallel Battery Wiring Difference between Series and Parallel connections Troubleshooting Scope of Warranty Technical Data and Specifications... -
Page 4: Safety Instructions
Safety Instructions General Please read the manual and all the safety remarks. This product is designed and tested in accordance with international standards. It must be used exclusively for the purpose for which it was designed. WARNING ELECTRIC SHOCK HAZARD This product works with rechargeable batteries. -
Page 5: Illustrations
Illustrations and Layout Diagrams 800W 1000KVA 12V Model Number PSX-080012... - Page 6 Illustrations and Layout Diagrams 1600/3200W 2000/4000KVA 12V/24V Model Numbers PSX-160012/PSX-300024...
- Page 7 Illustrations and Layout Diagrams 5000W 6250KVA 48V Model Number PSX-500048...
-
Page 8: Led Panel
LED Panel Indicator Lights Function Keys LED Indicators LED Indicator Messages Solid On Output is powered by utility in Line mode. AC / Inv Green Flashing Output is powered by battery or PV in battery mode. Solid On Battery is fully charged. Charge Yellow Flashing... -
Page 9: Operation
Operation General Please read the manual and all the safety remarks. This product is designed and tested in accordance with international standards. It must be used exclusively for the purpose for which it was designed. Inverter Mode When the electricity supply is off, or generator power disconnected, it will transfer to inverter mode. - Page 10 Display Display Display Settings Setting range Descriptions (Left) (Mid) (Right) Narrow range Mains input range is 155-265V Mains input voltage range Wide range Mains input range is 180-265V Narrow range Mains input frequency range is 45-65HZ Mains frequency voltage range Wide range Mains input frequency range is 40-70HZ The utility power will provide power to the...
- Page 11 Display Display Display Settings Setting range Descriptions (Left) (Mid) (Right) High speed Mains detection Mid. speed Mains sensitivity settings: high medium low speed Low speed 50Hz Inv. output Set inverter output frequency frequency 60Hz Restart 3 times after short circuit or overload Fault restart switch No restart after short circuit or overload Always on...
-
Page 12: Error Codes For Reference
Error Codes for Reference Tables Display (Left)__1 Tables Display (Right)__2 Tables Details__3 Inverter communication connection failure alarm Abnormal mains output alarm Abnormal machine load alarm Inverter overload alarm Abnormal output alarm High battery voltage alarm Low battery voltage alarm Memory chip read and write error alarm Memory chip connection failure alarm Inverter over temperature alarm Load-causing over temperature alarm... -
Page 13: Installation
Installation WARNING A qualified electrician should install this product. Locating and Mounting the Inverter The unit must be installed in a dry and well-ventilated area, as close as possible to the batteries. There should be a clear space of at least 100mm all around the unit for cooling. High temperatures can possibly result in the following issues: Reduced lifespan of the unit. - Page 14 DC Wiring WARNING DO NOT connect the DC wires from the battery bank to the inverter until: All AC wiring is complete, The correct DC and AC protection switches are OFF The correct DC voltage and polarity have been verified Depending on the type of batteries you use in the installation (6 or 12VDC), the batteries must be wired in series, parallel, or series-parallel.
- Page 15 DC Wiring Size It is important to use the correct sized DC wire to achieve maximum efficiency from the system and to reduce fire hazards associated with overheating. Always keep your wire runs as short as practically possible to prevent low voltage shutdowns and to keep the DC breaker from nuisance tripping (or open fuses) because of increased current draw.
-
Page 16: Battery Configurations
Battery Configurations Model DC Rating (Volts) Minimum Batteries Maximum Batteries PSX-080012 PSX-160012 PSX-300024 PSX-500048 Parallel Battery Wiring 12 Volt Battery In Series 24 Volts battery (total capacity=200 Ah) Difference between Series and Parallel connections Batteries in Parallel Batteries in Series Voltage remains the same Voltage doubles Ah capacity doubles... -
Page 17: Troubleshooting
Troubleshooting Proceed as follows for quick detection of common faults. DC loads must be disconnected from the batteries and the AC loads must be disconnected from the inverter before the inverter and/ or battery charger is tested. Consult your local dealer/repair center if the fault cannot be resolved. Note If the fuse is blown due to the reverse connection of the battery or overcurrent, please remove the right fan and replace the fuse. -
Page 18: Technical Data And Specifications
Technical Data and Specifications Model PSX-080012 PSX-160012 PSX-320024 PSX-500048 Input Capacity (VA) 1000VA 2000VA 4000VA 6250VA Voltage (DC) Nominal Voltage 220VAC/110VAC Voltage Range 154-265VAC/77-135VAC Frequency 50-60Hz Auto-Sensing Output Watts 800W 1600W 3200W 5000W Voltage 220VAC/110VAC (+10% UPS Mode) Frequency 50/60Hz Waveform Pure Sinewave Transfer Time(AC to DC) - Page 19 Technical Data and Specifications Model PSX-080012 PSX-160012 PSX-320024 PSX-500048 Battery Low Recovery Battery Light Discharge 12V*N; Battery Load Discharge 12V*N@Load<20%; Battery Light Discharge 11V*N; Battery Load Discharge 11 V*N@Load<20%; DC Low Voltage Shutdown 10.5V*N@Load>50% / 10V*N@Load>50% DC High Voltage Alarm and Fault 16V*N DC High Voltage Recovery 15V*N...
- Page 20 Appendix How to choose and configure PV panels The following parameters can be found in the specifications of each PV panel: Pmax: Maximum output power (W) Voe: Open circuit voltage (V) lsc: Short circuit current (A) Vpm: Rated voltage (V) 1pm: Rated current (A) PV panels can be connected in series or in parallel to obtain the required output voltage and current to meet the specified range of the solar controller.
- Page 21 Example 1 Take a 12 V inverter as an example to select suitable PV modules. Considering that the total Voe of the PV panel cannot exceed the maximum (PWM controller 30 V / MPPT controller 60 V). The total power should be equal to or slightly greater than 800 W, we can choose the following specifications of PV panels.
- Page 22 Example 2 Take a 24 V inverter as an example to select suitable PV modules. Consider that the maximum total Voe of PV panels cannot exceed ( PWM controller 60 V / MPPT controller 60 V ). The total power should be equal to or slightly greater than 1600 W,we can choose the following specifications of PV panels.
- Page 23 Example 3 Take the 48 V inverter as an example to select the appropriate PV module. Consider that the total Voe of the PV panel cannot exceed the maximum ( PWM controller 105 V / MPPT controller 150 V). The total power should be equal to or slightly greater than 3200 W, we can choose the following specifications of PV panels.
- Page 24 Pure Sine Wave SX-S Hybrid Solar Inverter 800W-5000W 12-48V PSX-0800012/160012/320024/500048 Scan to download manual. This product should be installed by a qualified electrician or an approved installer. Warning Electric shock hazard. www.pwrproducts.co.za Illumin8 Imports (Pty) Ltd. www.pwrproducts.co.za...
