Summary of Contents for Forno FCTIN0539-36
- Page 1 FCTIN0539-36 Model: Five Burner User Guide...
-
Page 2: Table Of Contents
Thank you for purchasing the our Induction five burner unit. Please read the entire instruction manual prior to using your unit. You can download an owner's&installation manual at www.forno.ca. Customer service : 1-866-231-8893 Fill out the following information for future reference... - Page 3 I. Important Safety Information When using electrical appliances,basic safety precautions should always be followed.For the Induction cooker,even with the built-in safety features,it is essential to heed all precautons. Installation of the appliance into a kitchen countertop and its connection to the main power and electrical supply may only be performed by a qualified technician.
- Page 4 I. Important Safety Information Proper Installation-Be sure your appliance is properly installed and grounded by a qualified technician. Never Use Your Appliance for Warming or Heating the Room. Do Not Leave Children Alone-Children should not be left alone or unattended in area where appliance is in use.
- Page 5 I. Important Safety Information Do Not Cook on Broken Cook-Top-If cook-top should break, cleaning solutions and spillovers may penetrate the broken cook-top and create a risk of electric shock. Contact a qualified technician immediately. Do Not Cook on Broken Cook-Top-If cook-top should break, cleaning solutions and spillovers may penetrate the broken cook-top and create a risk of electric shock.
- Page 6 I. Important Safety Information This product should not be thrown away as household waste. Instead it should be handed over to the applicable collection point for the recycling of electrical and electronic equipment. By ensuring this product is disposed of correctly, you will help prevent potential negative consequences to the environment and human health, which could otherwise be caused by inappropriate waste handling of this product.
-
Page 7: Control Panel Overview
II. Control Panel Overview 1. Front left cooking zone 2. Back left cooking zone 3. Back right cooking zone 4. Front right cooking zone 5. Middle cooking zone Ceramic glass Touch control panel Diagram may look different from actual product. 7. -
Page 8: Specifications & How To Use
III. Specifications & How to Use Power 9600 Watts Voltage 240V / 60Hz Power Range 100W - 3700W Level Selection Select settings 1 through 9 Max Time Set timer from 1 to 99 minutes Glass Ceramic Top / Metal Body Material Unit Measurements 36"... -
Page 9: Operating The Keys
III. How to Use Readiness Mode While on standby mode, press the main “ ” key, the induction hob will make a “beep” sound once indicating that it is ready to use. If only the indicator light above the “ ”... -
Page 10: Lock
III. How to Use Lock Activating the Child Safety Lock during cooktop use: Child Lock prevents activation of any sensor key, except for the “ ” key and the “Lock” key. A. Manual: Press the Lock key to activate the function. The unit will make a “beep”... -
Page 11: Timer
III. How to Use Timer Setting the Timer to Automatic switch-off: With the desired heating zone Powered ON, press the “Timer” key. The timer display will blink and show a “00”, Press the “+” or “-” to increase or decrease to the desired time until the desired time appears in the display (Choose up to 99 minutes). -
Page 12: Compatible Cookware
IV. Compatible Cookware Induction requires pots and pans that are made of ferrous(meaning magnetic) materials. Check your cookware’s retail box for the induction symbol. To tell if your current cookware is compatible with the induction technology, grab a magnet and see if it holds to the bottom of the cookware. - Page 13 V. Cleaning and Maintenance: Cleaning Burned on Residue: WARNING: Damage to the glass surface may occur if you use scrub pads or any other type of abrasive cleaning materials. 1. Allow the cooktop to cool. 2. Spread a few drops of the ceramic cooktop cleaner on the burned residue area. Using the included ceramic cooktop cleaning pad, rub the residue area, applying pressure as needed.
- Page 14 VI.Counter Installation Instructions for 1" thickness or less Warning! For Your Safety:Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance.To eliminate the risk of burns or fire due to overheating,cabinets located above the induction unit should be avoided.If cabinet space is available, the risk can be reduced by installing a range hood that protects horizontally at a minimum of 5 inches below the bottom of the cabinets.
- Page 15 VI.Counter Installation Instructions: 70mm(2-3/4") Note:do not put a OVEN divider between the oven and cooktop Cooktop Dimensions A. Width B. Depth C. Height D. Height 36" 21" 5/32" 2-5/32" Cooktop Cutout Dimensions E.Depth G.Depth I. Depth F.Depth H. Depth Minimum:19-21/32" Minimum:13/32"...
-
Page 16: Counter Installation Instruction
VI. Counter Installation Instructions for more than 1” thickness: This page and next page (page 14 & 15) is for the kitchen with over than 1” thickness Countertop... - Page 18 VI.Counter Installation Instructions: Before installing the cooktop: 1. Visually inspect the cooktop for damage. Also make sure all cooktop screws are on tight. 2. Place the cooktop into the countertop cutout. Model and Serial Number Location: The serial plate is located under the cooktop. When ordering parts or making inquiries about your cooktop, be sure to include the model and serial numbers.
- Page 19 VI.Counter Installation Instructions: Connecting to a 3 wire power supply cable electrical system 3. Circuit breaker fuse rating must be above 50 A , and wire should be 2/6 or 3/6 copper. Minimum acceptable size of conductors should be no less than 10AWG,copper only, and no less than167°F .
-
Page 20: Troubleshooting
VII.Troubleshooting Error Codes If the display shows an error code, please refer to this sheet for a potential solution. Cooktop does not work Cooktop does not heat up The cooktop control panel may read liquids Cooktop turns off or objects obstructing the panel, which can while cooking cause the cooktop to shut off. - Page 21 VII.Troubleshooting Error Codes If the display shows an error code,please refer to this sheet for a potential solution. Error Code Possible Cause Solution Electronics fault error appears on the “ ” E See E0,E1,E2,E3,E7,E8,E9,EE message of specific cooking Power display zone.
-
Page 22: Fcc Statement
VIII.FCC STATEMENT: FCC STATEMENT; This device complies with Part 18 of the FCC Rules. NOTE: 1.This equipment has been tested and found to comply with the limits for a Consumer ISM equipment, pursuant to Part 18 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. - Page 23 « bourdonnement » est normal, notamment avec une puissance élevée. Warranty For all details regarding the warranty , pls go visit : WWW.FORNO.CA Garantie Pour plus de details pour la garantie, Veuillez visiter notre site: WWW.FORNO.CA...
