Home EV Wallbox
P1/P2/P3
Loading Balancing
Setup Guide

Advertisement

loading
Need help?

Need help?

Do you have a question about the P1 and is the answer not in the manual?

Questions and answers

Related Manuals for MasterPower P1

Summary of Contents for MasterPower P1

  • Page 1 Home EV Wallbox P1/P2/P3 Loading Balancing Setup Guide...

  • Page 3: How It Works

    Home EV Wallbox - Loading Balancing Setup Guide Introduction The loading balancing has been designed with ease of installation in mind. Its lightning-fast reaction time to overload currents coupled with the fact that EV charging station records the power and energy from the CT-Meter means you will improve on the safety of your installation while gaining insights into the energy usage of the property.
  • Page 4 Home EV Wallbox - Loading Balancing Setup Guide 1 Fuse rating/max incomer load. 2 CT sensor (MF-EV7.2kW-P1 CT Sensor only 1PC, MF-EV11kW-P2 or MF-EV22kW-P3 CT Sensor need 3PS). 3 Home distribution BOX. 4 EV Charging station (MF-EV7.2kW-P1/MF-EV11kW-P2/MF-EV22kW-P3). 5 2*0.5 mm RS485 communication shielded twisted pair.
  • Page 5 Home EV Wallbox - Loading Balancing Setup Guide B. MF-EV11kW-P2/MF-EV22kW-P3 the Meter is ADL400 Serial Number Wiring Mark CT A line black CT A line red CT B line black CT B line red CT C line black CT C line red N Input power line 22AWG 450V/750V 105°C L Input power line 22AWG 450V/750V 105°C RS485 A Shielded twisted pair cable 24AWG...
  • Page 6 Home EV Wallbox - Loading Balancing Setup Guide Your property will have a maximum allowed total power consumption that can be configured inside your EV charging station. Once installed and configured, the charger monitors this consumption in real-time. In the event that charging would cause you to exceed the pre-set limit, we will then reduce the EV charging rate in order to protect your electrical wiring and avoid blowing the fuse in your meter whilst continuing to charge your vehicle.
  • Page 7 Home EV Wallbox - Loading Balancing Setup Guide APP Load Fuse Rating/ CT Installed APP Setting Balancing Enabled Max. Incomer Load 100A 120A 100A 150A 120A...
  • Page 8 Paseo de Extremadura, 39 28935 Móstoles - Madrid (Spain) (+34) 918 021 649 info@masterbattery.es www.masterbattery.es/en...

This manual is also suitable for:

P2P3
