Page 1 StX S1 Cosmic Ray Neutron Detector Technical Reference Manual...
Page 2 Although every effort has been made to ensure the accuracy of this manual, StyX Neutronica shall not be liable for any errors, incidental, or consequential damages in connection with the furnishing, performance, or use of this manual or examples herein. StyX Neutronica...
Page 3: Table Of Contents
........1.2 StX S1 Components .
Page 5: General Setup And Functions
Part 1 General setup and functions 1.1 Safety instructions • Do not modify the electronics of AC-powered devices. Before starting the instrument ensure hardware integrity. • The product is a high voltage device. In operation the amplifier, the cables and connectors to the proportional counter tubes can carry high voltages above 1000 V.
Page 6: Stx S1 Components
C interface for data transmission, - GSM/LTE/NB-IoT data transfer. In the displayed configuration the detector StX S1, PV Panel and environmental sensors are mounted on a single pole. Detector Base Unit The main component of the Cosmic Ray Neutron Detector is the base unit.
Page 7 • onboard environmental sensors for temperature, air pressure and relative humidity, • a temperature-stabilized real time clock, • a status display, • an SD card slot for FAT/FAT32 formatted cards up to 4 GB. • RJ45 (ethernet) connectors for I C for environmental sensors, I C for nCatcher units, differential C for nCatcher units, serial lines for external GPS units,...
Page 8 Figure 1.3: Logger front side with 12 V-in, on/off switch, display switch, SD card slot, display and USB connector. Figure 1.4: Logger back side with SIM card slot, SDI-12 connector, GSM antenna connector, RJ45 connectors for external devices including cosmic-ray detectors and GPS antenna.
Page 9: Operation
2.1.2 Sensor start • Switch on the device by setting the main power switch to the ’On’ position. The status display shows the StyX Neutronica logo. • The logger checks whether there is an SD card inserted. – If yes, it checks the existence of a correct configuration file central.cfg with the correct revision in the root folder and whether the configuration file should be used.
Page 10: Sensor Operation
On the status display the sensor start procedure iterates through the following panels: Step 1 Step 2 Step 3 Step 4 Step 5a Step 5b Step 6b Independently from the logger boot process the nCatcher is initialized with the following steps: •...
Page 11 • the number of cycles for averaging GPS values before storing them to the SD card. • the number of cycles for recording neutron data before saving histograms to the SD card. Due to the low bus speed SDI-12 sensors are not read out every cycle but once every averaging interval. The status display can be switched through several panels Panel 2 Panel 3...
Page 12: Service And Transport
2.1.4 Service and transport The sensor can be transported by means of usual spring-suspended transport devices. For transporta- tion an anti-shock mat is recommended. Dropping down a tube on a hard surface from heights more than 10 cm can lead to damages. 2.2 Software configuration The configuration file central.cfg in the main folder of the SD card contains the following settings 1 // use this config file [bool]...
Page 13 0 // FTP server user name [string] 0 // FTP server password [string] 0 // FTP file path [string] 0 // use ftp file upload [bool] 1 // ftp transmission mode [1=passive, 0=active] iot.1nce.net // PDP context [string] 10.64.81.69 // UDP server address [string] 61556 // UDP server port [int] 26201 // BC95 operator ID [int] 8 // BC95 band number [int]...
Page 14 • threshold: The amplifier features a hardware threshold for setting a lower limit for signal detection. It spans 4096 values. Setting the threshold in the range 1–4095 is a non-permanent adjustment, the range 4096–8192 writes the value to the internal nCatcher EEPROM memory. In that case this value is restored after a bootup or a power loss.
Page 15 12. PM temperature and pressure sensor 21. ATMOS-14 weather station 22. SMT-100 FDR sensors 23. ATMOS-41 weather station and SMT-100 FDR sensors 24. SMT-100 FDR sensors and PM temperature and pressure sensor For detailed information of specific settings please contact StyX Neutronica.
Page 16: Logger Data
2.3 Logger data The logger stores data in four tab-separated ASCII files: • envlog.txt: information about environmental sensors. • gpslog.txt: information from the GPS device. • hvlog.txt: information from the nCatcher unit. • cnt.txt: raw data from the neutron pulses. •...
Page 17: Appendix
Appendix...
Page 18: A Technical Specifications
A Technical specifications Dimensions: • Casing : 146 cm× 18 cm Voltages: • Logger: 12 V (9 V to 24 V) • nCatcher: 6.5 V, -6.5 V, 5 V (via logger) Environmental sensors: • temperature: – absolute precision: 1 K –...
