MS230 - 2
MULTISTRIPPER
Operating Manual
This manual is provided to persons purchasing an
SPE machine and may not be reproduced in part or full
without written permission of
SPE International Ltd.
This manual provides the basic information required
and is only to be used as a guideline.
The SPE machines are manufactured and covered by
SPE design registrations granted and pending.
SPE International Ltd reserves the right to alter the
equipment design and specification as required
without notice.
The SPE product range is subject to amendment and
improvement as a result of on going research
Honeyholes Lane, Dunholme, Lincoln LN2 3SU, England
Tel: +44 (0) 1673 860709 Fax: +44 (0) 1673 861119
Email:
sales@spe-int.com
VERSION 1.03

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MS230 and is the answer not in the manual?

Questions and answers

Summary of Contents for SPE MS230

  • Page 1 MS230 - 2 MULTISTRIPPER Operating Manual This manual is provided to persons purchasing an SPE machine and may not be reproduced in part or full without written permission of SPE International Ltd. This manual provides the basic information required and is only to be used as a guideline.
  • Page 2 This manual covers to the best of our knowledge, the operation and maintenance of the MS230 Multistripper. Before operation of the equipment the manual should be read and understood by the operator. The safety regulations must be followed at all times. Service of electrical components should be carried out by authorised personnel.
  • Page 3 MS230-2 MULTISTRIPPER Operating Manual INDEX Page No Starting Work Electrical Instructions Maintenance Blade Change Blade Angle Basic Maintenance Checklist Safety Spare Parts Breakdown Body Components Operational Parts Electrical Listing Wiring Diagram Specifications Noise/Vibration Assessment Warranty Declaration of Conformity Conditions of Sale...

  • Page 4: Starting Work

    Extension cables must be no less than 2.5 mm (normal length 30 metres) All cables should be fully uncoiled and never left wrapped around cable reels or tied in loops. An RCD unit must be used with the MS230 240v.

  • Page 5: Maintenance

    MS230-2 MULTISTRIPPER Operating Manual MAINTENANCE AFTER USE: - Clean the machine to remove all the build up of dust and surface residue. If using a hose pipe or pressure washer take care that water is not directed onto electrical components and switches.
  • Page 6 3) Keep hands and feet away from the moving blade at all times 4) Keep the electric lead away from the moving blade 5) Never leave the MS230 unattended whilst in use. Always stop the motor before leaving the machine.
  • Page 7 DWG No. ISSUE MS230 3 of 3 NOT TO SCALE SCALE SHEET...
  • Page 8 MS230-1 MULTISRIPPER Operating Manual...
  • Page 9 MS230-2 MULTISTRIPPER Operating Manual Part no Description 25MF@400V Run Capacitor 230v 125MF@240V Start Capacitor 230v SP210-306 230v 16A 3 pin Trailing Plug 7536 1.5mm Cable - Black 5 mtrs...

  • Page 11: Specification Sheet

    MS230-2 MULTISTRIPPER Operating Manual SPECIFICATION SHEET MS230 Electric Type MS230-2 Part number 2.0 h.p Power output 230v Voltage Cycles Machine dimensions (mm) Length Width Height Weight (kg) Working width mm 1400 Engine/Motor rpm ELECTRICAL REQUIREMENTS Machine Volts Plug Cable size...
  • Page 12 MS230-2 MULTISTRIPPER Operating Manual RECORD OF NOISE AND VIBRATION ASSESSMENT Manufacturer: Type: Tile Lifter Model No. MS230-2 Electric Operation : Free running Running Conditions: 1420 rpm HAND-ARM VIBRATION Frequency Weighted Energy Equivalent Accelerations (a Measurement Position Acceleration (m/s Vector axis...

  • Page 13: Warranty

    Conditions of Sale (copy attached). Warranty start date: As despatch date Model: MS230-2 Serial no: Customer name: Customer Address: Manufacturer: SPE International Ltd Honeyholes Lane Dunholme Lincoln LN2 3SU England Telephone: +44 (0) 1673 860709 Fax:...

  • Page 14: Declaration Of Conformity

    Directive 2006/42/EC............Brian Jacklin – Technical Manager SPE INTERNATIONAL LTD SPE International Ltd, Honeyholes Lane, Dunholme, Lincoln. LNS 3SU England Tel: +44 (0) 1673 860709 Fax: +44 (0) 1673 861119 Web: www.spe-int.com...
  • Page 15 MULTISTRIPPER CONDITIONS OF SALE Operating Manual The quotation overleaf and any order placed following such quotation are subject to the following conditions of sale in which SPE International Limited is referred to as the “Company”. Validity of quotation No order received from a customer by the Company shall constitute a contract until accepted in writing by the Company.
