Summary of Contents for Northern Industrial Tools 486781
- Page 1 ALUMINUM MANUAL NOZZLE WITH DIGITAL METER OWNER’S MANUAL WARNING: Read carefully and understand all INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety precautions may result in serious personal injury. Item #486781...
-
Page 2: Technical Specifications
Thank you very much for choosing a NORTHERN TOOL + EQUIPMENT CO., INC. Product! For future reference, please complete the owner’s record below: Model: _______________ Purchase Date: _______________ Save the receipt, warranty and these instructions. It is important that you read the entire manual to become familiar with this product before you begin using it. -
Page 3: Installation
Before Installation: Check if there is numerical value indicated on the meter, Check that the trigger is in proper working order. Check if the inlet could be swiveled. INSTALLATION Generally, the nozzle is installed before shipment. If it is not installed when received, take the following steps: 1. - Page 4 Fig. 6 OPERATION INSTRUCTION a. Before operating Check the technical data and make sure it matches the readout on the meter, i.e.; connection, pressure, flowrate range, medium, etc. Use the following Formula : Proper correction factor =(actual value/ display value) × current correction factor ...
-
Page 5: Maintenance
Fig.8 Fig.9 2. Manual Nozzle 1) Start Switch the trigger on to start pumping. (See Fig. 10) Fig.10 1010 2) Keep Push the lock key, then squeeze the trigger to keep the nozzle flowing. (See Fig. 11) Fig. 11 3) Finish a. - Page 6 In this condition, the meter continues to work correctly, but the flashing icon warns the user that it is advisable to change the battery. Fig. 14 To change the battery, remove the screw on the battery cover and open the battery box. After that, install the battery cover, tighten the screw, fix on the rubber protection to finish the battery change.
- Page 7 DIAGRAM AND PARTS LIST Description Qty. Spout Digital Meter 3/4" Connector Nozzle 7 of 9...
- Page 8 Digital Meter Description Qty. Rubber Protection Protection Board For LCD Display Battery Batter Cover Self Tapping Screw Spring Slice For Battery Self - Tapping Screw Self - Tapping Screw Shaft Oval Gear O - Ring Bottom Plate Self - Tapping Screw Magnet Meter Body Fix Board...
- Page 9 WARRANTY One-year limited warranty Northern Tool + Equipment Company, Inc. Burnsville, Minnesota 55306-6936 Made in China 9 of 9...
