Zafferano LD0340C3 Manual

poldina
Rechargeable table lamp
LD0340B3 white
LD0340N3 dark grey
LD0340R3 corten
LD0340A3 blue
LD0340G3 sage green
LD0340P3 pink
LD0340M3 dark green
LD0340S3 sand
LD0340F3 red
LD0340X3 bordeaux
*LD0340C3 chrome
*LD0340O3 gold
*LD0340BFA silver color leaf
*LD0340BFO gold color leaf
*LD0340RFR copper color leaf
*Not suitable for outdoor use.
1. Tips for use:
This product is exclusively for lighting purposes and:
A) It must not be exposed to heavy mechanical loads or contamination; B) It can be installed and used only after checking the state of the pro-
duct; check that is not dirty and has not been damaged during storage; C) Installation and maintenance must be carried out when the appliance
is switched off; D) Any alterations to the product, any tampering and any failure to comply with the instructions provided may make the appliance
hazardous; E) When fully assembled, the lamp (head+structure, without the recharging base), reaches an IP65 rating, making it ideal
for outdoor use. The light fixture (top) alone and the assembled lamp placed on the recharging base has an IP20 rating, making it unsuitable for
outdoor use; F) All metal and plastic surfaces should be cleaned with a soft dry cloth; G) The company Zafferano shall not be held liable for any
damage caused due to its products being assembled in any manner that does not comply with the instructions provided.
2. Technical data of the lamp:
- Power: 2,2 W
- Volt: DC 5 V
- Color temperature: 2200 - 2700 - 3000 K
- Lumen LED: 234-251-256 lm
- Lithium battery pack included (see section accessories included); for instructions about how to replace the battery pack, please consult the
website: www.zafferanoitalia.com. Use only original batteries for replacement.
- Charge: 6/7 h
- Battery life: 12 h
- Class: III
- Protection rating: IP65
- CRI>80
3. Battery charger technical data:
- Contact charging base: INPUT/OUTPUT 5Vdc - 1A; cavo USB 1.2 Mt.
- Charger: INPUT AC100-240V 50/60Hz; OUTPUT 5Vdc- 1A.
- The lamp works correctly even when connected to the charging base.
- It is advisable to use the original charger and charging base. Alternatively, you can use a certified 1A max. charger.
4. Important:
- The versions with a metal leaf finish are handmade and protected by a clear varnish. We recommend cleaning using only a soft, dry cloth. The use of
aggressive cleaning agents or abrasive cloths, and any accidental knocks, may damage the delicate leaf finish.
- The support surface for the lamp must not exceed a 15° tilt or it will fall.
- The battery has an overload protection function.
- To preserve the integrity of the battery, we recommend keeping the charge between minimum 20% and maximum 80%; if the lamp is not used for
long periods, it is advisable to regularly charge/discharge the product.
- Please refer to local laws for the proper disposal and recycling of the battery.
DESIGNED BY ZAFFERANO SRL IN ITALY, MADE IN PRC • Zafferano srl, Viale dell'Industria, 26 - 31055 Quinto di Treviso - TV - Italia • For more information
and updates visit our website • www.zafferanoitalia.com
3
LED DIMMER
2,2W LED • 234-251-256lm • 2200-
2700-3000K • IP65
50-60H • CRI>80 • 5Vdc max 1A
Ø 11 x h 38 cm / Ø 4,3 x h 14,9 in
INCLUDED
Single-contact
charging station
This product contains a class F light source
• 100-240V
NOT INCLUDED
LD0350RP
Multi-contact
charging base (max. 6 pc)
LD0340RA
Multi-socket USB
charger (8xUSB)
BAT04703706701900
Replacement battery pack
KIT00009006800203
Replacement LED board
