SOLAR COLOUR PRO

TPMS - USER MANUAL

–

KIT INCLUDES EXTERNAL SENSORS

4x PRE-REGISTERED TCSO

www.tyrepal.co.uk

505-802-101-0 SOLAR COLOUR PRO MANUAL

VEHICLE USE:

CARS, CLASSIC CARS,

VANS

MOTORHOMES,

CAMPERVANS

TWIN-AXLE CARAVANS

TWIN-AXLE TRAILERS

HORSEBOXES

PAGE 1

Table of Contents

Need help?

Do you have a question about the SOLAR COLOUR PRO and is the answer not in the manual?

Questions and answers

Summary of Contents for Tyrepal SOLAR COLOUR PRO

Page 1 PAGE 1 505-802-101-0 SOLAR COLOUR PRO MANUAL SOLAR COLOUR PRO TPMS - USER MANUAL – KIT INCLUDES EXTERNAL SENSORS 4x PRE-REGISTERED TCSO VEHICLE USE: CARS, CLASSIC CARS, VANS MOTORHOMES, CAMPERVANS TWIN-AXLE CARAVANS TWIN-AXLE TRAILERS HORSEBOXES www.tyrepal.co.uk...
Page 2 PAGE 2 505-802-101-0 SOLAR COLOUR PRO MANUAL MAX= +80°C; MIN= -20°C MAX= 99psi / 6.8Bar MAX= 120mph MONITORS LEFT UNDER WINDSCREENS CAN EXPERIENCE EXTREME HEAT – THIS CAN DAMAGE THE DEVICE DO NOT USE WITH TYRE SEALANT ENSURE SENSOR DOES NOT...
Page 3 PAGE 3 505-802-101-0 SOLAR COLOUR PRO MANUAL NOTE: FOR DISTANCES GREATER THAN 7.0M OUR TCRR-2 SMART SIGNAL REPEATER IS REQUIRED 7.0M max 10 min 10 min SENSORS GO TO SLEEP AFTER 10 MINUTES VEHICLE MOVEMENT. MONITOR GOES TO SLEEP AFTER...
Page 4 PAGE 4 505-802-101-0 SOLAR COLOUR PRO MANUAL READ INSTRUCTIONS BEFORE INSTALLING THIS KIT DOES NOT REPLACE THE NEED TO CARRY OUT REGULAR CHECKS ON THE CONDITION AND WEAR OF THE TYRES MONITOR SHOULD BE INSIDE VEHICLE WHERE IT DOES NOT INTERFERE WITH DRIVING...
