Summary of Contents for Protool SAW40
- Page 1 42582 SAW40 40" / 1000 LB CAPACITY LIGHTWEIGHT ALUMINUM FIXED LEG SAWHORSE PRODUCT MANUAL SCAN TO WATCH PRODUCT ASSEMBLY VIDEO CAUTION: To reduce the risk of injury, user must read and understand this product manual. Save these instructions for future reference.
-
Page 3: Table Of Contents
TABLE OF CONTENTS Features and Specifcations ........................3 Preparing the Sawhorse..........................4-5 Mounting Workpiece or Sacrifcial Wood ....................6 Constructing a Jobsite Table ........................7 Storing the Sawhorse..........................8-9 Safety and Warnings........................... 10 General Maintenance..........................10 Warranty ................................11 WARNING: Be sure to read and understand all safety instructions in this manual, including all safety alert symbols such as “DANGER”, “WARNING”, “CAUTION”, and “IMPORTANT”... -
Page 4: Preparing The Sawhorse
PREPARING THE SAWHORSE PUSH TO SLIDE Place sawhorse on a flat and level surface with folded legs facing up. Push to slide leg lock and unfold first set of legs from chassis. Deploy first set of legs. Make sure cross brace is secured in place to ensure legs are fully opened. - Page 5 PREPARING THE SAWHORSE After both sets of legs are deployed, lift sawhorse in an upright position. Ensure sawhorse is stable and both sets of legs are fully opened. FIND OUT MORE AT PROTOCOLEQUIPMENT.COM...
-
Page 6: Mounting Workpiece Or Sacrifcial Wood
MOUNTING WORKPIECE OR SACRIFICIAL WOOD Place workpiece or 2" X 4" lumber on top of chassis. Rubber straps are located on both ends of sawhorse. Pull each strap over material and secure strap to knob. PRE-DRILLED MOUNTING HOLES NOTE: Pre-drilled mounting holes on saddle trays can also be used to attach sacrifcial wood. FIND OUT MORE AT PROTOCOLEQUIPMENT.COM... -
Page 7: Constructing A Jobsite Table
CONSTRUCTING A JOBSITE TABLE Materials Required: (2) SAW40, (4) 2" X 4" Lumber, (1) Plywood sheet Place 2" X 4" lumber on top of each chassis. Rubber straps are located on both ends of sawhorses. Pull each strap over material and secure strap to knob. -
Page 8: Storing The Sawhorse
STORING THE SAWHORSE Carefully flip sawhorse over so that legs are facing up. FIRST SET OF LEGS NEST INTO CHASSIS FRAME, OPPOSITE SIDE OF LEG LOCK LEG LOCK Set of legs opposite from leg lock must be folded into chassis first. Press on cross brace to bring legs together. - Page 9 STORING THE SAWHORSE Slide leg lock to secure legs in place for transport and storage. FIND OUT MORE AT PROTOCOLEQUIPMENT.COM...
-
Page 10: Safety And Warnings
SAFETY AND WARNINGS SAFETY INSTRUCTIONS FOR SAWHORSES Use caution when folding or unfolding legs to limit any finger pinch points. Place sawhorse on flat and level surface to keep from rocking or tipping. Do not exceed the rated capacity on main frame table/chassis. Ensure load is equally distributed. -
Page 11: Warranty
WARRANTY 3-YEAR LIMITED WARRANTY This product is backed by a 3-year limited warranty. This warranty covers manufacturer defects and workmanship. The warranty excludes misuse or abuse and normal wear and tear. This warranty gives you specifc legal rights, and you may have other rights, which vary from state to state. - Page 12 02.27.2023 JS PRODUCTS • 6445 MONTESSOURI STREET • LAS VEGAS, NV 89113 CUSTOMER SERVICE: 1-877-707-6449 • PROTOCOLEQUIPMENT.COM...
