CLIMMA CWS

Installation, usage and

maintenance manual

DC INVERTER

Rev. 190124

Table of Contents

Need help?

Do you have a question about the CWS and is the answer not in the manual?

Questions and answers

Summary of Contents for Climma CWS

Page 1 CLIMMA CWS Installation, usage and maintenance manual DC INVERTER Rev. 190124...
Page 2: Table Of Contents
Unpacking ........................................... 4 1.6. Directives ..........................................4 1.7. General safety ........................................4 Installation ............................................5 2.1. Climma DC chiller positioning ..................................5 2.2. Electronic control box and display ................................5 2.3. Flow switch installation ....................................5 2.4. Grounding ........................................... 5 2.5.
Page 3: Introduction
Climma chiller and products are designed and produced to the highest standards and they are all tested in the factory. If your Climma system is used according to the guidelines in this manual, it will guarantee you trouble free operation for many years.
Page 4: Transport And Handling
The unit must be installed by an authorized Climma service center and in compliance with the instructions given in this manual. 1.4. Transport and handling When loading or unloading the unit, use a fork lift equipped with forks at least 2/3 the length of the shipping base.
Page 5: Installation
The unit must be secured on a surface using the mounting brackets below the drain pan. WARNINGS The Climma DC chiller is provided with an inverter mounted on the unit (VDF - Variable Frequency Drive). The inverter is IP20, therefore the Climma DC chiller must be installed where it would not get wet.
Page 6: Chiller Condensate
2.6. Other system components: fancoils Climma fancoils have to be installed in a technical space inside or close to the cabin they have to cool/heat. Fancoils need to be properly secured on a leveled surface in order to operate correctly and remove the condensation.
Page 7: Other System Components: Fresh Water Circuit
Water pressure in the circuit must be between 1 and 1.5 Bar (14.5 and 22 psig). FRESH WATER PUMP (CIRCULATION PUMP) The fresh water pump must be installed near the Climma DC chiller. The pump has to be installed on the return line of the fresh water circuit, pumping water directly in the chiller and then to the fancoils.
Page 8: Electrical Connections
EXPANSION TANK The expansion tank allows the water in the system to expand as it gets hot when the chiller is in heat mode and it also acts as a cushion. The expansion tank has to be installed in the fresh water pump inlet. AIRBLEEDER ...
Page 9: Operating Instructions
Modbus protocol. In this chapter only the main electrical box control and remote mechanical panel are shown. 3.1. The electrical control box The electrical control box of the chiller Climma DC can be external, as in the DC35, DC50 and DC65, or internal, as in the DC130. Example of external electrical box. ...
Page 10: Climma Functions
3.4. Climma functions When the unit is working, the system can run with two different functions: AUTO function: when system is in AUTO function, the Climma Control will automatically adjust the  system power: when more power is requested, the compressor will run up to its maximum speed, but when less power is requested, compressor will slow down.
Page 11: Shut Off Procedure
Main screen. The main screen will show the current state of the system (Status: ON, OFF), the operation mode (Summer, Winter) and the function active (Auto, Eco). To turn on the system, press the DOWN/UP button to position the cursor on the ON/OFF symbol, then press ENTER to change the Status and turn the system ON.
Page 12: User Menu
3.7.1. User Menu The main User Menu has a set of different screens, where you can check the system values, and change some of them. To move between screens, use DOWN/UP buttons. To go back to the main screen, press ESC. SC01 screen shows system Status, Mode and Function.
Page 13: Input/Output
SC06 shows the list of compressors available and for each compressor the high pressure value (discharge pressure) and low pressure value (suction pressure). This is a read only screen, no value can be changed. SC07 shows the list of compressors available and for each compressor the sea water flow value (in liters/minutes).
Page 14: Language & Infos
(the value will blink), then use the arrows UP/DOWN to modify the value. To confirm the value press ENTER again. I03 screen shows the software and Bios version of your Climma DC system. While contacting a service center, please make sure to identify the software version through this screen.
Page 15: Mechanical Remote Control (Optional)
3.10. Secondary digital display (optional) Climma DC chillers allows you to add a secondary digital display to the system. If the second display is there, both displays will show you exactly the same thing at the same time. Veco S...
Page 16: Maintenance And Cleaning
4. Maintenance and cleaning Climma DC chillers require some basic maintenance that has to be done frequently and some extended maintenance to be done at longer intervals. 4.1. Basic maintenance Following tasks need to be performed frequently. Clean the seawater strainer to allow enough sea water to the condenser coil ...
Page 17: Warnings, Alarms And Troubleshooting
1 minute, then try to restart the AL19 Probe S1,S2,S3,S4 Alarms compressor 3 Manual 60sec OFF compressor system. If the error does not go away, contact the closest Climma AL20 Probe S1,S2,S3,S4 Alarms compressor 4 Manual 60sec OFF compressor service center.
Page 18 AL95 Power+ offline compressor 3 Automatic 30 sec Turn OFF If the error does not go away, contact the closest Climma service center. AL96 Power+ offline compressor 4 Automatic 30 sec Turn OFF...
Page 19 The DC voltage between the inverter and the compressor has exceeded the allowed limits. There may be a voltage surges in the power supply, therefore check the 3: Overvoltage power supply. Shut off the system, wait 1 minute, then try to restart the system and reset the alarm. If the error does not go away, contact the closest Climma service center.
Page 20: Basic Troubleshooting
PFC circuit overcurrent; there may be a problem in the power supply or maybe other circuit errors, so check also for other errors, then shut off the system, wait 1 20: PFC Failure minute, then try to restart the system and reset the alarm. If the error does not go away, contact the closest Climma service center. 21: Error code 21 AC input voltage too high, Check line voltage and the presence of inductive loads on the line that may generate overvoltage.
