Summary of Contents for ALTURAS MOUNTS AM300
- Page 1 AM300 Above Fireplace Pull-Down Full-Motion TV Wall Mount Installation Guide WEIGHT: Max:800X600/32X24” 30~80 lbs Min:300X200/12X6” 13.6~36.2kg...
- Page 2 © 2022. All Right Reserved.
- Page 3 3/16” 3/8” 10mm 1½” © 2022. All Right Reserved.
- Page 4 © 2022. All Right Reserved.
- Page 5 If the main wall is wood, the wall covering must not exceed 5/8 inches thick. There must be at least 2 studs available for mounting. If the main wall is concrete or brick wall, please refer to the S4 installation points. TV weight must be between 30~80lbs(13.6~36.2kg).
- Page 6 Please reference point 5 on page 5 to ensure that the four mounting holes are the correct distance above the mantel surface. Reference point 5 on page 5 © 2022. All Right Reserved.
- Page 7 Please reference point 5 on page 5 to ensure the four mounting holes are the correct distance above the mantel surface. If the main wall is concrete or solid brick wall, you can use the expansion pipe we provided (Part M). For heavier weights above 60lbs, we recommend use of metal sleeve anchors.
- Page 8 Take out N/J from the packaging, lock the four allen pan head screws(M8x10) with Hexagon wrench in N, then use cable ties in N to tie up the wires as is shown in the pictures below. Leave appropriate amount of cable slack to allow full motion of the lifting arm. ©...
- Page 9 © 2022. All Right Reserved.
- Page 10 © 2022. All Right Reserved.
- Page 11 Lift the TV through hooks for hanging onto the Take out GG from the packaging, bracket panel, then press the safety locks on the and press them onto the wallboard. hooks and x it with the screws (H). © 2022. All Right Reserved.
- Page 12 WARNING: Do not try to force the tension adjustment beyond the minimum setting. This will damage the mount. © 2022. All Right Reserved.
- Page 13 © 2022. All Right Reserved.
- Page 14 © 2022. All Right Reserved.
- Page 15 25° © 2022. All Right Reserved.
- Page 16 WARNING: This product can expose you to chemicals including Lithium Grease, which is known to the State of California to cause cancer or developmental harm. For more information go to www.P65Warnings.ca.gov. AM300 09.09.22 © 2022. All Right Reserved.
