Soundbar Bracket
INSTALLATION INSTRUCTION
HCMS5745
Universal
fit
Thank you for choosing HCMOUNTING! This product comes with 10 years warranty.
For any questions during installation and use, please contact us first. We are 7*24
hours available to ensure that your problems will be 100% well-solved.
Email: hcmounting@outlook.com
Rev.2
Advertisement
Table of Contents
Summary of Contents for HCMOUNTING HCMS5745
- Page 1 HCMS5745 Universal fit Thank you for choosing HCMOUNTING! This product comes with 10 years warranty. For any questions during installation and use, please contact us first. We are 7*24 hours available to ensure that your problems will be 100% well-solved.
- Page 2 HCMOUNTING is not liable for any damage or injury caused by improper installation, incorrect assembly, or misuse. Do not use this product to any other purpose not indicated by HCMOUNTING. 2. WARNING This product contains small hardware that could be a choking hazard if swallowed.
- Page 3 STEP 1. Attach brackets and soundbar 1-1 Main components and hardwares Main components Bracket x 2 "L" Bracket x 2 Matting x 2 Installation hardwares M4X15mm M5X15mm M6X15mm M6X30mm M4/M5/M6 Washer M6 Blocking nut 1-2 Select Soundbar installation mode 1. For installation with wide hole 2.
- Page 4 1-3 Install Soundbar Select the right Screws/Washers/Spacers to install 1-4 Select the appropriate installation mode according to the holes on the Soundbar 1. The screw holes on the back of the soundbar 2. The wall-mounted holes on the back of the soundbar Tips: The dimension of L in the figure is equivalent to the pitch of two holes on the soundbar.
- Page 5 STEP 2. Mount the soundbar bracket ono the TV Hardware Listing M4X15mm M4X30mm M6X15mm M6X30mm M8X25mm M8X45mm M4/M6 Washer 10mmSpacer Ring 5mmSpacer Ring ( 18x8.5x5.0)X4 ( 18x8.5x10.0)X4 Warm Tips: Only one screw is needed to complete the installation of the soundbar and TV.
- Page 6 For soundbar bracket directly attach to TV back, follow STEP 2A For soundbar bracket attach to TV mount, follow STEP 2B STEP 2A For soundbar bracket directly attach to TV back Installation effect 1. There is no countersunk screw hole on the back of the TV. 2.
- Page 7 STEP 2B For soundbar bracket attach to TV mount 2B-1 Removing the TV from the TV mount Ⅰ Ⅱ Ⅲ Pack up all cables Take off the TV from Remove the TV the mount brackets from the TV 2B-2 Assemble the soundbar bracket and TV bracket together, as below:...
