- Page 1 COLOUR ELECT TELEVISION Owner’s Instructions Before operating the unit, please read this manual thoroughly, and retain it for future reference. REMOTE CONTROL ON-SCREEN MENUS ENJOY GAME...
-
Page 2: Safety Instructions
RESULT IN FIRE OR SHOCK HAZARD. DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. The main voltage is indicated on the rear of the TV set and the frequency is 50 or 60Hz. Do NOT expose the television to direct sunlight. -
Page 3: Table Of Contents
PREPARING YOUR TELEVISION Safety Instructions ... Caution ... Front Control Panel ... Connection Panels ... Infrared Remote Control ... Inserting the Batteries in the Remote Control... Connecting the Aerial (or Cable Television Network)... Switching Your Television On and Off... Placing Your Television in Standby mode ... Plug &... -
Page 4: Front Control Panel
Front Control Panel (depending on the model) Buttons and markings are subject to change. TV/VIDEO STAND-BY/TIMER SELECTION INDICATOR VOLUME ADJUSTMENT POWER MENU DISPLAY CHANNEL SELECTION REMOTE CONTROL SENSOR STAND-BY/TIMER MENU DISPLAY CHANNEL SELECTION INDICATOR VOLUME ADJUSTMENT REMOTE CONTROL SENSOR POWER... -
Page 5: Connection Panels
Connection Panels This figure shows the Standard Connector-jack panel. The actural configuration on your TV may be different, depending on the model. Side of TV RCA AUDIO/VIDEO INPUT CONNECTORS HEADPHONE JACK (OPTION) RCA AUDIO/VIDEO INPUT/OUTPUT CONNECTORS S-VIDEO CONNECTOR HEADPHONE JACK... -
Page 7: Inserting The Batteries In The Remote Control
An outdoor aerial A cable television network Plug the aerial or cable network input cable to the 75 on the rear of the television. coaxial socket Rear of TV Cable Television Network... -
Page 8: Switching Your Television On And Off
The mains lead is attached to the rear of the television. Plug the mains lead into an appropriate socket. The main voltage is indicated on the rear of the TV set and the frequency is 50 or 60Hz. Press the “... -
Page 9: Placing Your Television In Standby Mode
Placing Your Television in Standby mode Your television can be placed in Standby mode, in order to reduce: Power consumption Wear of the cathode ray tube The Standby mode can be useful when you wish to interrupt viewing temporarily (during a meal, for example). The television is placed automatically in Standby mode when you turn it on. -
Page 10: Plug & Play Feature
Input : Check” is displayed. If any language is not selected on the “Language” menu, the “Language” menu will be displayed about 30 seconds later. Exit Make sure that the antenna is connected to the TV. And then press – button. Result: The “Auto store”... -
Page 11: Viewing The Demonstration
Viewing the Demonstration To become familiar with the various menus provided by your television, you can view the inbuilt demonstration. Press the MENU button. Press the button to select the “Function” and press the – button. Press the button to select the “Demonstration” and press –... -
Page 12: Choosing Your Language
Press the Press the Exit Select a particular language by pressing the repeatedly. When you have finished, press the TV button or, press the MENU button repeatedly to return to normal viewing. Exit Exit button to select the “Function”. –... -
Page 13: Storing The Channels Automatically
Storing the Channels Automatically You can scan the frequency ranges available on your television and in your area and store all the channels found automatically. The channels are stored in the order in which they appear in the frequency bands. It is possible that the automatically allocated numbers may not correspond to those by which you wish to identify the channels. -
Page 14: Storing The Channels Manually
Storing the Channels Manually Channel Auto store Manual store Add/Erase Fine tune Sort Child lock Select Enter Channel Auto store Manual store Add/Erase Fine tune Sort Child lock Select Enter Manual store Color system : Auto Sound system : BG Search : 138MHz Channel... - Page 15 Result: “OK” is displayed. Repeat Steps for each channel to be stored. When you have finished manual storage, press the TV button or, press the MENU button repeatedly to return to normal viewing (continued...) button to select the “Channel”. –...
-
Page 16: Skipping Unwanted Channels
Press the Exit To add or erase the desired channel by pressing the When you have finished adding and erasing channels, press the TV button or, press the MENU button repeatedly to return to normal viewing Exit Exit button to select the “Channel” and press the button to select the “Add/Erase”... -
Page 17: Fine Tuning Channel Reception
When you have finished, press the TV button or, press the MENU button repeatedly to return to normal viewing. – button. Result: The horizontal bar’s cursor moves to the left or right. -
Page 18: Sorting The Stored Channels
To... Confirm the exchange of channel numbers Exit When you have finished sorting channels, press the TV button or, press the MENU button repeatedly to return to normal viewing Exit button to select the “Channel” and press the button to select the “Sort” and press the –... -
Page 19: Changing Channels
Changing Channels Once you have stored the channels on your television, you can switch easily from one channel to another using the remote control. To switch... Press... To the next channel To the previous channel To another channel The numeric button(s) corresponding to that channel. -
Page 20: Changing The Picture Standard
Press the choices: Custom, Standard, Sports, Natural, Mild. These picture standards are saved for each channel. When you are satisfied with the settings, press the TV button or, press the MENU button repeatedly to return to normal viewing. Exit You can use your remote control to select the type of picture which best corresponds to your viewing requirements. -
Page 21: Adjusting The Picture Settings
Sharpness Color Tint (NTSC only) When you are satisfied with the settings, press the TV button or, press the MENU button repeatedly to return to normal viewing. The television has an “automatic degaussing” system that is activated if magnetic interference is present. To degauss the television screen, switch power off by pressing the “... -
Page 22: Activation/Deactivation The Digital Noise Reduction Feature
Exit Press the Press the To select the “On” press the When you have finished, press the TV button or, press the MENU button repeatedly to return to normal viewing. Exit Press the button to increase the volume (cursor moves to the right) -
Page 23: Switching The Sound Off Temporarily
Custom, Standard, Music, Movie, Speech. These sound standards can be saved for each channel When you are satisfied with the settings, press the TV button or, press the MENU button repeatedly to return to normal viewing. You can use your remote control to select the type of special sound effect to be used when watching a given broadcast. -
Page 24: Adjusting The Sound Settings
The “Adjust” (or “Equalizer”) menu is displayed. Select the required option and adjust to satisfy your preference. Exit When you are satisfied with the settings, press the TV button or, press the MENU button repeatedly to return to normal viewing. Exit... -
Page 25: Extra Sound Settings
“Sound” and press the button. To... Change an option Select the required option (On/Off) When you are satisfied with the settings, press the TV button or, press the MENU button repeatedly to return to normal viewing. (depending on the model) – Press the... -
Page 26: Enjoying The Woofer Sound
(if not mounted, the volume is much lower). Remove the packing materials between the woofer speaker and TV. Attach the woofer speaker ribs in the holes on the top of the TV. Connect the woofer speaker jacks to the TV rear panel inputs and follow the below. -
Page 27: Selecting The Sound Mode
Selecting the Sound Mode The “S.MODE I-II” button displays/controls the processing and output of the audio signal. When power is switched ON, the mode is automatically preset to either “Dual-I” or “Stereo”, depending on the current transmission. Type of broadcast Regular broadcast (Standard audio) Regular +... -
Page 28: Setting The Sleep Timer
To cancel the sleep timer function,repeat steps 1 to 3. Press the W hen you have finished setting the sleep Timer press the Exit TV button or, press the "MENU" button repeatedly to return to normal viewing. Exit button to select the "Function " and press the button to select the "Time"... -
Page 29: Setting And Displaying The Current Time
"Clock". To... Move to the hour or minute Set the hour or minute When you have finished, press the TV button or, press the button repeatedly to return to normal viewing. To display the... Channel information Current time To remove the display, press the DISPLAY button again. -
Page 30: Setting The On/Off Timers, On Time Program And Volume
Setting the On/Off Timers, On Time Program and Volume Time Sleep : Off Clock : 11 : 35 am Timer REMINDER Select Enter 11:35am Time Timer : on On time : -- : -- am Off Time : -- : -- am Prog. - Page 31 Set the Volume at which you wish the television to be switched on by using the button. When you have finished setting the On/Off time, Prog. No and Volume, press the TV button or, press the MENU button repeatedly to return to normal viewing. 11:35am Time...
-
Page 32: Setting The Reminder
Setting the Reminder Time Sleep : Off Clock : 11 : 35 am Timer REMINDER Select Enter 11:35am REMINDER REMINDER : on MESSAGE DISP TIME : -- : -- am Select Adjust 11:35am REMINDER REMINDER : on MESSAGE DISP TIME : -- : -- am Select Enter... - Page 33 Adjust the hour or minute W hen you have finished setting the message and display time, press the TV button or press the MENU button repeatedly to return to normal viewing. It is recommended that you set the message before setting the display time.
-
Page 34: Setting The Blue Screen Mode
Exit Press the Press the When you have finished, press the TV button or, press the MENU button repeatedly to return to normal viewing. You can restrict viewing by locking the channels of your choice. Example: You can prevent your children from watching unsuitable programmes. -
Page 35: Enjoying Games
Enjoying Games You can enjoy the game (Chicken Farm), programmed in this TV. Press the GAME button to enter the Game mode. Result: The READY window will be displayed. Press the button to run the game. Move the farmer to catch eggs by using the time the scores go up, the speed of game becomes faster bit by bit. -
Page 36: Connecting To The Av-1 Or 2 Input/Outputs
The S-VIDEO/RCA (AUDIO-L and R) connectors are used for equipment with an S-Video output, such as a camcorder or VCR. Rear of TV These figures show typical connector-jack panels. The actual configuration on your TV may be different, depending on your model. AV cable (MONO) -
Page 37: Connecting To The Rear Dvd Input
Connecting to the Rear DVD Input The DVD/RCA (AUDIO-L and R) connectors are used for equipment with a DVD output. Rear of TV (MONO) VIDEO L-AUDIO-R MONITOR -OUT INPUT 2 INPUT 1 Connecting to the RCA Input The RCA (VIDEO + AUDIO-L and R) connectors are used for equipment such as camcorders, video disc players and some video game devices. -
Page 38: Connecting Headphones
Switch the television on and if necessary, press the VIDEO button one or more times until the required input is displayed. Depending on the source selected, the pictures may appear automatically. To watch television programmes again, press the TV button and select the number of the channel required. -
Page 39: Automatic Degaussing To Remove Colour Patches
Troubleshooting: Before Contacting Service Personnel Before contacting Samsung after-sales service, perform the following simple checks. If you cannot solve the problem using the instructions below, note the model and serial number of the television and contact your local dealer. - Page 40 - AFTER SALES SERVICE - Do not hesitate to contact your retailer or service agent if a change in the performance of your product indicates that a faulty condition may be present. ELECTRONICS AA68-02793A (ENG)
