ISY IBH 2100-BK, IBH 2100-WT, IBH 2100-TI - Bluetooth Headset Manual

Get connected

1. Fully charge your bluetooth headphone via the provided USB cable.
2. Switch "On" the power button of the headphone, the headphone will turn on and the red and blue LEDS quickly blink alternately, this indicates that the headset is in Bluetooth pairing mode.

3. Enable Bluetooth on your smartphone or tablet.

4. Search the headphone from your smartphone or tablet's Bluetooth device list and connect to IBH 2100-BK/IBH 2100-WT/IBH 2100-TI,
   When the headphone is connected, the blue LED is on. The unit will automatically re-connect again after the first time connection.
5. Now short press the play button, the song will start to play. Press the play button again, the song will pause. When there is an incoming call, press the play button again and you can answer the call. Press again to disconnect the phone call.

Function of buttons:

6. 6. Line In - Plug in your 3.5mm cable from your audio device to the. line-in socket. You can play the songs via headphone.
   7. Micro USB charge port
   8. LED – Bluetooth connection status/LED – charge status

When the headphone is switched on or playing songs, and the red LED is flashing, a double beep sound is heard alert and song is not playing stable, indicates the unit is almost out of battery. Plug the USB cable from a computer/adapter output to the micro-USB port of the headphone.
The red LED is on and the charging occurs. When the red LED is off(in about 1 hour), this means the headphone is fully charged.

Specifications

Input: DC 5V 200mA
Impedance: 32Ω
Profile supported: A2DP and AVRCP
Working distance: Up to10m
Battery: 3.7V 400mAh Li-Polymer Battery
Bluetooth Version: Bluetooth 4.1
Size: W86 X H46mm
Standby time: up to 300Hour
Play time: 8hours(MAX.)

Bluetooth (4.1) Stereo Headset.
Adjustable headstrap,
Frequency range: 20-20,000 Hz,
Play time: 8 Hours (MAX.)*, Impedance: 32 Ω,
Standby time: up to 300 Hour, 400mAh rechargeable battery,
Input: DC 5V,
Included 30 cm micro USB cable for charging,
Audio cable included, works with cable if battery is empty.

Hereby we declare that the product is in conformity with the following European standards:
-R&TTE Directive 1999/5/EG
-RoHS Directive 2011/65/EU
Complete declarations of conformity can be found at:
www.imtron.eu

Intended use

This product is only intended for streaming music from Bluetooth-enabled devices such as cell phones, PDAs, MP3 players, PCs and laptops. Playing music wireless and portable and is designed for both indoor and out door use. This product is sealed.
Do not use it if damage is seen. Imtron GmbH accepts no liability whatsoever for any injuries or damages caused due to careless, improper or incorrect use of the product or use of the product for purposes not recommended by the manufacturer.

Conformity notice

Operation of the device (the devices) may be affected by strong static, electrical or highfrequency fields (radio installations, mobile telephones, microwaves, electrostatic discharges).If this occurs, try increasing the distance from the devices causing the interference.

Battery safety

This product is fitted with a Li-Polymer battery. Do not damage, open or dismantle the battery and do not use it in damp and/or corrosive conditions. Only use compatible chargers. Never dispose of batteries in a fire and never expose them to high temperatures. Do not expose the product to temperatures exceeding 60°C (140°F).

Disposal

The crossed-out wheelie-bin symbol means that you may not dispose of this product together with general household waste; instead, take it to a recycling point for electrical and electronic equipment. Forinformation about local recycling points, contact your local authority, civic amenity site or the business where you purchased this product. The separate collection and recycling of used items of electrical and electronic equipment prevents any harmful substances they contain from harming human health and polluting the environment.

Please keep this information for later reference.

Includes

Bluetooth Stereo Headphone
USB-Micro USB charging cable (30cm)
3.5mm Audio cable (120cm)
User manual

Warnings

Recommended speaking distance for hands free calling: approx. 50cm
Do not expose the headphone to a heat source or hot environment.
Do not short-circuit the headphone. Do not submerge or expose the headphone to fluids.
Do not pierce, break, twist, bend, throw, hit or apply any pressure to the headphone.
Do not disassemble or alter the outside cover or the headphone.
