Polestar 10800001P Instructions

Wireless Remote Control Instructions
ITEM #10800001P
Polestar wireless remote works lets you operate your winch from up to 75 ft. without cables or switches. Just
press the remote transmitter and you're ready to operate your winch Start, stop, in or out.
Remote range up to 75 ft.
◆
Transmitter equipped with long life.
◆
◆ Battery and power saver circuit.
◆ Transmitter & receiver.
◆ Visual indicator light shows remote operation.
◆ Additional transmitters available to operate receiver.
Installs in minutes.
◆
Transmitter replacement battery readily available.
◆
WARNING: The Wireless Remote is designed for use on front mount self-recovery winches only. The remote is
not designed for and should not be used on winches or hoists in industrial applications (commercial car
haulers/carriers, wreckers, cranes, etc.) or for any other remote controlled applications.
Part List:
one transmitter.
1.
one receiver with connector.
2.
Installation and operating instructions:
solenoid control box
female connector
Transmitter Receiver
We suggest operate your winch as follows:
Disengage the clutch of your winch.
1.
Pull out the winch wire rope about 1.5 meters.
2.
Reengage the clutch of your winch.
3.
Insert the plug of the receiver into the winches control box female connector
4.
Put your receiver at a certain place.
5.
Keep the antenna of receiver out and straight.
6.
Pull out the antenna of transmitter, and move down the cover of your transmitter, bare out the
7.
control button.
Press the button, you can operate your winch start, stop, in and out.
8.
Trouble Solving:
SYMPTOM POSSIBLE CAUSE
Motor turns,
but Winch Defective winch.
does not work,
Motor does not turn, Receiver Loose connections to the
but you can hear winch.
"Click" sound in the
Defective winch.
receiver
Receiver Loose connections to the
Motor runs in one
winch.
direction only
Defective winch.
Receiver and transmitter does not
No actions
matching.
SUGGESTED ACTION
Check the winch Operating instructions.
Reinsert the wire.
Check the winch Operating instructions.
Reinsert the wire.
Check the winch Operating instructions.
return to the manufacture to rematch.
