TEKPAC TP65 Operation Manual

Plate compactor

Advertisement

Quick Links

OPERATION MANUAL
PLATE COMPACTOR
TP65/TP85/TP100/TP120
TP85
TP65
TP100
TP120

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TP65 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for TEKPAC TP65

  • Page 1 OPERATION MANUAL PLATE COMPACTOR TP65/TP85/TP100/TP120 TP85 TP65 TP100 TP120...
  • Page 2: Table Of Contents

    Accessories Model The goal of our company is to produce power equipment that TP65 series, helps the operator work safely and efficiently. The most Built-in wheel - for easy TP85 series, important safety device for this or any tool is the operator.
  • Page 3 ! MECHANICAL HAZARDS DO NOT operate the machine unless all protective guards are in place. KEEP handles and feet clear of rotating and moving parts as they will cause injury if contacted. ENSURE that the motor operation switch is in the OFF position and the spark plug ignition lead is disconnected before removing the guards or making adjustments.
  • Page 4: Operation

    WEAR an approved hearing protection device to limit noise exposure. As required by Occupational Health and Safety regulations. PROTECTIVE CLOTHING ALWAYS wear approved hearing protection when working in a confined work space. Protective goggles and a dust mask should be worn when working in a dusty environment. Protective clothing and footwear may also be desirable when working with hot mix bitumen.
  • Page 5 Turn the engine ON/OFF switch clockwise to the “1” position. Set the throttle to the idle position by moving the throttle lever fully to the right. Do not start the engine on full throttle, as the compactor will vibrate as soon as the engine starts.
  • Page 6: Care And Preventive Maintenance

    CARE AND PREVENTIVE MAINTENANCE Check the oil level in the motor crankcase daily. Inspect the rubber anti vibration mounts for wear or deterioration. If the optional water tank is fitted inspect the water hose and its connections to ensure that they do not leak. Clean the underside of the plate regularly to prevent a build up of material.
  • Page 7 When changing the vibrator oil, remove the drain plug located at the bottom-right of the vibrator, and simply tip the compactor to drain the oil. Note that the oil will drain more easily while it is hot. For TP65 series, TP85 series, TP100 series, TP120 series, replace the oil with 200ML of 10W-30 motor oil.
  • Page 8: Specification

    4.2 kW (5.7hp) TP120-4 Petrol, Honda GX160 4.1 kW (5.5hp) Governed Speed - 3,500r/min Drive Belt 1 x ‘A’ section vee belt Vibrator Model TP65 series TP85 series TP100 series TP120 series Frequency (vibration/min) 5400 5400 5400 5400 Centrifugal Force (kN) 12.0...
  • Page 9: Transportation

    105.2dB power level Uncertainty Hand-Arm-Vibration (as per ISO8662, Part 1, m/s ): 4-9 Working Size (L X W X H): TP65 series: 34x108x105cm TP85 series:41x115x105cm TP100 series:45x115x105cm TP120 series: 50x115x105cm TP85 series: 84x50x81cm TRANSPORTATION Always shut off Motor when transporting machine.
  • Page 10: Trouble Shooting

    TROUBLE SHOOTING SYMPTOM POSSIBLE CAUSES SOLUTION Engine speed too low? Set engine speed to correct RPM. Clutch slips? Check or replace clutch. Travel speed too low, and vibration is V-belt slips? Adjust or replace V-belt. weak. Excessive oil in vibration? Drain excess oil and fill to proper level.
  • Page 11: Warranty

    WARRANTY These products are covered by warranty for a period of six (6) months from the date of purchase against defects in material or workmanship provided that: · The product concerned has been operated and maintained in accordance with the operating instructions. ·...
  • Page 12: Ec Declaration

    Distributed By TEKPAC ENGINEERING CO., LTD Add: YAXI VILLAGE, LUOSHE TOWN, HUISHAN DISTRICT, WUXI, JIANGSU, CHINA Tel: 86-510-80226679 Fax: 86-510-80226685 E-mail: sales@tekpac.com.cn Http://www.tekpac.com.cn Version: 01/10/01 Printed:05/2010...

This manual is also suitable for:

Tp85Tp100Tp120
