TFA 38.2021 - Timer And Stopwatch Manual

Before you use this product

Please make sure you read the instruction manual carefully.
Following and respecting the instructions in your manual will prevent damage to your instrument and loss of your statutory rights arising from defects due to incorrect use.
We shall not be liable for any damage occurring as a result of non-following of these instructions. Likewise, we take no responsibility for any incorrect readings or for any consequences resulting from them.
Please pay particular attention to the safety notices!
Please keep this instruction manual safe for future reference.

For your safety

This product should only be used as described within these instructions.
Unauthorized repairs, modifications, calibrations or changes to the product are prohibited.

Risk of injury:

Keep this device and the battery out of reach of children.
Small parts can be swallowed by children (under three years old).
Batteries contain harmful acids and may be hazardous if swallowed. If a battery is swallowed, this can lead to serious internal burns and death within two hours. If you suspect a battery could have been swallowed or otherwise caught in the body, seek medical help immediately.
Batteries must not be thrown into a fire, short-circuited, taken apart or recharged. Risk of explosion!
Low batteries should be changed as soon as possible to prevent damage caused by leaking.
Avoid contact with skin, eyes and mucous membranes when handling leaking batteries. In case of contact, immediately rinse the affected areas with water and consult a doctor.

Do not expose the device to extreme temperatures, vibrations or shocks.
Protect it from moisture.

Operation

Open the battery compartment by lifting up the holder and pulling down the battery compartment. Remove the battery insulation strip. Remove the protective foil from the display.
The unit is now ready to use.

Count Down Timer

Push the "M" button (max. 99 min.) and "S" button (max. 59 sec.) to set the desired time.
Holding "M" button or the "S" button in setting mode and you will enter fast mode.
Push the START/STOP button to start the countdown process.
You can stop and continue the countdown by pushing the START/STOP button.
When the timer counts down to "00m00s", a beeping alarm (max. 60 sec.) will sound. To turn off the alarm, press the START/STOP button.
The timer will recall the last selected time automatically.
You can restart the countdown by pushing the START/ STOP button.
Push the "M" and "S" button at the same time to reset the timer.

Stopwatch

Push the START/STOP button to start the count up process.
Use START/STOP button to stop and restart
Push the "M" and "S" button at the same time to reset the timer.

Fixing

Use the magnet or the clip at the back of the timer for fixing.
With the fold out hanging device you can fix it on a wall.
For table standing please fold out first the holder and than the metal support.

Care and maintenance

Clean your instrument with a soft damp cloth. Do not use solvents or scouring agents.
Remove the battery, if you do not use the product for a long period of time.
Keep the instrument in a dry place.

Battery replacement

Replace the battery when the display becomes weak or the alarm tone declines.
Ensure correct polarity when inserting the battery.

Troubleshooting

Problem	Solution
No display / Incorrect display	Ensure correct polarity of the battery
Incorrect display	Change battery

If your device fails to work despite these measures contact the supplier from whom you purchased it.

Specifications

Minutes:	up to 99 m
Seconds:	up to 59 m
Power consumption:	1 x 1.5 V AAA battery (included)
Dimensions:	83 x 28 (45) x 70 mm
Weight:	68 g (device only)

TFA Dostmann GmbH & Co. KG, Zum Ottersberg 12, 97877 Wertheim, Germany

No part of this manual may be reproduced without written consent of TFA Dostmann. The technical data are correct at the time of going to print and may change without prior notice. The latest technical data and information about this product can be found in our homepage by simply entering the product number in the search box.
