Ambientika Smart
APP
EN – CONFIGURATION AND USER MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Ambientika Smart and is the answer not in the manual?

Questions and answers

Summary of Contents for Süd wind Ambientika Smart

  • Page 1 Ambientika Smart EN – CONFIGURATION AND USER MANUAL...

  • Page 3: Table Of Contents

    TABLE OF CONTENTS 1. INTRODUCTION a. DOWNLOADING THE APP b. REGISTERING YOUR ACCOUNT 2. CONFIGURATION a. CREATING YOUR HOME b. SEARCHING FOR DEVICES c. CONFIGURING YOUR DEVICES d. RESETTING THE PRODUCT 3. ADDITIONAL CONFIGURATIONS a. ADDING A HOME b. RECONFIGURING OR REMOVING A HOME c.

  • Page 4: Introduction A. Downloading The App

    INTRODUCTION – DOWNLOADING THE APP Download the App from the store and install it on your smartphone. (for iOS® devices from the App Store, for Android® devices from the Play Store) Read the QR codes through the camera or search for the app directly in the stores. INTRODUCTION –...
  • Page 5 Select the ticks to accept these (at Enter the requested information and least the two mandatory ones) and tap register. tap confirm. Enter the code that was sent to the email listed on the previous page. Wait a few minutes, in case the You can now access the APP using security code has not yet reached the data you just entered.

  • Page 6: Configuration A. Creating Your Home

    CONFIGURATION – CREATING YOUR HOME To set up the system you will need to have Bluetooth and Wi-Fi enabled on your phone. To configure the system, the fan units should be connected to the power supply and powered as per the product instructions. Creating your own home: Enter the requested information Once you are logged in, tap “Add...

  • Page 7: Searching For Devices

    CONFIGURATION – SEARCHING FOR DEVICES Searching for installed devices and associating them with your home Internet network: Once the home is registered, the APP will search via Bluetooth for Select one of the products in the list. devices available to be configured, which will be displayed in a list.
  • Page 8 When a device is selected from the list, the Name the device, select the room it corresponding physical product will cause is in, and tap continue. the white LED to flash and beep so that it can be identified. You will need to repeat this with all products in the list.

  • Page 9: Configuring Your Devices

    CONFIGURATION – SETTING UP THE SYSTEM AUTOMATIC By choosing automatic configuration, the APP autonomously decides how to configure products according to the layout in the rooms. The configuration of individual products can be changed manually later from the “Home management” section in the APP. Select “Single system”...
  • Page 10 Proceed by naming the first zone and If you have chosen the configuration selecting the rooms you want to as “Zone system” tap on the “Add enter. zone” button Once the rooms have been selected, tap confirm. When zones have been Now you need to add the other configured, or you have chosen the...
  • Page 11 MANUAL Choosing manual configuration enables the user to choose how to configure each individual device. Please note that in each zone there must be a product configured as Master, which will be the product that will detect the environmental parameters of the zone. The configuration of individual products can be changed manually later from the “Home management”...
  • Page 12 Use the arrow to the right of the products to select the configuration Name the zone and select the rooms you want for the product. you want to include. It should be kept in mind that in each Once the rooms have been selected, zone there should be only one tap confirm.

  • Page 13: Resetting The Product

    IMPORTANT: the response time of devices varies depending on the speed of your available home connection. CONFIGURATION – RESETTING THE PRODUCT In the event you experience device configuration errors, you can perform a factory reset that restores the devices to their initial settings. To perform the reset, the physical button shown in the image below should be pressed for 15 seconds: Once the reset is done, the unit will beep.

  • Page 14: Additional Configurations

    ADDITIONAL CONFIGURATIONS – ADDING A HOME To add a home to the APP, tap the From the HOME screen, tap the little house icon with the “+” and proceed house in the upper left corner. with the configuration as explained in the “Configuring the system”...

  • Page 15: Reconfiguring Or Removing A Home

    ADDITIONAL CONFIGURATIONS – RECONFIGURING OR REMOVING A HOME The cases in which a home needs to be re-configured and in which it needs to be removed are listed below. When to RECONFIGURE a home from the APP: If you want to add a product to the system If you want to change configuration to one or more products (e.g.
  • Page 16 Follow the steps below to RECONFIGURE the home. USER MANAGEMENT Select the home you want to screen, tap the “home management” reconfigure by tapping the arrow to arrow. its right. If you want to add a product you will Then tap “Reconfigure Home” at the have to search for the device in the bottom.
  • Page 17 To REMOVE the home, follow the below steps. USER MANAGEMENT Select the home you want to remove screen, tap the “home management” by tapping on the arrow to its right. arrow. Then tap “Remove home” at the bottom. At this point, should you wish to reconfigure the home, you must also physically reset the machines following the instructions in the chapter “Resetting the...

  • Page 18: Renaming A Home Or Products

    ADDITIONAL CONFIGURATIONS – RENAMING A HOME OR PRODUCTS To rename a home or products, follow the below steps. USER MANAGEMENT Select the home where you want to screen, tap the “Home management” make the change by tapping the arrow. arrow to its right. Now tap the pencil to the right of the name you want to edit.

  • Page 19: Instructions For Use A. App

    INSTRUCTIONS FOR USE – APP IMPORTANT: If the product is part of a system with more than one machine communicating with each other, remember that commands will be received exclusively by the MASTER unit, which will then manage all SLAVE units. AUDIO-VISUAL SIGNALS Receive Command: when the fan unit correctly receives a command it will emit a BEEP and the white LED will flash once.
  • Page 20 SMART MODE...
  • Page 21 To activate this mode you will need to go the “Operating mode” screen and tap the SMART button. In this mode, sensors are active on the unit that detect the temperature, air quality and light intensity indoors, which are then compared with those outdoors measured by the nearest weather station.
  • Page 22 AUTOMATIC MODE To activate this mode you will need to go to the “Operating mode” screen and tap the AUTO button. In this mode, the HUMIDITY CURSOR is activated to enable you to choose the desired threshold. In this mode both the humidity sensor and the twilight sensor are active, the units then self-manage without the need to give further commands.
  • Page 23 NIGHT MODE To activate this mode you will need to go to the “Operating mode” screen and tap the NIGHT button. In this mode, all units will run at night speed heat recovery mode until another command is entered. Usage tips This mode is recommended in cases where the outdoor environment is very quiet and even the minimum...
  • Page 24 SURVEILLANCE MODE To activate this mode, you will need to go to the “Operating mode” screen and tap the SURVEILLANCE button. In this mode, the HUMIDITY CURSOR is activated to enable you to choose the desired threshold. In this mode both the humidity sensor and the twilight sensor are active, the units will normally be at rest with the damper closed and the sensors active, so that when the...
  • Page 25 MANUAL HEAT RECOVERY MODE To activate this mode, you will need to go to the “Operating mode” screen and tap the MANUAL HEAT RECOVERY button. In this mode the FAN CURSOR is activated to enable you to choose the desired speed. In this mode the sensors are deactivated and the units will always go into heat recovery mode.
  • Page 26 EXPULSION MODE To activate this mode, you will need to go to the “Operating mode” screen and tap the EXPULSION button. In this mode, the FAN CURSOR button is activated to enable you to choose the desired threshold. Tapping the relevant button will cause all units to run constantly in expulsion mode with the option to change the operating speed to suit your needs.
  • Page 27 MASTER-SLAVE AIRFLOW MODE To activate this mode, you will need to go to the “Operating mode” screen and tap the MASTER-SLAVE FLOW key. In this mode, the FAN CURSOR is activated to enable you to choose the desired threshold. In this mode, the products create a continuous air flow from MASTER or SLAVE EQUAL TO MASTER units to SLAVE OPPOSITE TO MASTER units to the...

  • Page 28: User Profile

    SHUTDOWN MODE To activate this mode, you will need to go to the “Operating mode” screen and tap the POWER OFF button. In this mode, the products are turned off and the sensors are disabled. NOTE: The background and icons shown in this manual may differ from those on the device. USER PROFILE –...

  • Page 29: Faq

    Make sure the product is connected to the power supply correctly. The product does not turn on. Check that the ON/OFF (I/O) switch is in the ON (I) position. Get physically close to the products with the smartphone During configuration, products cannot be found Enable permissions for the APP to search Bluetooth via Bluetooth...
  • Page 30 SUEDWIND SRL Via Artigiani 14, - 39057 Appiano sulla Strada del Vino, Italy Tel. 030 68 62 341 info@ambientika.eu www.ambientika.eu...
