Light Symphony LS30050WRC Quick Start Manual

'2-WAY' OR 'ON/OFF' SWITCHING
By default, the remote control transmits Area 'Toggle' commands. For example, when
button 'Area 1' is operated, the remote will transmit 'Area 1 Toggle'. If Area 1's
lighting is ON this will switch it OFF, but if Area 1 was OFF it will switch it ON. In
this way the remote can work intuitively with wireless switch modules to create a
2-way switching system.
However, on larger installations, where lighting circuits may have been included in
overlapping Areas this type of control may be less convenient.
For example Area 1 may have been designated 'All Tree Lights' and Area 2 as "Upper
Garden", where the upper garden includes some tree lighting. In this case, if only the
upper garden is ON then 'Changing' Area 1 could turn some tree lights on and others
off.
The remote control's behaviour can be modified to transmit On and Off commands
instead of 'Toggle' commands. This makes 2-way switching less convenient but
prevents the unwanted behaviour outlined above.

ON/OFF MODE

To configure the remote to transmit 'ON/OFF' commands;
Press and hold buttons "1" and "3" together until the led blinks rapidly.
'TOGGLE' (2-WAY) MODE
To configure the remote to transmit 'TOGGLE' commands;
Press and hold buttons "4" and "6" together until the led blinks rapidly.
The master 'Garden On/Off' buttons are not affected by the above, they will
Note:
always send On/Off type commands.
Environmental Information for Customers in the European Union
European Directive 2002/96/EC requires that the equipment bearing this symbol on the product and/or its
packaging must not be disposed of with unsorted municipal waste. The symbol indicates that this product
should be disposed of separately from regular household waste streams. It is your responsibility to dispose
of this and other electric and electronic equipment via designated collection facilities appointed by the
government or local authorities. Correct disposal and recycling will help prevent potential negative
consequences to the environment and human health. For more detailed information about the disposal of your old
equipment, please contact your local authorities, waste disposal service, or the shop where you purchased the product.

SPECIFICATIONS

Battery 2 x AAA Lithium
Frequency 434.075MHz
Range >1000 meters line-of-sight
Safety Rating Extra Low Voltage
Physical 105 x 58 x 45mm / 0.15Kg
Ambient Temp. 0°C to +40°C

INTRODUCTION

The Light Symphony long-range remote control provides simple
walk-about control over your garden lighting.
This manual provides a basic guide to its functions and assumes
your lighting is now installed and fully working. For more
detailed information on the setting up of the system please refer to
the instructions provided with Light Symphony's other products.
Before using the remote control please ensure it is fitted with two
Lithium 'AAA' size batteries. These are inserted by removing the
slide cover on the rear of the unit. For best performance use long-
life Alkaline or Lithium batteries.
Long-Range Remote-Control
ISSUE 4.0
COPYRIGHT © PM INTERNATIONAL LTD 2023
