Ultima 500

User's Guide

G O U L D I N S T R U M E N T S Y S T E M S

Part Number 269-937303

Version 2.3

Table of Contents

Need help?

Do you have a question about the Ultima 500 and is the answer not in the manual?

Questions and answers

Summary of Contents for Gould Ultima 500

Page 1 Ultima 500 User's Guide G O U L D I N S T R U M E N T S Y S T E M S Part Number 269-937303 Version 2.3...
Page 2 Ultima 500 DSO Gould Instrument Systems, Inc. 5225 Verona Road, Bldg. 4 Madison, Wisconsin USA 53711 Phone (608) 327-6600 • Fax (608) 327-6700 Version 2.3...
Page 3 G O U L D S Y S T E M W A R R A N T Y THIS WARRANTY REPLACES ALL OTHER WARRANTIES, EXPRESSED Gould warrants that each product we sell is OR IMPLIED, INCLUDING THE free from defects in labor and materials and...
Page 4 This is your sole remedy for product defects. In no event will Gould's liability exceed the price paid for the software, regardless of the form of the claim. Gould does not warrant that the software be uninterrupted or error-free. Version 2.3...
Page 5 Y E A R 2 0 0 0 C O M P L I A N C E and attempts to do so, are also criminal The Gould Ultima operating system and violations, with penalties that may exceed software has been tested and verified for $100,000 in fines and 10 years in prison.
Page 6: Table Of Contents
Channel Menu Symbols Used in This Manual Channel Select Manual Conventions Scale Chapter 3: Introduction Probe Scaling Offset Introducing the Gould Ultima 500 Units and Scaling Chapter 4: Using the Front Variable Gain 6-10 Panel Controls Termination 6-12 Acquisition Menu...
Page 7 Controls 8-12 Save Format 6-101 Save As 6-102 Chapter 9: Tutorial Recall 6-105 Exploring the Ultima 500 Front Panel 9-2 Export to Folder 6-110 A - Power Up Export As… 6-111 B - Obtaining a Display Print 6-114 C - Viewing a Signal Using the Front...
Page 8 Appedix A: Connector Pinouts Appendix E: Service and Driver Circuit Information Driving the External Clock Input Ultima Replaceable Parts Driving the External Clock Appendix F: Ultima 500 External Clock Specifications I/O Connector Vertical +5 V on I/O Connector Horizontal Probe Power (Rear Panel)
Page 9: Chapter 1: Safety Messages
Ultima 500 DSO Chapter 1: Safety Messages Chapter 1: Safety Messages Version 2.3...
Page 10 Chapter 1: Safety Messages Ultima 500 DSO Version 2.3...
Page 11 Ultima 500 DSO Chapter 1: Safety Messages The first WARNING note below is Whenever it is likely that safety protection required by the FCC and relates only to the has been impaired, the instrument must be interference potential of this equipment.
Page 12 Chapter 1: Safety Messages Ultima 500 DSO L I V E P A R T S WARNING The covers protect the user from live parts and should only be removed by suitably It is recommended that signal grounds qualified personnel for maintenance and always be connected to a local ground.
Page 13 Ultima 500 DSO Chapter 1: Safety Messages interference to other equipment. However, P O W E R A N D F R E Q U E N C Y R E Q U I R E M E N T S there is no guarantee that interference will not occur in a particular installation.
Page 14 Chapter 1: Safety Messages Ultima 500 DSO WARNING WARNING This instrument and related accessories are not designed for biomedical ELECTRICAL SHOCK HAZARD! experimentation on humans and should Any interruption of the protective not be directly connected to human conductor inside or outside the subjects or used for patient monitoring.
Page 15 Ultima 500 DSO Chapter 1: Safety Messages Nederlands I N T E R N A T I O N A L S A F E T Y W A R N I N G S VEILIGHEIDSWAARSCHUWING Danish Dit instrument mag uitsluitend worden...
Page 16 Chapter 1: Safety Messages Ultima 500 DSO Suomi Français TURVAOHJEITA ATTENTION - DANGER! Tätä laitetta käytettäessä sen tulee olla Cet appareil doit impérativement être mis à suojamaadoitettu joko verkkojohdon la masse par le conducteur de terre du câble suojajohtimen tai erillisen d’alimentation ou, si l’instrument en...
Page 17 Ultima 500 DSO Chapter 1: Safety Messages Deutsch Italiano WARNHINWEIS! AVVISO DI SICUREZZA Dieses Gerät muß mit einer Schutzerde Questo strumento deve esser utilizzato con betrieben werden, die über den Schutzleiter un collegamento protettivo di messa a terra des Speisekabels oder über die tramite il filo di messa a terra del cavo di Erdungsklemme des Gerätes (falls...
Page 18 Chapter 1: Safety Messages Ultima 500 DSO Norsk Português ADVARSEL! Aviso de segurança Dette instrumentet må bare anvendes så Este aparelho deve ser operado com uma lenge det er jordet via den beskyttende ligação terra ligado por um conductor jordlederen i strømkabelen, eller via trifásico do cabo principal ou, se o...
Page 19 Ultima 500 DSO Chapter 1: Safety Messages Español Svenska SÄKERHETSVARNING ADVERTENCIA SOBRE SEGURIDAD Detta instrument måste drivas med en skyddande jordledning ansluten via den Este instrumento debe utilizarse conectado skyddande jordledaren på matarkabeln eller, a tierra a través del conductor de puesta a om instrumentet har sådan monterad, via...
Page 20 Chapter 1: Safety Messages Ultima 500 DSO English SAFETY WARNING This instrument must be operated with a protective ground (earth) connected via the protective ground conductor of the supply cable or, if the instrument is fitted with one, via the safety ground terminal. Any...
Page 21: Chapter 2: About This Manual
Ultima 500 DSO Chapter 2: About This Manual Chapter 2: About This Manual Version 2.3...
Page 22: Symbols Used In This Manual
Chapter 2: About This Manual Ultima 500 DSO Symbols Used in This Manual The following symbols are used throughout this manual to indicate warnings and cautions. Indicates a potentially hazardous situation which, if not avoided, WARNING could result in death or serious injury.
Page 23: Chapter 3: Introduction
Ultima 500 DSO Chapter 3: Introduction Chapter 3: Introduction Version 2.3...
Page 24: Introducing The Gould Ultima 500
Ultima 500 DSO Introducing the Gould Ultima 500 Congratulations on your purchase of the Ultima 500, the first in a family of Gould Workstation DSO’s. Combining the acquisition power of a high performance four-channel DSO with the flexibility and features of a PC, Ultima 500’s unique capability simplifies data handling by effortlessly moving from capture to report in one compact unit.
Page 25 Ultima 500 DSO Chapter 3: Introduction ProView Analysis and Report Software – Accepts data directly from Ultima, providing lightning fast display and processing of data. A formula database with over 100 math functions defines custom calculations. ProView is automatically updated every time Ultima acquires new data, or when manually commanded with a one-button control.
Page 26 Chapter 3: Introduction Ultima 500 DSO Blank page. Version 2.3...
Page 27: Chapter 4: Using The Front Panel Controls
Ultima 500 DSO Chapter 4: Using the Front Panel Controls Chapter 4: Using the Front Panel Controls Version 2.3...
Page 28: Using Front Panel Controls
Help Opens and closes the on-line help. To update the on-line help in your system, visit the Gould Ultima website www.gouldis.com/ultima and choose Downloads. Run/Stop Toggles between starting and stopping an acquisition. The acquisition status is shown by the Stored light.
Page 29: Auto Setup
Ultima 500 DSO Chapter 4: Using the Front Panel Controls Auto Setup Pressing this button opens a menu to the left which requests confirmation. This confirmation prevents activating the Auto Setup feature in error. Auto Setup interrogates all (four) channel inputs and sets the amplitude scale for appropriate viewing.
Page 30 Chapter 4: Using the Front Panel Controls Ultima 500 DSO Page 1 / Page 2 The Ultima has two modes of operation which are displayed in Page 1 and Page 2. This control toggles the display between Page 1 and Page 2. Toggling between pages does not affect the setup of either page.
Page 31: Cursor Controls
Ultima 500 DSO Chapter 4: Using the Front Panel Controls Cursor Controls The front panel Cursor 1 and Cursor 2 controls adjust the position of the cursors seen on the display. Vertical cursors measure time and Y value at the cursor, Horizontal cursors measure amplitudes manually and crosshair cursors measure both time and amplitude.
Page 32: Trace Select
Chapter 4: Using the Front Panel Controls Ultima 500 DSO Trace Select Trace Select toggles the selection of the active trace among the (displayed) traces. The Cursor Panel at the bottom of the screen indicates the selected trace. Trace Select also controls which trace the Snapshot Measurements are performed upon.
Page 33 Ultima 500 DSO Chapter 4: Using the Front Panel Controls Equivalent Time Sampling (ETS) The fastest timebase ranges are achieved when using Equivalent Time Sampling. This is a technique whereby a complete trace is built up by sampling a number of acquisitions at various times relative to the trigger point.
Page 34 Chapter 4: Using the Front Panel Controls Ultima 500 DSO Memory Length & Sample Rate The Ultima can display up to 500 columns per horizontal sweep. When the memory length is 500 samples, there is one sample per column. When memory lengths are greater than 500, video compression is used.
Page 35 Ultima 500 DSO Chapter 4: Using the Front Panel Controls Avoiding Aliasing with Glitch Detection Glitch Detect feature exposes aliases. With dot join on, this usually results in a filled-in wave envelope being seen on the screen, indicating a high frequency, as shown below.
Page 36 Chapter 4: Using the Front Panel Controls Ultima 500 DSO External Clock To use an external clock as the timebase, move the Time/Div control counterclockwise until EXT appears on the display. The external clock TTL input is on the rear panel in a “D” type connector.
Page 37 Ultima 500 DSO Chapter 4: Using the Front Panel Controls Main and Zoom Display Sets the display mode to Main, Zoom or Main & Zoom. Main mode displays the total acquisition sweep. For example, if a 500 ksample memory is chosen, the data is compressed in the...
Page 38 Chapter 4: Using the Front Panel Controls Ultima 500 DSO X Zoom Factor Pressing the Time/div control turns this knob into the X Zoom Factor control. The Zoom Bar across the top of the display grid and the vertical line then brighten up, signifying that the Ultima is in Zoom Set mode.
Page 39 Ultima 500 DSO Chapter 4: Using the Front Panel Controls Position – X Zoom When the Ultima is in Zoom Set mode, this control moves the position of the Zoom Bar, and thus the region of the main trace to be zoomed, from the beginning of the main trace to the end.
Page 40: Vertical Controls
Chapter 4: Using the Front Panel Controls Ultima 500 DSO Vertical Controls The primary channel (input) controls are front panel rotary style and push button. They are individual for each channel to facilitate ease of use. Channel Scale The scaling for each input is adjusted in 1-2-5 steps using the Scale knob.
Page 41 Ultima 500 DSO Chapter 4: Using the Front Panel Controls Channel Position The Position control shifts the baseline of the respective trace up or down. Turn the control clockwise to shift the trace up and counterclockwise to shift the trace down. The control applies acceleration if it is operated quickly and continuously in one direction.
Page 42 Chapter 4: Using the Front Panel Controls Ultima 500 DSO Channel Coupling AC-DC-GND The coupling control cycles the respective input between AC, DC and Ground. DC is the most generally applicable coupling so Auto Setup sets this control to DC when possible.
Page 43: Trigger Controls
Ultima 500 DSO Chapter 4: Using the Front Panel Controls Trigger Controls The Trigger Controls perform the following functions: • Adjust the Trigger Level(s) • Open the Trigger menu for advanced triggering functions • Switch between Normal and Auto modes •...
Page 44 Chapter 4: Using the Front Panel Controls Ultima 500 DSO Blank page. 4-18 Version 2.3...
Page 45: Understanding The Display
Ultima 500 DSO Chapter 5: Understanding the Display Chapter 5: Understanding the Display Version 2.3...
Page 46: The Status Panel
Chapter 5: Understanding the Display Ultima 500 DSO Understanding the Display The Ultima 500 display is designed to be comprehensive and complete. The Ultima's display is easy to read, with groupings of pertinent information and neatly packaged areas as described in this section.
Page 47: Channel Panels
Ultima 500 DSO Chapter 5: Understanding the Display Channel Panels Displays the volts per division for each channel in both the Main and Zoom modes. Channel settings are changed Scale using the front panel Scaling controls, the button in Channel menu or mouse driven control panels.
Page 48: Cursor Panel
Chapter 5: Understanding the Display Ultima 500 DSO Cursor Panel Displays the ∆X, ∆Y, absolute X, absolute Y or with respect to trigger values of the cursors for the active channel. The cursor mode is set Cursors Display using the...
Page 49: Setting Cursors
Ultima 500 DSO Chapter 5: Understanding the Display Setting Cursors Cursor modes (Horizontal, Vertical or Both (crosshairs)) are changed in a number of ways: • Pushing the Cursor 1 control. • Clicking in the Cursor Status Panel with a mouse.
Page 50 Chapter 5: Understanding the Display Ultima 500 DSO Blank page. Version 2.3...
Page 51: Chapter 6: Using The Main Menus
Ultima 500 DSO Chapter 6: Using the Main Menus Chapter 6: Using the Main Menus Version 2.3...
Page 52: About The Main Menu
Chapter 6: Using the Main Menus Ultima 500 DSO About the Main Menu Main menu contains setups for all functions of the oscilloscope, with the exception of triggering which is activated from the Trigger Menu button on the front panel. To view the...
Page 53: Channel Menu
Ultima 500 DSO Chapter 6: Using the Main Menus Channel Menu Channel menu controls the vertical parameters of each input signal: scaling, offset, measurement units and input impedance. Version 2.3...
Page 54: Channel Select
Chapter 6: Using the Main Menus Ultima 500 DSO Channel Select Use the Cursor 2 control to select which channel to configure. Once selected, that channel becomes the active channel. All subsequent changes made in this menu apply to that active channel. Selecting different channels allows independent configuration of each channel.
Page 55: Offset
Ultima 500 DSO Chapter 6: Using the Main Menus Offset Channel Offset Opens a new menu, , which allows configuration of a plus or minus DC offset for the active channel. Version 2.3...
Page 56 Chapter 6: Using the Main Menus Ultima 500 DSO Offset Select an offset for the active channel by either rotating the Cursor 2 control or by clicking and dragging the slider control. Users with a keyboard may enter a value directly.
Page 57: Units And Scaling
Ultima 500 DSO Chapter 6: Using the Main Menus Units and Scaling Channel Scaling Opens the menu which allows configuration of the numerical offset, multiplication factor, and units, based on the y=m(x-b) equation. Version 2.3...
Page 58 Chapter 6: Using the Main Menus Ultima 500 DSO Offset Select an offset value for the display only. Values can be entered with the Cursor 1 and Cursor 2 controls or entered directly using a keyboard. Enter a value by...
Page 59 Ultima 500 DSO Chapter 6: Using the Main Menus Scaling Turns channel scaling on or off. Use the Cursor 2 control to make the selection. Units Text Entry Opens the standard menu enabling direct entry of custom units for the channel input. Use the Cursor 1 and Cursor 2 controls as described in the menu or type the entry using a keyboard.
Page 60: Variable Gain
Chapter 6: Using the Main Menus Ultima 500 DSO Return To Channel Exits the current menu and returns to the menu. Variable Gain Channel Variable Gain Opens the menu, which changes the scaling of the volts per division into custom units, between the standard 1, 2, 5 sequence settings.
Page 61 Ultima 500 DSO Chapter 6: Using the Main Menus Variable Gain Sets the gain for the input between 35% and 100% of the current scale setting. Effective scaling in voltage per division is instantly reported when Variable Gain is enabled. Use the Cursor 2 control or the mouse to select the value.
Page 62: Termination
Chapter 6: Using the Main Menus Ultima 500 DSO Termination menu allowing either a 1MΩ or 50 Ω Channel Termination Opens the termination (the input impedance of the BNC input connector). Note that following the selection of 50 Ω termination, the following warning...
Page 63: Acquisition Menu
Ultima 500 DSO Chapter 6: Using the Main Menus Acquisition Menu Acquisition menu controls the settings for acquiring data: • Resolution • Memory Length • Fast Modes • Glitch Detect (max-min presentation) • Averaging • Bandwidth • Horizontal (axis) Scaling Version 2.3...
Page 64: Resolution
The 10-bit mode requires fewer triggered events to obtain a complete capture and therefore completes an acquisition with increased speed. For more information on this high resolution mode, see The Gould High Resolution System. 6-14 Version 2.3...
Page 65 (MAIN and ZOOM display) resolution (MAIN and ZOOM display) The Gould method of acquiring high resolution signals involves injecting a dither signal in series with the input and then over-sampling. The dither signal is extracted after the ADC conversion to digital with special DSPs. The dither signal effectively offsets the signal relative to the ADC levels.
Page 66: Memory Length
Chapter 6: Using the Main Menus Ultima 500 DSO Memory Length Both the memory length and sample rate determines the total time your system will acquire data. Memory Length X 1/(Sample Rate) = Total Acquisition Time It is often best to start with a high sample rate and a large memory length to obtain the highest resolution on the entire data set to be collected.
Page 67 Ultima 500 DSO Chapter 6: Using the Main Menus Arbitrary Memory Select the number of points to capture using the Cursor 2 control or use the mouse to move the slider. Enter the number from the keyboard or press the Memory Length button again to select the numeric entry from the bezel buttons.
Page 68 Chapter 6: Using the Main Menus Ultima 500 DSO Multi Shot The Multi Shot function offers the ability to segment the acquisition memory allowing multiple acquisitions packaged into one data set. When Multi Shot is selected the memory mode is automatically switched to Arbitrary to accommodate the number of segments with the preset length.
Page 69: Fast Modes
Ultima 500 DSO Chapter 6: Using the Main Menus Fast Modes Fast Modes are used to tailor the acquisition engine to various high-speed data capture applications. Select the mode using the Cursor 2 control or mouse click. ETS - Repetitive signals only - the fastest timebase ranges are achieved when using ETS (Equivalent Time Sampling).
Page 70: Glitch Detect
Chapter 6: Using the Main Menus Ultima 500 DSO Glitch Detect Glitch Detect Turns on or off the feature. Use the Cursor 2 control or mouse click to make the selection. Any sample rates less than the fastest (500 MS/s) increase the chance to miss a fast transient.
Page 71: Average
Ultima 500 DSO Chapter 6: Using the Main Menus Average Select the value to use for Averaging using the Cursor 2 control or mouse click. Average uses a weighted average system. When operating on a repetitive acquisitions the signal will...
Page 72: Horizontal Scaling
Chapter 6: Using the Main Menus Ultima 500 DSO Horizontal Scaling Horizontal Scaling Opens the menu to allow horizontal scaling for measurements and display. 6-22 Version 2.3...
Page 73 Ultima 500 DSO Chapter 6: Using the Main Menus Multiplication Factor Select a multiplication factor for the horizontal display using the Cursor 1 and Cursor 2 controls as described in the menu or by typing in a value using a Apply keyboard.
Page 74 Chapter 6: Using the Main Menus Ultima 500 DSO Units Text Entry Opens the standard menu enabling direct entry of custom units for the horizontal display. Use the Cursor 1 and Cursor 2 controls as described in the menu or type the entry using a keyboard.
Page 75 Ultima 500 DSO Chapter 6: Using the Main Menus Return To Acquisition Exits the current menu and returns to the menu. Version 2.3 6-25...
Page 76: Display Menu
Chapter 6: Using the Main Menus Ultima 500 DSO Display Menu Display menu contains controls for: Setting the display mode (YT, XY, YT+XY or TruTrace ® Customizing the window layouts for Page 1 Customizing the window layouts for Page 2...
Page 77: Page 1 Mode
Ultima 500 DSO Chapter 6: Using the Main Menus Page 1 Mode Select the display mode for Page 1 using the Cursor 2 control. In Page 1 mode there are four selections: displays channels 1 through 4 with the Y amplitude against the X timebase.
Page 78 Chapter 6: Using the Main Menus Ultima 500 DSO Page 1 Layout for XT + XY Standard and Full Screen displays two windows. One for the YT trace and one for the XY trace. Trace Split displays up to seven display windows four with the channel YT sweeps and three for the channel XY traces.
Page 79: Page 1 Window Layout
Ultima 500 DSO Chapter 6: Using the Main Menus Page 1 Window Layout The display layout for Page 1 has five preset formats giving flexibility to view the waveforms from the four input channels. The window layouts are Standard, Full Screen, Zoom Split, and Trace and Zoom Split which operate in conjunction with the mode selection, Main and Zoom, and the Channel On/Off.
Page 80 Chapter 6: Using the Main Menus Ultima 500 DSO Page 2 Window Layout Select a Window Layout for Page 2 using the Cursor 2 control. Assign any trace to any window whether it is real-time direct, derived, processed, main, zoomed, XY, YT, statistical, frequency domain, or recalled from a previous acquisition.
Page 81: Page 2 Analysis And Window Definition
Ultima 500 DSO Chapter 6: Using the Main Menus Page 2 Analysis and Window Definition Analysis Opens the menu and switches to Page 2. When closing the instrument will return to Page 1 use the front panel Page 1/2 button to select Page 2 display.
Page 82: Cursors
Chapter 6: Using the Main Menus Ultima 500 DSO Cursors Cursor Opens the Menu or pressing the front panel Cursor 2 control will provide a short cut. The menu contains commands to set the options for vertical, horizontal cursors or both horizontal and vertical.
Page 83 Ultima 500 DSO Chapter 6: Using the Main Menus channel. The Snapshot measurements, if switched ON, are displayed in the channel color. When multiple windows are used, the cursors can be shown in all windows, which indicates the time relationship between them. To make measurements on multiple channels simultaneously, go to Page 2 analysis and allocate measurements as required.
Page 84 Chapter 6: Using the Main Menus Ultima 500 DSO Bring Cursors On Screen Positions the cursors onto the Zoom section of the display. The cursors move to a position one division in from each end of the Zoom trace with Cursor 1 on the left and Cursor 2 on the right.
Page 85: Persistence
The persistence display shows deviations in acquired signals. The Ultima 500 has three modes of persistence Decay Over Time – for signals that have regular triggers. Each acquisition is written to the display and held with a constant brightness for a defined period of time, highlighting edge fluctuations and or glitches.
Page 86 Chapter 6: Using the Main Menus Ultima 500 DSO Persistence Mode Select the Persistence mode using the appropriate menu button or the Cursor 2 control. Decay Over Time Select the Time For Full Decay by using the appropriate menu button or Cursor 2 control.
Page 87 Ultima 500 DSO Chapter 6: Using the Main Menus Decay by Sweeps Select the Sweeps For Full Decay by using the appropriate menu button or Cursor 2 control. This mode is best for signals that have erratic or infrequent triggers. If triggers are regular...
Page 88: Display Mode
Chapter 6: Using the Main Menus Ultima 500 DSO Persistence Enable Set Persistence On or Off using the appropriate menu button or Cursor 2 control. Persistence Clear When Persistence is enabled, this control allows immediate refresh of the display. In this manner, Infinite Decay (no decay) can be used allowing manual clearing of old data.
Page 89: Math Menu
Ultima 500 DSO Chapter 6: Using the Main Menus Math Menu Math menu contains controls for: • Snapshot Measurements (Page 1 only) • Analysis and Custom Measurements (Page 2 only) • Transfer of data to ProView or MS Excel for further analysis and report generation.
Page 90: Page 1 Snapshot Measurement Setup
Chapter 6: Using the Main Menus Ultima 500 DSO Page 1 Snapshot Measurement Setup Snapshot Measurements are assigned to a signal as a group by using the Trace Select front panel control. The measurements are displayed in a column on the left hand side of the display in the color corresponding to the signal being measured.
Page 91 Ultima 500 DSO Chapter 6: Using the Main Menus Snapshot Measurement Parameters (AD means taken on All Data) • Horiz(ontal) - time referenced to the trigger • Level - referenced to input signal ground • Top - algorithm to define top (AD) •...
Page 92: Page 2 Analysis And Window Definition
Chapter 6: Using the Main Menus Ultima 500 DSO Page 2 Analysis and Window Definition Analysis Opens the menu and switches to Page 2. The controls in this menu provide a comprehensive set of waveform analysis, custom measurements and measurement analysis tools.
Page 93 Ultima 500 DSO Chapter 6: Using the Main Menus Insert New Function Select the analysis function using the appropriate menu button or the Cursor 2 control. Analysis function choices are as follows: • Trace Math – derive a new trace from a mathematical operation performed on one (1) or two (2) traces.
Page 94 Chapter 6: Using the Main Menus Ultima 500 DSO Once the analysis function is selected: • The menu system becomes dynamic, offering the relevant choices in a progressive sequence. • An Analysis Preview window opens. This ‘live action’ window displays source traces, resultant traces, custom Measurements, XY windows, FFTs, Graphs and Histograms.
Page 95 Ultima 500 DSO Chapter 6: Using the Main Menus About Trace Math Functions - The selected traces are added together. Each point on the resultant trace is the sum of the amplitude from the equivalent time related points on the two source traces.
Page 96 Chapter 6: Using the Main Menus Ultima 500 DSO Trace Math – Add, Subtract, Multiply, and Divide Functions The functions (Add through Time Shift) are set up in a similar fashion. An example of the Add function is presented here.
Page 97 Ultima 500 DSO Chapter 6: Using the Main Menus Upon choosing Add, the Analysis Preview window displays two source windows and a result window. Note: Analysis Preview While in the window, the result waveform can be positioned and scaled with...
Page 98 Chapter 6: Using the Main Menus Ultima 500 DSO Select source 1 from the list of channels, or other resources that had previously been defined, using the appropriate menu button or the Cursor 2 control. Next When a source 1 is selected, click the button for the next prompt.
Page 99 Ultima 500 DSO Chapter 6: Using the Main Menus Trace Math – Invert, Filter, Integrate, and Differentiate Functions The Invert, Filter, Integrate, and Differentiate functions are set up in a similar fashion. An example of the Filter function is presented here.
Page 100 Chapter 6: Using the Main Menus Ultima 500 DSO Upon choosing Filter, the Analysis Preview window displays two source windows and a result window. Note: Analysis Preview While in the window, the result waveform can be positioned and scaled with...
Page 101 2 ms/div the first filter frequency will be: 5.44/2e−3 = 2.72 kHz. To define other filters, use post-acquisition analysis programs like Gould’s ProView or ImPRESSion analysis and report generation software. Rename Item / Change Color / Delete Item / Delete All Use the button to name, color or delete the function.
Page 102 Chapter 6: Using the Main Menus Ultima 500 DSO Trace Math – XY Function XY in Page2 analysis is different from XY in Page1 in a few ways. Page1 is a simple way to see CH1 as the X axis and CH2, CH3, CH4 as Y axis and is not flexible.
Page 103 Ultima 500 DSO Chapter 6: Using the Main Menus Upon choosing XY, the Analysis Preview window displays two source windows and a result window. Note: When outside of the Analysis Preview window, the Display Mode must be set to XY mode or XY + YT mode to view the XY relationship.
Page 104 Chapter 6: Using the Main Menus Ultima 500 DSO Select source 1 from the list of channels, or other resources that had previously been defined, using the appropriate menu button or the Cursor 2 control. Next When a source 1 is selected, click the button for the next prompt.
Page 105 Ultima 500 DSO Chapter 6: Using the Main Menus Trace Math –Segment Function Segment under Trace Math in Page2 allows individual segments to be selected and displayed in any of the Windows where in Page1 the display can show either one of the segments or all the segments.
Page 106 Chapter 6: Using the Main Menus Ultima 500 DSO Upon choosing segment, the Analysis Preview window displays the source window and a result window. This display shows segment 5 from channel 1. The bar across the bottom allows changes to be made for the source...
Page 107 Ultima 500 DSO Chapter 6: Using the Main Menus Trace Math –Time Shift Function Time Shift under Trace Math in Page2 allows a waveform to be moved in time to correct for phase errors or to display waveforms that are not coincident in time.
Page 108 Chapter 6: Using the Main Menus Ultima 500 DSO Upon choosing Time Shift, the Analysis Preview window displays the source window and a result window. This display shows the waveform from channel 1. The bar across the bottom allows changes to be made for the source channel and the value of time to shift the waveform.
Page 109 Ultima 500 DSO Chapter 6: Using the Main Menus Source button opens a menu of all relevant sources for easy selection. There can be many different parameters. Parameters More button toggles which parameters are presented for adjustment. In this case, Reference and Bounds parameters are available.
Page 110 Chapter 6: Using the Main Menus Ultima 500 DSO The Reference Parameters for Pulse Width for example are Crossing level where there are subsections as shown. Transitions can be set at a percentage of the crossing amplitude defined by the Crossing selection. Here shown for % Top-Base...
Page 111 Ultima 500 DSO Chapter 6: Using the Main Menus The setting up of each Measurement is slightly different as each measurement has its own set of parameters: Source type(s), Bounds and References. This section describes the sequence for setting up a typical Measurement.
Page 112 Chapter 6: Using the Main Menus Ultima 500 DSO About Measurements Due to their ability to be completely customized, these analysis Measurements are a very powerful tool. Any parameters that are reasonable to customize can be customized. These parameters include: source, references, boundries, levels absolute, statistical levels, specific crossing number, etc.
Page 113 Ultima 500 DSO Chapter 6: Using the Main Menus Measurement Parameters Each measurement has a specific set of parameters, some of which are unique to the particular measurement and some of which are drawn from a standard set of parameters. The standard parameters are described here and the unique parameters are described under the appropriate measurement heading.
Page 114 Chapter 6: Using the Main Menus Ultima 500 DSO From this histogram the two peaks corresponding with the Top and the Base of the waveform PT and PB can be identified. The mean of the PT and PB are calculated and taken to be the Top and Base levels respectively.
Page 115 Ultima 500 DSO Chapter 6: Using the Main Menus Measurements – Changing Measurement Parameters The set of Parameters is individual for each Measurement. Parameters, in general, are: • Source(s) • Bounds • References Parameters for any Measurement can be edited after the original Measurement definition is complete.
Page 116 Chapter 6: Using the Main Menus Ultima 500 DSO Source button opens a menu of all relevant sources for easy selection. There can be many different parameters. Parameters More button toggles which parameters are presented for adjustment. In this case, Reference and Bounds parameters are available.
Page 117 Ultima 500 DSO Chapter 6: Using the Main Menus Reference Parameters for this particular Measurement (Amplitude) are: Statistical - per IEEE 1977 standards for waveform measurement (Top and Base determination) Max & Min - to not consider a Top or Base in the measurement.
Page 118 Chapter 6: Using the Main Menus Ultima 500 DSO The setting up of each Measurement is slightly different as each measurement has its own set of parameters: Source type(s), Bounds and References. This section describes the sequence for setting up a typical Measurement.
Page 119 Ultima 500 DSO Chapter 6: Using the Main Menus Once the analysis function is selected: • The menu system becomes dynamic, offering the relevant choices in a progressive sequence. • An Analysis Preview window opens. This 'live action' window displays source traces, resultant traces, custom measurements, XY windows, FFTs, graphs and histograms.
Page 120 Chapter 6: Using the Main Menus Ultima 500 DSO Choose an appropriate source signal using the appropriate menu button or the Cursor 2 control. When the source is Apply selected, click the Back button or use the button to change previous selections.
Page 121 Ultima 500 DSO Chapter 6: Using the Main Menus Measurements – Individual Descriptions L E V E L A T V E R T I C A L C U R S O R S Sources: YT, FFT, Graph, Histogram References: Horizontal Cursors, Ground(Zero), other Measurement YT result: Y value at Cursor position.
Page 122 Chapter 6: Using the Main Menus Ultima 500 DSO L E V E L A T H O R I Z O N T A L C U R S O R S Sources: YT, FFT, Graph, Histogram References: Horizontal Cursors, Ground(Zero), other Measurement YT result: Y value at Cursor position.
Page 123 Ultima 500 DSO Chapter 6: Using the Main Menus H O R I Z A T M A X L E V E L / H O R I Z A T M I N L E V E L...
Page 124 Chapter 6: Using the Main Menus Ultima 500 DSO A M P L I T U D E Sources: YT, Graph References: Top/Base, Max/Min, Cursor positions Bounds: All Data, Between Cursors, other Measurements YT result: a pulse Top minus Base or Max minus Min for selected portion...
Page 125 Ultima 500 DSO Chapter 6: Using the Main Menus P E R I O D / F R E Q U E N C Y / D U T Y C Y C L E Period is the time between at least three crossing points as defined by crossing parameters.
Page 126 Chapter 6: Using the Main Menus Ultima 500 DSO R I S I N G C R O S S I N G / F A L L I N G C R O S S I N G This measurement displays the word AUTO if the trace does not cross the specified level, indicating that the 50% of max/min levels have been used instead.
Page 127 Ultima 500 DSO Chapter 6: Using the Main Menus A C - R M S / D C - R M S AC-RMS is the same as Standard Deviation, used to calculate an AC component by taking the Mean of the trace as reference.
Page 128 Chapter 6: Using the Main Menus Ultima 500 DSO H O R I Z A T T R I G G E R Indicates the time of the Trigger with respect to the beginning of the data. This is very useful when used as part of a boundary (Bounds) for another Measurement (Area, Frequency, etc.) or for making time measurements from...
Page 129 Chapter 6: Using the Main Menus Result Math An exclusive feature of the Ultima 500 is that Measurement results can be used in live math formula. The Page 2 Analysis mode does this with Result Math. Result Math is setup in exactly the same way as Measurements.
Page 130 Chapter 6: Using the Main Menus Ultima 500 DSO Example 1 - Find the phase between an AC voltage and an AC current Get a Rising Crossing on the voltage (zero crossing) provides an X value Get a Rising Crossing on the current (zero crossing) provides another X...
Page 131 Ultima 500 DSO Chapter 6: Using the Main Menus Once the analysis function is selected: • The menu system becomes dynamic, offering the relevant choices in a progressive sequence. • An Analysis Preview window opens. This 'live action' window displays source traces, resultant traces, custom measurements, XY windows, FFTs, graphs and histograms.
Page 132 Chapter 6: Using the Main Menus Ultima 500 DSO Upon choosing FFT, the Analysis Preview window displays the selected source and result window. Select the source from the list of channels, or other resources that had previously been defined, using the appropriate menu button or the Cursor 2 control.
Page 133 Ultima 500 DSO Chapter 6: Using the Main Menus FFT Parameters Parameters for any Measurement can be edited after the original Measurement definition is complete. Select the Measurement to be edited from the list of Definitions using the Cursor 1 control.
Page 134 Chapter 6: Using the Main Menus Ultima 500 DSO Graphs The Graphs function provides a means of live trending of a particular Measurement over time. Graphs can update periodically or with each new acquisition. Any Measurement can be graphed. In some cases there is a level...
Page 135 Ultima 500 DSO Chapter 6: Using the Main Menus Once the analysis function is selected: • The menu system becomes dynamic, offering the relevant choices in a progressive sequence. • An Analysis Preview window opens. This 'live action' window displays source traces, resultant traces, custom measurements, XY windows, FFTs, graphs and histograms.
Page 136 Chapter 6: Using the Main Menus Ultima 500 DSO Select the Measurement to be graphed from the list of resources. Only Measurements are available in this list. Traces cannot be graphed and are grayed out. Use the appropriate menu button or the Cursor 2 control to select the Measurement.
Page 137 Ultima 500 DSO Chapter 6: Using the Main Menus Graphs Parameters Parameters for any Measurement can be edited after the original Measurement definition is complete. Select the Measurement to be edited from the list of Definitions using the Cursor 1 control.
Page 138 Chapter 6: Using the Main Menus Ultima 500 DSO Once the analysis function is selected: • The menu system becomes dynamic, offering the relevant choices in a progressive sequence. • An Analysis Preview window opens. This 'live action' window displays source traces, resultant traces, custom measurements, XY windows, FFTs, graphs and histograms.
Page 139 Ultima 500 DSO Chapter 6: Using the Main Menus Select the Measurement to histogram from the list of resources. Only Measurements are available in this list. Traces cannot be put in a histogram and are grayed out. Use the appropriate menu...
Page 140 Chapter 6: Using the Main Menus Ultima 500 DSO Histogram Parameters Parameters for any Measurement can be edited after the original Measurement definition is complete. Select the Measurement to be edited from the list of Definitions using the Cursor 1 control.
Page 141 Ultima 500 DSO Chapter 6: Using the Main Menus Rename Item / Color Change / Delete Item / Delete All Rename This button opens the and Delete menu. To Rename the definition, Name choose and use the text entry controls.
Page 142 Chapter 6: Using the Main Menus Ultima 500 DSO Name Text Entry Opens the standard menu to allow the entry of a name for the custom analysis being configured. Use the Cursor 1 and Cursor 2 controls as described in the menu or type the entry using a keyboard.
Page 143 Ultima 500 DSO Chapter 6: Using the Main Menus Main Window The result of the analysis definition is put in a default window. Select another window from the list of windows using the appropriate menu button or the Cursor 2 control.
Page 144 Chapter 6: Using the Main Menus Ultima 500 DSO Units and Scaling Analysis Units and Opens the Scaling menu to define the unit and scaling for the selected analysis. Each Analysis result waveform can be scaled with a multiplication factor and given an offset and units.
Page 145: Transfer To Proview
Additional processing is available and sometimes preferable with a PC Analysis Software Package. The Ultima provides the ability to transfer data to the optional Gould ProView analysis and reporting software. Pressing one button transfers all data for additional analysis and reporting.
Page 146: Transfer To Msexcel
Chapter 6: Using the Main Menus Ultima 500 DSO Transfer to MSExcel Additional processing is available using MSExcel. Ultima provides the ability to transfer data to Excel. Pressing one button transfers all data for additional analysis and reporting. Transfer To MSExcel...
Page 147: Transfer Setup
Ultima 500 DSO Chapter 6: Using the Main Menus Transfer Setup Transfer Setup Opens the menu, allowing configuration of the transfer data options. Transfer Area Choose whether to transfer the entire acquisition or just the area bounded between the cursors using the Cursor 2 control.
Page 148 Chapter 6: Using the Main Menus Ultima 500 DSO Auto Transfer Auto Enable and define the Transfer function. Use the Cursor 2 control to choose an option. Turns the Auto Transfer feature off. Every Trigger (On Trigger) Automatically transfers data each time the system is triggered.
Page 149: File Menu
Ultima 500 DSO Chapter 6: Using the Main Menus File Menu File menu contains controls that allow: • Saving of complete Setups/Data • Saving of partial Setups • Recall of saved Setups/Data • Exporting of data • Screen printing • Directory management (create/delete) primarily used to facilitate data storage Version 2.3...
Page 150: Save
Chapter 6: Using the Main Menus Ultima 500 DSO Save Save Choosing initiates a save operation. Data defaults to a subdirectory coded with the time and date. The above time and date code would represent: Year - 2000 (00) Month - December (Dec)
Page 151: Save Format
Ultima 500 DSO Chapter 6: Using the Main Menus Save Format There are two standards for saving the data. Gould DASA Format. DAT and Nicolet Data Format .WFT Both forms can be recalled to Ultima and imported to Proview and imPRESSion.
Page 152: Save As
Chapter 6: Using the Main Menus Ultima 500 DSO Save As Save Opens the menu, allowing selection of: • What to save • Folder Name where the data is to be stored • Folder location where the data is to be stored The browser defines the location for data storage.
Page 153 Ultima 500 DSO Chapter 6: Using the Main Menus Folder Name Text Entry Opens the standard menu to allow changing of the name of the current folder. While mouse and keyboard compatible, this operation can be performed using only the front panel Cursor controls and the vertical menu buttons.
Page 154 Chapter 6: Using the Main Menus Ultima 500 DSO Save Preferences Select what to save using the Cursor 2 control. Traces and Setup – saves the current traces and entire setup. Note that when this option is selected, the other setup options are grayed out.
Page 155: Recall
Ultima 500 DSO Chapter 6: Using the Main Menus Recall Recall Opens the menu to restore previously saved traces and setups. While compatible with a mouse or other pointing device, this classic Windows implementation can be driven completely by the Cursor 1 front panel control.
Page 156 Chapter 6: Using the Main Menus Ultima 500 DSO Recall Traces and Setup Choose to Recall instrument setup, all trace data or both. Sep 17 01,14-56-00 - a complete data set including instrument setup and data. The file name is the date and time code for when it was saved, September , 2001 at 14:56.00 am (24 hour...
Page 157 Ultima 500 DSO Chapter 6: Using the Main Menus Recall Instrument Setup Choose to Recall instrument setup in whole or in part. Setup.ini – instrument setup file. This can be recalled without data, simply to recreate a previous instrument setup.
Page 158 Chapter 6: Using the Main Menus Ultima 500 DSO Recall Trace (Individual) Select a particular trace and destination (Recall Trace To). Ch3_03h.dat – data file for a specific channel or trace. ch is channel, dat is the type of file (data file).Trace designations are:...
Page 159 Ultima 500 DSO Chapter 6: Using the Main Menus Recall Reference Trace Reference Traces are valuable for comparing historical signals to live ones. Any saved trace can be recalled as a Reference Trace. A Reference Trace differs from a regular recalled trace as it:...
Page 160: Export To Folder
Chapter 6: Using the Main Menus Ultima 500 DSO Return To File Exits the current menu and returns to the menu. Export to Folder Export Initiates the operation. Data defaults to a subdirectory coded with the time and date. The above time and date code would represent:...
Page 161: Export As
Ultima 500 DSO Chapter 6: Using the Main Menus Export As… Export Opens the menu to set the parameters for exporting of data. Export Export – performs the operation, to be used after parameters are set below. Choose this option after all parameters are set up.
Page 162 Chapter 6: Using the Main Menus Ultima 500 DSO Folder Name Text Entry Opens the standard menu to allow changing of the name of the current folder. While the Ultima is mouse and keyboard compatible, this operation can be performed using only the front panel Cursor controls and the vertical menu buttons.
Page 163 Ultima 500 DSO Chapter 6: Using the Main Menus Export File Format Select between ASCII Text (TXT) or Nicolet Data Format (WFT) using the appropriate menu button or Cursor 2 control. For more information on WFT or ASCII files, see Appendix C.
Page 164: Print
Chapter 6: Using the Main Menus Ultima 500 DSO Print Allows color or black and white printing of the current Ultima screen to a local or network printer. Adding printers to Ultima is done in a typical WindowsNT fashion: Print...
Page 165 Ultima 500 DSO Chapter 6: Using the Main Menus Color Mode Choose between a Color or Monochrome (black/white) printout. If Color is selected, but printing is done on a black and white printer, gray scaling will occur. To facilitate printing, the background screen color is inverted to white.
Page 166: Folder Utilities
Chapter 6: Using the Main Menus Ultima 500 DSO Folder Utilities Folder Utilities Opens the menu, allowing the creation and removal of sub-directories. 6-116 Version 2.3...
Page 167 Ultima 500 DSO Chapter 6: Using the Main Menus Create New Folder Create New Folder Opens the menu, allowing the creation of a new directory or change the current directory name. It also opens a browse window to navigate where to create or rename a directory.
Page 168 Chapter 6: Using the Main Menus Ultima 500 DSO Change Folder Name Text Entry Opens the standard menu to allow changing of the name of the current folder. While the Ultima is mouse and keyboard compatible, this operation can be performed using only the front panel Cursor controls and the vertical menu buttons.
Page 169 Ultima 500 DSO Chapter 6: Using the Main Menus Delete Folder Select a directory to delete using the Cursor 1 control. When a directory to delete is selected, press the Delete Directory button to delete it. Return To File Exits the current menu and returns to the menu.
Page 170: Utilities Menu
Chapter 6: Using the Main Menus Ultima 500 DSO Utilities Menu The Utilities menu contains controls for: • IRIG Hardware Options • GPIB Hardware Options • System Calibration • General Preferences • Display Preferences • Color Preferences 6-120 Version 2.3...
Page 171: Hardware Options
Ultima 500 DSO Chapter 6: Using the Main Menus Hardware Options Hardware Options Opens the menu, allowing selection/setup of any optional hardware installed, such as: • IRIG Timing • GPIB Setup IRIG Timing IRIG Timing Opens the menu, allowing you to include IRIG time as the trigger time instead of using the time from the internal real time clock.
Page 172 Chapter 6: Using the Main Menus Ultima 500 DSO GPIB Menu GPIB Menu Opens the , displaying the current Primary Address and the EOI settings. The GPIB Primary Address and various GPIB settings can be changed by using the National...
Page 173 Ultima 500 DSO Chapter 6: Using the Main Menus GPIB Configuration To set up the DSO’s GPIB interface as a non-system controller and to change the GPIB Primary Address, follow the steps below. 1. Close all programs including the DSO’s operation software, then double-click on the National GPIB Configuration icon: 2.
Page 174 Chapter 6: Using the Main Menus Ultima 500 DSO 4. Click on the “Software>>” button to expand the software selections. Except for the “Serial Number”, the remaining settings should be configured as shown below. Under the “Advanced Items” section, the check box for “System Controller”...
Page 175: Calibration
Ultima 500 DSO Chapter 6: Using the Main Menus Calibration Calibration Opens the menu, allowing selection of: • Probe Calibration Voltage • Auto Calibration Probe Calibration Voltage Select either 1 or 6 volts to use as the probe calibration voltage using the Cursor 2 control.
Page 176 Chapter 6: Using the Main Menus Ultima 500 DSO Auto Calibration Confirm Opens the Calibration menu, allowing the commencement of calibration Start by choosing the button. To exit without calibrating the Cancel system, choose Once calibration has started, the Start...
Page 177: Preferences
Ultima 500 DSO Chapter 6: Using the Main Menus Preferences Preferences Opens the menu to set the General, Display and Color Preferences of the Ultima system. Version 2.3 6-127...
Page 178 Chapter 6: Using the Main Menus Ultima 500 DSO General Preferences Select General Preferences for the system using the Cursor 2 control. Immediate Action On Button Press – When this feature is on, no menu appears when a button is selected.
Page 179 Ultima 500 DSO Chapter 6: Using the Main Menus Display Preferences Select the Display Preferences using the Cursor 2 control. Trace Annotations – turn on or off the trace annotations that appear at the left corners of the waveform display.
Page 180 Chapter 6: Using the Main Menus Ultima 500 DSO Color Preferences Display Colors Opens the menu, allowing the color change of: • Channel 1 • Channel 2 • Channel 3 • Channel 4 • Graticule • Cursor • Reference Display Item...
Page 181 Ultima 500 DSO Chapter 6: Using the Main Menus Red / Green / Blue Changes the percentage of red, green or blue for the item selected. The change in color for that item can be immediately seen in the display as the color is adjusted.
Page 182 Chapter 6: Using the Main Menus Ultima 500 DSO Blank page. 6-132 Version 2.3...
Page 183: Chapter 7: Setting Triggers
Ultima 500 DSO Chapter 7: Setting Triggers Chapter 7: Setting Triggers Version 2.3...
Page 184: Trigger Level
Chapter 7: Setting Triggers Ultima 500 DSO Trigger Level The trigger level is set by the front panel Level control. This is a continuously variable control. An indication of the trigger level relative to the displayed trace is shown by a T- at the left hand side of the display, or if the trigger level is off the screen, by the small line indicating the relevant direction.
Page 185 Ultima 500 DSO Chapter 7: Setting Triggers Pre-trigger is given as a percentage of screen width and can be set from 0% to 100% in 0.2% steps. While adjusting the percentage, the adjustment briefly pauses at 10% and 50%. With 0% pre-trigger, the trigger point is at the left-hand edge of the screen and 100% pre-trigger puts the trigger point at the right hand edge of the screen.
Page 186: Trigger Menu
Chapter 7: Setting Triggers Ultima 500 DSO Trigger Menu The Ultima has very comprehensive trigger functions, which are accessed by pressing the Trigger Menu button on the Trigger front panel. The menu allows the changing of the Triggering Mode, Source, Coupling and Slope settings. The level and delay are controlled directly from the front panel.
Page 187: Triggering Modes
Ultima 500 DSO Chapter 7: Setting Triggers Triggering Modes Select a triggering mode using the Cursor 2 control. When selecting a mode, a graphic view of that trigger function is displayed in a separate window. The graphics change depending on the selections made for each trigger option.
Page 188 Chapter 7: Setting Triggers Ultima 500 DSO Level Triggering Modes – Edge Trigger Edge Trigger can be used to trigger on an edge, either positive or negative, with pre or post trigger as desired. Version 2.3...
Page 189 Ultima 500 DSO Chapter 7: Setting Triggers Source Using the Cursor 2 control, choose the source from which the trigger circuit takes its input. The trigger source can be any of the instrument’s input channels, an external signal or the AC line voltage.
Page 190 Chapter 7: Setting Triggers Ultima 500 DSO Slope Choose whether the trigger point is on the rising or falling edge of a signal using the Cursor 2 control. A trigger is generated when the selected source signal passes through the chosen trigger level.
Page 191 Ultima 500 DSO Chapter 7: Setting Triggers Level Control Adjusts The simplest way to set both levels is using just the Level control - adjust the Upper Level, push the Level control, adjust the Lower Level. The levels can be readjusted by dragging with a mouse.
Page 192 Chapter 7: Setting Triggers Ultima 500 DSO Trigger When Signal Select whether the trigger occurs when Enters the signal Leaves the band using the Cursor 2 control. Level Triggering Modes – Runt Runt Trigger produces a trigger when Channel 1...
Page 193 Ultima 500 DSO Chapter 7: Setting Triggers Level Control Adjusts The simplest way to set both levels is using just the Level control - adjust the Upper Level, push the Level control, adjust the Lower Level. The levels can be readjusted by dragging with a mouse.
Page 194 Chapter 7: Setting Triggers Ultima 500 DSO Runt Pulse Select whether the trigger occurs when the signal crosses Level B Only Level A Only . Use the Cursor 2 control to make the selection. Level Triggering Modes – Slew Rate...
Page 195 Ultima 500 DSO Chapter 7: Setting Triggers Level Control Adjusts The simplest way to set both levels is using just the Level control - adjust the Upper Level, push the Level control, adjust the Lower Level. The levels can be readjusted by dragging with a mouse.
Page 196 Chapter 7: Setting Triggers Ultima 500 DSO Slope Choose whether the trigger point is on the rising or falling edge of a signal using the Cursor 2 control. A trigger is generated when the selected source signal passes through the chosen trigger level.
Page 197 Ultima 500 DSO Chapter 7: Setting Triggers Pulse Triggering Modes – Divide By N Divide By N trigger produces a trigger every N events. The actual trigger point can be phase slipped so that the trigger occurs earlier or later in the signal cycle.
Page 198 Chapter 7: Setting Triggers Ultima 500 DSO Position Control Adjusts Use the Cursor 2 control on the front panel to select whether the Position control Position Phase adjusts . To change the phase of the trigger Phase point, select Adjustment...
Page 199 Ultima 500 DSO Chapter 7: Setting Triggers Coupling Select the coupling used for the trigger signal using the Cursor 2 control. The hf-rej (high frequency reject) option activates a low pass filter set to 15 kHz. Using this filter is helpful in...
Page 200 Chapter 7: Setting Triggers Ultima 500 DSO Count Select the number of counts (N) used for the trigger. Use the Cursor 2 control or click and drag the slider control using the mouse. Users with a keyboard may enter a value directly.
Page 201 Ultima 500 DSO Chapter 7: Setting Triggers Pulse Triggering Modes – Delay By N Delay By N trigger produces a trigger on the Nth (A or B) trigger event. To start the count, press Single Shot on the front panel. The trigger events are counted from that point.
Page 202 Chapter 7: Setting Triggers Ultima 500 DSO Source Using the Cursor 2 control, choose the source from which the trigger circuit takes its input. The trigger source can be any of the instrument’s input channels or an external signal. The AC LINE signal is neither appropriate nor available here.
Page 203 Ultima 500 DSO Chapter 7: Setting Triggers Slope Choose whether the trigger point is on the rising or falling edge of a signal using the Cursor 2 control. A trigger is generated when the selected source signal passes through the chosen trigger level.
Page 204 Chapter 7: Setting Triggers Ultima 500 DSO Pulse Triggering Modes – Missing Event Missing Event trigger looks for two events occurring within a preset time. If the second event does not occur, a trigger is generated. The two events can be on the same or different input signals.
Page 205 Ultima 500 DSO Chapter 7: Setting Triggers Source Using the Cursor 2 control, choose the source from which the trigger circuit takes its input. The trigger source can be any of the instrument’s input channels or an external signal. The AC LINE signal is neither appropriate nor available here.
Page 206 Chapter 7: Setting Triggers Ultima 500 DSO Slope Use the Cursor 2 control to choose whether the trigger point is on the rising or falling edge of a signal. A trigger is generated when the selected source signal passes through the chosen trigger level.
Page 207 Ultima 500 DSO Chapter 7: Setting Triggers Pulse Triggering Modes – B Gates A Delayed By N B Gates A Delayed By N trigger functions when a B trigger gates the A trigger, which then produces a trigger on the Nth A event after the B trigger has occurred.
Page 208 Chapter 7: Setting Triggers Ultima 500 DSO Source Using the Cursor 2 control, choose the source from which the trigger circuit takes its input. The trigger source can be any of the instrument’s input channels or an external signal. The AC LINE signal is neither appropriate nor available here.
Page 209 Ultima 500 DSO Chapter 7: Setting Triggers Slope Using the Cursor 2 control, choose whether the trigger point is on the rising or falling edge of a signal. A trigger is generated when the selected source signal passes through the chosen trigger level.
Page 210 Chapter 7: Setting Triggers Ultima 500 DSO Pulse Triggering Modes – A Delayed By N Gates B A Delayed by N Gates B trigger functions when the B trigger path is gated by the A trigger. The gate is opened on the Nth A trigger after which the first B trigger is the trigger point.
Page 211 Ultima 500 DSO Chapter 7: Setting Triggers Source Using the Cursor 2 control, choose the source from which the trigger circuit takes its input. The trigger source can be any of the instrument’s input channels or an external signal. The AC LINE signal is neither appropriate nor available here.
Page 212 Chapter 7: Setting Triggers Ultima 500 DSO Slope Using the Cursor 2 control, choose whether the trigger point is on the rising or falling edge of a signal. A trigger is generated when the selected source signal passes through the chosen trigger level.
Page 213 Ultima 500 DSO Chapter 7: Setting Triggers Time Triggering Modes – Pulse Width Pulse Width trigger is used when the width of a pulse is either narrower or wider than a pre-defined time. The trigger point is always on the back edge of the...
Page 214 Chapter 7: Setting Triggers Ultima 500 DSO Source Using the Cursor 2 control, choose the source from which the trigger circuit takes its input. The trigger source can be any of the instrument’s input channels or an external signal. The AC LINE signal is neither appropriate nor available here.
Page 215 Ultima 500 DSO Chapter 7: Setting Triggers Polarity Polarity Select the of the pulse using the Cursor 2 control. Trigger When Change between triggering when the pulse width is less than the preset time, to triggering when the pulse width is greater than the preset time.
Page 216 Chapter 7: Setting Triggers Ultima 500 DSO Time Triggering Modes – Frequency Frequency Trigger occurs when a frequency is either less than or greater than a pre-defined value. The frequency is specified in Hz. Select which trigger system to configure, A or B, using the Cursor 2 control.
Page 217 Ultima 500 DSO Chapter 7: Setting Triggers Source Using the Cursor 2 control, choose the source from which the trigger circuit takes its input. The trigger source can be any of the instrument’s input channels or an external signal. The AC LINE signal is neither appropriate nor available here.
Page 218 Chapter 7: Setting Triggers Ultima 500 DSO Slope Use the Cursor 2 control to choose whether the trigger point is on the rising or falling edge of a signal. A trigger is generated when the selected source signal passes through the chosen trigger level.
Page 219 Ultima 500 DSO Chapter 7: Setting Triggers Time Triggering Modes – Period Period trigger is produced by a period being less than or greater than a pre-defined value. The period is specified in seconds to nanosecond resolution. Version 2.3 7-37...
Page 220 Chapter 7: Setting Triggers Ultima 500 DSO Source Using the Cursor 2 control, choose the source from which the trigger circuit takes its input. The trigger source can be any of the instrument’s input channels or an external signal. The AC LINE signal is neither appropriate nor available here.
Page 221 Ultima 500 DSO Chapter 7: Setting Triggers Slope Use the Cursor 2 control to choose whether the trigger point is on the rising or falling edge of a signal. A trigger is generated when the selected source signal passes through the chosen trigger level.
Page 222 Chapter 7: Setting Triggers Ultima 500 DSO Time Triggering Modes – Skew Skew Trigger responds to the difference in time between two trigger events. The two events, A and B, can be on the same or different input signals. The trigger has two systems, A and B. Each system can be configured separately for source, coupling and slope.
Page 223 Ultima 500 DSO Chapter 7: Setting Triggers Source Using the Cursor 2 control, choose the source from which the trigger circuit takes its input. The trigger source can be any of the instrument’s input channels or an external signal. The AC LINE signal is neither appropriate nor available here.
Page 224 Chapter 7: Setting Triggers Ultima 500 DSO Slope Use the Cursor 2 control to choose whether the trigger point is on the rising or falling edge of a signal. A trigger is generated when the selected source signal passes through the chosen trigger level.
Page 225 Ultima 500 DSO Chapter 7: Setting Triggers Time Triggering Modes – A Delayed By Time Gates B A Delayed By Time Gates B Trigger produces a trigger on the first B trigger that occurs after a preset time following an initial A trigger.
Page 226 Chapter 7: Setting Triggers Ultima 500 DSO Source Using the Cursor 2 control, choose the source from which the trigger circuit takes its input. The trigger source can be any of the instrument’s input channels or an external signal. The AC LINE signal is neither appropriate nor available here.
Page 227 Ultima 500 DSO Chapter 7: Setting Triggers Slope Use the Cursor 2 control to choose whether the trigger point is on the rising or falling edge of a signal. A trigger is generated when the selected source signal passes through the chosen trigger level.
Page 228 Chapter 7: Setting Triggers Ultima 500 DSO TV Triggering Modes – NTSC and PAL (TV) TV Trigger triggers on the selected TV line number. When the TV trigger is in use, the characters "TV" appear on the second line at the left-hand side of the trace display.
Page 229 Ultima 500 DSO Chapter 7: Setting Triggers TV Trigger On Use the Cursor 2 control to set the trigger system to trigger on either a specific TV line number or on sync pulses. If sync pulses are selected, the menu changes as shown here.
Page 230 Chapter 7: Setting Triggers Ultima 500 DSO Source Only Channel 1 can be used for the TV trigger. No other selection is possible. TV Standard Set the trigger system to respond to either PAL or NTSC TV signals using the Cursor 2 control.
Page 231 Ultima 500 DSO Chapter 7: Setting Triggers Acquire Line Number (Line Number Only) Select the required line number. Use the Cursor 2 control or click and drag the slider control using the mouse. Users with a keyboard may enter a value directly.
Page 232 Chapter 7: Setting Triggers Ultima 500 DSO Logic Triggering Modes – Combination Combination Trigger is used to produce a trigger when a particular combination of events occurs. The top line of this menu provides a brief description of the trigger setup.
Page 233 Ultima 500 DSO Chapter 7: Setting Triggers Selection Use the Cursor 2 control to choose the active role of the Channel selected above. Trigger If Use the Cursor 2 control to select the trigger condition for the input channels in use. The...
Page 234 Chapter 7: Setting Triggers Ultima 500 DSO Qualification Select a qualification for the trigger using the Cursor 2 control. The above five trigger conditions can all be qualified by a further condition so that a trigger only occurs if the trigger conditions and the qualification are both met.
Page 235: Chapter 8: Mouse And Keyboard Control
Ultima 500 DSO Chapter 8: Mouse and Keyboard Control Chapter 8: Mouse and Keyboard Control Version 2.3...
Page 236 This chapter illustrates Ultima 500 command and control using a mouse and keyboard. The Ultima 500 is designed for operation without a mouse and keyboard. To offer the user an operation alternative and enhancement of some features, there is a mouse/keyboard implementation of each control.
Page 237: Front Panel Mouse Controls
Ultima 500 DSO Chapter 8: Mouse and Keyboard Control Front Panel Mouse Controls Selected parts of the Status Panel offer direct access mouse control panels: Version 2.3...
Page 238: Channel Controls (& Vertical Zoom)
Chapter 8: Mouse and Keyboard Control Ultima 500 DSO Channel Controls (& Vertical Zoom) Clicking in this Status Panel brings up a Channel Control Panel for the corresponding channel. There is a separate control panel for each channel. Position (p. 4-13) – choose a point in the radial...
Page 239: Timebase And Horizontal Zoom Controls
Ultima 500 DSO Chapter 8: Mouse and Keyboard Control Timebase and Horizontal Zoom Controls Clicking in this Status Panel brings up the Timebase and Horizontal Zoom Control Panel. Time (4-5) – choose a point in the radial that differs from the...
Page 240: Trigger Controls
Chapter 8: Mouse and Keyboard Control Ultima 500 DSO Trigger Controls Clicking in this Status Panel brings up the Trigger Control Panel. Position (p. 4-15) – choose a point in the radial that differs from the current position (white indicator) to adjust the Pre- and Post- Trigger Position, or drag the indicator around the dial for coarse adjustment.
Page 241: Using Mouse Control Panels
Chapter 8: Mouse and Keyboard Control Using Mouse Control Panels In the Ultima 500, when control panels are active, some display obstruction does occur. When controlling the Ultima over a network, a larger display offers the ability to position the control panels outside of the Ultima display, eliminating all display obstructions.
Page 242: Arranging Control Panels
Chapter 8: Mouse and Keyboard Control Ultima 500 DSO Arranging Control Panels The default position for the Channel Control Panels are: Channels 1 and 2 to the left Channels 3 and 4 to the right The control panels are not sizable, but can be re-positioned.
Page 243: Special Ultima Mouse Controls
Ultima 500 DSO Chapter 8: Mouse and Keyboard Control Special Ultima Mouse Controls Right Click Copy A right click on the mouse when the pointer is in the trace display area opens a short option box. Copy Screen To Clipboard – places a screen...
Page 244: Trace Position
Chapter 8: Mouse and Keyboard Control Ultima 500 DSO Trace Position To position a trace with a mouse, place the mouse pointer on the M for MAIN or Z for ZOOM trace, click and hold the mouse button and drag the marker (M or Z) to its new position, releasing the mouse button when finished repositioning the cursor.
Page 245 Ultima 500 DSO Chapter 8: Mouse and Keyboard Control After dragging over the area to be ZOOMed, the display opens a ZOOM trace near (but not exact) to the area defined by the drag. Note the gray bar above the MAIN trace, representing the location and size of the ZOOM trace.
Page 246: Conventional Mouse And Keyboard Controls
Chapter 8: Mouse and Keyboard Control Ultima 500 DSO Conventional Mouse and Keyboard Controls In the classic Windows conventions, the mouse and keyboard are used to perform various control functions, including: Save and Recall of data, instruments setups, etc. While designed for a mouse or other...
Page 247: Chapter 9: Tutorial
Ultima 500 DSO Chapter 9: Tutorial Chapter 9: Tutorial Version 2.3...
Page 248: Exploring The Ultima 500 Front Panel
Ultima 500 …a tutorial. The Ultima 500 is an all-new concept oscilloscope designed to take the hard work out of waveform capture, analysis and data handling. This tutorial identifies and exercises the controls, making familiar the capabilities of the Ultima 500.
Page 249: A - Power Up
Ultima 500 DSO Chapter 9: Tutorial A - Power Up 1. Connect the power cord to the rear of the Ultima. Connect to a power source. Connect a keyboard and mouse (optional, not required for oscilloscope operation). 2. Turn on the power by pressing the front panel Power On button.
Page 250 Chapter 9: Tutorial Ultima 500 DSO A - Power Up – continued 3. After booting up, the Ultima displays a splash screen, then a display setting similar to the one shown below. (The Ultima status will be exactly the same as when the instrument was powered off.)
Page 251 Ultima 500 DSO Chapter 9: Tutorial A - Power Up – continued Main Menu File Recall... Recall Setup Preferences) 4. Recall Default Setup. ( Turn Off All Instrument Turn On All Default 5. Select Recall Default Setup. Recall Default Setup popup should appear for approximately 5 seconds.
Page 252: B - Obtaining A Display
Chapter 9: Tutorial Ultima 500 DSO B - Obtaining a Display 1. Press the Auto Setup button and confirm by Start Auto Setup pressing (the top menu button). Auto Setup automatically turns off those channels where no signal is present and then adjusts the scaling, timebase and trigger conditions appropriately for the channels that have a signal.
Page 253: C - Viewing A Signal Using The Front Panel Controls
Ultima 500 DSO Chapter 9: Tutorial C - Viewing a Signal Using the Front Panel Controls Note : The following setup procedure is basic in nature. It assumes that some features, such as averaging Status and advanced trigger modes, are not active. The trigger mode should be set to Edge, as denoted in the Panel at the bottom of the display.
Page 254: D - Setting The Trigger
Chapter 9: Tutorial Ultima 500 DSO D - Setting the Trigger Trigger 1. Open the menu (the only menu that has a designated front panel button). Edge, CH1, AC Coupling 2. Select Positive Slope. 3. Adjust the front panel LEVEL control so the indicator above the control is constantly illuminated.
Page 255: E - Pre And Post Trigger
Ultima 500 DSO Chapter 9: Tutorial E - Pre and Post Trigger Pre- and Post-trigger move the trigger point on screen. Setting a Pre- or Post-trigger moves the signal in the X-direction (left and right). This movement is denoted by an "M" at the bottom of the screen.
Page 256: F - Selecting A Display
Chapter 9: Tutorial Ultima 500 DSO F - Selecting a Display Window Layout offers a number of window selections. Note: Main Zoom For full impact, it is recommended to turn ON all channels and enable Zoom ( indicators both illuminated) before performing this procedure.
Page 257: G - Zoom Control
Ultima 500 DSO Chapter 9: Tutorial G - Zoom Control Zooming is a way of seeing detail within a signal. It is effectively another timebase and especially useful when a deep Memory Length is used. 1. Make sure that Main and Zoom are both ON, and that all channels are ON.
Page 258: H - Cursors
Chapter 9: Tutorial Ultima 500 DSO H – Cursors 1. Press the Trace Select button on the front panel (cursor section). Repeated pressing will toggle cursors through Channel 1, 2, 3, 4 and OFF. If a channel is OFF, Trace Select skips it.
Page 259 Ultima 500 DSO Chapter 9: Tutorial H – Cursors – continued Bring Cursors On Screen 5. The command is very useful for locating and positioning cursors in zoomed windows. Display Main Page 1 Window Layout 6. Select from the menu and change...
Page 260: I - Capture
Chapter 9: Tutorial Ultima 500 DSO I – Capture Oscilloscopes can be used to display live signals and to capture data. Capturing data can be controlled manually as follows: 1. Press Run/Stop (top of the front panel) to capture and hold the current waveform(s). The Stored indicator illuminates to indicate that the data has been stored.
Page 261: J - Using The Ultima Menus
Ultima 500 DSO Chapter 9: Tutorial J – Using the Ultima Menus Menus can be driven by the front panel bezel buttons or with a mouse. Either way, the procedure is the same. Text and data entry is done with the Cursor controls or a keyboard.
Page 262: K - Conditioning A Channel
Chapter 9: Tutorial Ultima 500 DSO K - Conditioning a Channel 1. The Channel controls adjust the Y axis parameters. The Channel Menu allows modification of Y parameters for each of the four channels. Main Menu Channel Select Channel 2. Select the channel to modify by choosing...
Page 263: L - Acquisition
Ultima 500 DSO Chapter 9: Tutorial L – Acquisition This menu adjusts Resolution, Memory Length and other acquisition parameters. Memory Length Fixed 1. Set the to 50,000 and turn Memory (Main Menu / Acquisition / OFF. Memory Length / Fixed Memory)
Page 264: M - Snapshot Measurements (Page 1 Only)
Chapter 9: Tutorial Ultima 500 DSO M – Snapshot Measurements (Page 1 only) Ultima offers two measurement facilities, Snapshot Measurements and Analysis (custom) Measurements. Snapshot Measurements are designed to be highly accessible and easy to turn ON and OFF. Snapshot Measurements only work in Page 1 mode.
Page 265: N - Math
Ultima 500 DSO Chapter 9: Tutorial N - Math on Page 2 Page 2 contains the more complex custom measurement and analysis functions typically found only on the higher end ‘Performance DSOs.’ All analysis and custom measurements are managed within one list. Preview Windows assist the analysis setup process.
Page 266 Chapter 9: Tutorial Ultima 500 DSO N - Math on Page 2 – continued 6. While in the Analysis Preview Window, the result trace can be scaled and positioned using the front panel Channel 1 SCALE and POSITION controls. These controls will not perform on Channel 1 until the Analysis Preview Window is closed.
Page 267 Ultima 500 DSO Chapter 9: Tutorial N - Math on Page 2 – continued Main Menu / Display / Page 2 Window Layout. 10. Select 11. Choose the appropriate display format to include the windows chosen during the Analysis setup (if necessary, return to the Analysis setup and redefine the Main Window and Zoom Window selections).
Page 268: O - Save Data
Chapter 9: Tutorial Ultima 500 DSO O – Save Data The ability to save data is critical to most oscilloscope users. That’s why Ultima offers unparalleled flexibility in the saving of data. There is complete control over: • What can be saved - traces and/or setup, in whole or in part.
Page 269: P - Recall Data
Ultima 500 DSO Chapter 9: Tutorial P – Recall Data Main Menu / File / Recall. 1. Select 2. Identify the folder from which data is to be recalled in much the same fashion as the Save operation previously performed.
Page 270 Chapter 9: Tutorial Ultima 500 DSO Q - XY Display – continued 7. Varying the Horizontal Zoom Factor (press Time/Div and adjust) and Zoom Position (adjust the Horizontal Position while in Zoom Set Mode) allows isolation of single cycles in the YT and XY windows.
Page 271: R - Advanced Analysis - Filter
Ultima 500 DSO Chapter 9: Tutorial R - Advanced Analysis - Filter Filtering can be set up using the Wizard. 1. Setup a filter on Channel 1. Main Menu / Math / Page 2 Analysis Setup / Insert New Function / Analysis Type - Trace Math (set by default) /...
Page 272: S - Advanced Analysis: Custom Measurements, Histograms And Graphs
Chapter 9: Tutorial Ultima 500 DSO S - Advanced Analysis: Custom Measurements, Histograms and Graphs Histograms and Graphs can be set up using the Wizard. The Histogram function performs a statistical analysis on a measurement. The result is a live histogram measurement display of the selected channel.
Page 273 Ultima 500 DSO Chapter 9: Tutorial S - Advanced Analysis: Custom Measurements, Histograms and Graphs – continued 4. The Analysis Preview Window shows the live Histogram waveform. This Histogram is extremely narrow due to the repetitive nature of the signal, thus the non- variation in the Peak To Peak Measurement.
Page 274 Chapter 9: Tutorial Ultima 500 DSO Special Mouse Functions • Waveforms can be moved by dragging the trace markers on the left of the screen. • Pre-trigger can be moved by dragging the “M” marker at the bottom of the screen.
Page 275: Chapter 10: Using The Datasentry Option
Ultima 500 DSO Chapter 10: Using the DataSentry Option Chapter 10: Using the DataSentry Option Version 2.3 10-1...
Page 276: Using The Datasentry Window
Chapter 10: Using the DataSentry Option Ultima 500 DSO DataSentry is an optional application you can purchase for your system to alert you when important test data occurs or to quickly gather waveform information, allowing unattended operation of your system. A Windows program, DataSentry is closely linked to the main oscilloscope application using the COM interface.
Page 277: Stop
Ultima 500 DSO Chapter 10: Using the DataSentry Option Stop Stops system monitoring by DataSentry. Hide Switches to the DataSentry Monitor Display, which enables the oscilloscope display to be observed while at the same time having a display of DataSentry activity.
Page 278: Start Time Panel
Chapter 10: Using the DataSentry Option Ultima 500 DSO Start Time Panel The Start Time panel sets, enables and displays the initial start up time. Time Selecting the checkbox enables the preset start time and date, which must be done before starting DataSentry.
Page 279: Master Condition Panel
Ultima 500 DSO Chapter 10: Using the DataSentry Option Master Condition Panel This panel contains controls that allow you to set up the gating Time, Wait for Acquisition and Measurement Conditions. Time - enables regular intervals or specified times to start actions.
Page 280 Chapter 10: Using the DataSentry Option Ultima 500 DSO Time Setup Dialog Every – runs DataSentry at equal timed intervals. Set time intervals up to a maximum of 23 hours 59 minutes and 59 second periods using the keyboard for direct entry or using the mouse and clicking the up/down arrows.
Page 281 Ultima 500 DSO Chapter 10: Using the DataSentry Option Measurement Conditions Setup Dialog The Measurement Conditions Setup dialog contains a list of measurement conditions that are being tested. When the list is shown for the first time or following a reset to defaults, it will be empty.
Page 282: Actions Panel
Chapter 10: Using the DataSentry Option Ultima 500 DSO When Double click on to set whether the measurement condition should be Inside or Outside Add/Edit limits or click to select and use the button. Low Limit Double click on to add a low limit measurement or click to select and then use Add/Edit button.
Page 283 Ultima 500 DSO Chapter 10: Using the DataSentry Option Browse for Folder Dialog Select a folder and the data will be saved with date and time under the selected path. Note the data format is defined by the setting under the File menu in the main instrument application. The alternative formats are WFT and DAT.
Page 284 Chapter 10: Using the DataSentry Option Ultima 500 DSO E-Mail Setup Dialog SMTP server - enter your local server address or machine name for Simple Mail Transfer Protocol (SMTP). (Refer to your local network administrator.) Destination address - enter the e-mail address of the intended recipient.
Page 285: Termination Condition Panel
Ultima 500 DSO Chapter 10: Using the DataSentry Option Termination Condition Panel The Termination Condition can be set to a number of acquisitions, the measurement conditions being met, reaching the set time duration, or reaching a set end time (or a combination of conditions).
Page 286 Chapter 10: Using the DataSentry Option Ultima 500 DSO Blank page. 10-12 Version 2.3...
Page 287 Ultima 500 DSO Appendix A: Connector Pinouts and Driver Circuit Appendix A: Connector Pinouts and Driver Circuit Version 2.3...
Page 288: Driving The External Clock Input
Appendix A: Connector Pinouts and Driver Circuit Ultima 500 DSO Driving the External Clock Input Driving the External Clock The external clock input expects a TTL level. The input is designed to accept a drive signal from bus and line drivers.
Page 289: I/O Connector
Probe power is fitted to the instrument at the back of the unit in the form of an eight way mini-din probe power socket. The socket provides approximately ± 11 V at up to 800 mA. This supply is suitable only for powering Gould active probes (a maximum of four) and should not be used for any other purpose.
Page 290: Video Output Option
Appendix A: Connector Pinouts and Driver Circuit Ultima 500 DSO Video Output Option On the rear panel of the instrument is a 15 way high density D-type connector conforming to standard VGA pinout configuration. The output signal is a standard 800 x 600 pixel Super VGA signal with the colors the same as on the oscilloscope's display.
Page 291 Ultima 500 DSO Appendix B: Windows Task Bar, Printers, and Networks Appendix B: Windows Task Bar, Printers, and Networks Version 2.3...
Page 292: Accessing The Windows Task Bar
Appendix B: Windows Task Bar, Printers, and Networks Ultima 500 DSO Accessing The Windows Task Bar To access the Windows Task Bar, press ‘Ctrl’ and ‘Esc’ simultaneously on the Ultima keyboard. Some Ultima systems may come equipped with a keyboard that includes a Windows key near the space bar.
Page 293 Ultima 500 DSO Appendix B: Windows Task Bar, Printers, and Networks 3. Select ‘My computer’ or ‘Network printer server’ and click Next>. 4. Select the ‘LPT1 port’ and click Next>. For a network printer, the appropriate network identification for the printer must be entered. A network system administrator may need to provide this information.
Page 294: Appendix B: Windows Task Bar, Printers, And Network
Appendix B: Windows Task Bar, Printers, and Networks Ultima 500 DSO 5. Select the manufacturer and model from the Windows list of supported printers and then click ‘Have Disk’ to install the appropriate printer driver for the model selected. Note: Most manufacturers ship printer drivers with the printer or provide drivers from their web site.
Page 295: Installing A Windows Network
Ultima 500 DSO Appendix B: Windows Task Bar, Printers, and Networks Installing a Windows Network Note: READ THIS FIRST Your DSO Windows Workstation is setup as: User Name: administrator Password: ultima If you plan to change the User Name, the new User Name MUST HAVE FULL “administrator rights”...
Page 296 Appendix B: Windows Task Bar, Printers, and Networks Ultima 500 DSO 3. Click on the ‘IP Address’ tab and select the option called ‘Obtain an IP address from a DHCP server’. This enables the Ultima to obtain the IP address automatically from a DHCP server.
Page 297: Appendix C: Export File Format
Ultima 500 DSO Appendix C: Export File Format Appendix C: Export File Format Version 2.3...
Page 298: Ascii Txt Format
Appendix C: Export File Formats Ultima 500 DSO ASCII TXT Format To best facilitate a wide range of destination applications, ASCII data can be exported with a choice of the following delineations: • New Line – a line feed follows each item •...
Page 299 Ultima 500 DSO Appendix C: Export File Format Example 2 – Histogram Description Gould Ultima 500 instrument identification 20:56:36 Thursday November 30 2000 time (H:M:S), date of export Trace Type Histogram histogram data Time of Last Hit 20:54:07 Thursday, November 30, 2000...
Page 300 Appendix C: Export File Formats Ultima 500 DSO Example 3 - Graph Data Description Gould Ultima 500 instrument identification 20:56:36 Thursday November 30 2000 time H:M:S, Date Exported Trace Type GRAPH Graph data Time of Last Value 20:54:07 Thursday, November 30, 2000...
Page 301 Ultima 500 DSO Appendix C: Export File Format Example 4 - FFT Data Description Gould Ultima 500 Instrument type number 21:07:31 Monday December 04 2000 Time H:M:S, Date Exported Trace Type FFTlin Linear or logarithmic frequency scaling Start Frequency FFT frequency at first data point (0)
Page 302: Gould/Nicolet Wft Format
Ultima 500 DSO Gould/Nicolet WFT Format The Ultima 500 exports data in the Gould/Nicolet WFT format. This format is a compact 16- bit binary file format containing an ASCII header to retain scale factors, channel titles, time/date, etc. It is used by Ultima and is supported by a variety of software. Each channel is stored in a separate file of 2-byte integers.
Page 303 Ultima 500 DSO Appendix C: Export File Format point# = Represents the n-th point in a sweep. HORIZONTAL_NORM = Time per point, in seconds. HORIZONTAL_ZERO = Trigger to 1st point, in seconds. USER_HORIZONTAL_NORM = User defined multiplier, unitless (normally 1)
Page 304 Appendix C: Export File Formats Ultima 500 DSO Offset Max. Size Field Description ASCII Data Field Description (Bytes) Type User_vertical_label Character User vertical label: default = "V" User_horizontal_zero Float User time offset User_horizontal_norm Float User seconds per unit User_horizontal_label Character User horizontal label: default = "s"...
Page 305: Gould Dasa Standard Format
Note 2: These fields are presently only in multi-waveform files. Gould DASA Standard Format Gould DASA format uses an extension .DAT within Ultima. The format is used to Save and Recall data. The file layout comprises a header with keys for each set of parameters. Each key begins with an ASCII vertical bar ( | hexadecimal value 7C) immediately followed by a unique key identifier of two upper case alphabetical characters.
Page 306 14= Number of following characters which identifies the text description, (Trace_Type) 0= V/seconds, 1= Graph data, 2= Histogram data, 3= FFT; | NL,1,Ultima 500 1= Key format, Device that acquired the data = Ultima 500 | NO,1,0; 1= Key format, 0= acquired data, 1= Analysis / Calculated data;...
Page 307 Ultima 500 DSO Appendix C: Export File Format | CP,1,1,16,+Y; 1= Key format, 1= Type of processor; (Intel is this case giving data LSB byte first followed by the MSB byte), 16= data bits, Y= Vertical Y axis; | CJ,1,0000001020;...
Page 308 Appendix C: Export File Formats Ultima 500 DSO Blank page. C-12 Version 2.3...
Page 309: Appendix D: Performance Checking
Ultima 500 DSO Appendix D: Performance Checking Appendix D: Performance Checking Version 2.3...
Page 310 Appendix D: Performance Checking Ultima 500 DSO The aim of this section is to verify the major performance specifications of the Ultima. Should any of these parameters fail to be within specification, then it is recommended that the instrument be repaired or re-calibrated as necessary. Return the instrument to your local distributor for repair.
Page 311: Bandwidth
Ultima 500 DSO Appendix D: Performance Checking All Default 6. Turn On Recall Default Setup 7. Select Recall Default Setup 8. The screen should appear for approximately 5 seconds. Bandwidth Equipment Required: • Leveled Signal Generator: Tektronix SG503 or equivalent •...
Page 312 Appendix D: Performance Checking Ultima 500 DSO 5. Adjust the Snapshot Measurements as follows: Page 1 Snapshot Measurements 6. Verify that is turned On. Version 2.3...
Page 313 Ultima 500 DSO Appendix D: Performance Checking 7. Set the amplitude of the signal generator to give 6 divisions at 1.01 MHz or similar reference frequency. The screen should look similar to this: 8. Set the timebase to 2 nS/div.
Page 314 Appendix D: Performance Checking Ultima 500 DSO 9. Increase the frequency of the signal generator until the eak to peak amplitude reduces to 4.2 divisions. 10. The measured frequency should be greater than 500 MHz. Repeat for the other three channel inputs.
Page 315: Trigger Sensitivity
Ultima 500 DSO Appendix D: Performance Checking Trigger Sensitivity Equipment Required: • Leveled Signal Generator: Tektronix SG503 or equivalent • 50 Ω coaxial cable Internal Trigger Source 1. Connect the signal generator to a channel input (set to 50Ω through the coax cable).
Page 316 Appendix D: Performance Checking Ultima 500 DSO External Trigger Source 1. Connect the signal generator to the Channel 1 input (set to 50Ω through the coax cable). 2. Set the Trigger source of the Ultima to EXTernal. This is set by pressing the Trigger Menu button on the Front Panel and choosing Source.
Page 317 Ultima 500 DSO Appendix D: Performance Checking 8. Change signal frequency to 500.1 MHz. 9. Slowly decrease the signal amplitude. Verify that the Ultima triggers until the signal amplitude is <600 mV. 10. Adjust trigger level control to obtain a continuously updating and stable display.
Page 318 Appendix D: Performance Checking Ultima 500 DSO Timebase Calibration Equipment Required: • Time Calibrator: Bradley (Pulsetek) 192, Tektronix TG501 or similar • 50 Ω coaxial cable Procedure: 1. Connect the signal generator to a channel input (set to 50Ω through the coax cable).
Page 319 Ultima 500 DSO Appendix D: Performance Checking Vertical Calibration Equipment Required: • Oscilloscope voltage calibrator (0.25% or better accuracy): Bradley (Pulsetek) 192 or similar • Coaxial cable Procedure: 1. Connect the voltage calibration output of the oscilloscope calibrator to a channel input, which must be set to 1M Ω, through the coax cable.
Page 320 Appendix D: Performance Checking Ultima 500 DSO 8. Verify that the Average button has changed to indicate an Average amount of 10. 9. The Ultima begins collecting ten sweeps and averages them together in order to get a more accurate representation of the signal amplitude. Verify that the amplitude of the averaged signal is within ±2 % of full scale for the voltage input (i.e.
Page 321: Appendix E: Service Information
Ultima 500 DSO Appendix E: Service Information Appendix E: Service Information Version 2.3...
Page 322: Ultima Replaceable Parts
Return Material Authorization (RMA) number. Attach this number to the unit and/or the accompanying paperwork. During the warranty period, the customer pays for shipping to Gould. Gould will pay for the return of the equipment in the same fashion as it was received. Outside the warranty period, a quote will be given.
Page 323 Ultima 500 DSO Appendix E: Service Information Part Number Description 222-924800 ATX MOTHER BD W/ SOUND 222-923200 PROCESSOR INTEL CELERON P533 222-911100 ETHERNET CARD 10/100 3-COM 3C905 163-901200 DISPLAY/HORIZ COLOR NEC NL8060B 163-901100 DISPLAY/HORIZ SVGA NEC 800X600 122-901500 PNR THERMAL CONDUCTIVE ADHESIVE...
Page 324 Appendix E: Service Information Ultima 500 DSO Part Number Description 055-900500 SPRING/INTEGRA HANDLE 460617 053-904200 GSKT/EMI I.S. 0095-1006-00 053-901600 GASKET/EMI SCHLEGEL E1119T 051-902200 BUMPER/INTEGRA FOOT 460495 051-711900 BUMPER/RND .94 .625 #8PL 051-709000 BUMPER/RND .250 .687 GREY #6 SCR 045-902900 KNOB/ULTIMA LG FP (LTP-385)
Page 325: Appendix F: Ultima
Ultima 500 DSO Appendix F: Ultima 500 Specifications Appendix F: Ultima 500 Specifications Version 2.3...
Page 326: Vertical
Appendix F: Ultima 500 Specifications Ultima 500 DSO Vertical BANDWIDTH: (–3 dB) DC Coupled: DC to 500 MHz AC Coupled: 4 Hz to 500 MHz BANDWIDTH LIMITS: 200 MHz, 20 MHz, 1 MHz SENSITIVITY RANGE: 2 mV/div to 5 V/div in a 1-2-5 sequence ×...
Page 327: Trigger
Ultima 500 DSO Appendix F: Ultima 500 Specifications SEGMENTATION: In 2, 5, 10 steps to 2000 @ 500 word minimum ×2 to ×4000 (×2 to ×20,000 with 1 Mword) ZOOM: TIMEBASE ACCURACY: ± 10 ppm TIME RESOLUTION: 0.0005% of full scale (200 kword memory)
Page 328: Display
Appendix F: Ultima 500 Specifications Ultima 500 DSO DELAY BY N: Trigger after N events, 2 to 9999 counts DIVIDE BY N: Trigger every N events, 2 to 9999 counts SLEW RATE > or < time to pass through A and B levels...
Page 329: Data Storage
Ultima 500 DSO Appendix F: Ultima 500 Specifications Data Storage Recorded Traces and Setups in whole or in part. Stored data is stamped with time and user defined labels. Export of data in differing file formats. INTERNAL HARD DISK: > 10 Gbyte FLOPPY DISK: 3.5"...
Page 330: Analysis
Appendix F: Ultima 500 Specifications Ultima 500 DSO Analysis TRACE MATHS: Add, Subtract, Multiply, Divide, Invert, Filter, Integrate, Differentiate, XY of any two inputs, FFT (windows are Hanning or Rectangular, scaling is linear or Log, averaging is none up to 100) .
Page 331: General Characteristics
Ultima 500 DSO Appendix F: Ultima 500 Specifications General Characteristics VOLTAGE: 90 - 265 V FREQUENCY: 45 - 400 Hz POWER: 350 W max, 250 W typical WEIGHT: Net Weight: 12.2 kg (27 Ib) approx Shipping Weight: 14.0 kg (31 Ib) approx 449 ×...
Page 332 Appendix F: Ultima 500 Specifications Ultima 500 DSO Blank page. Version 2.3...
Page 333: Index
Ultima 500 DSO Index Index A Delayed By N Gates B Trigger, 7-28 Calibration, 6-121, 6-125 A Delayed By Time Gates B Trigger, 7-45 Calibration Menu, 6-121, 6-125 AC, 4-16 Auto-Calibration, 6-126 Accumulate Over Time, 6-37 Probe Calibration Voltage, 6-125...
Page 334 Index Ultima 500 DSO Channel Variable Gain Menu, 6-10 Time Setup Dialog, 10-6 Return To, 6-11 Window, 10-2 Variable Gain, 6-11 DC, 4-16 Variable Gain Enable, 6-11 Decay by Sweeps, 6-37 Channels, 7-52 Decay Mode, 6-36 Color Mode, 6-115 Delay, 7-47, 7-51...
Page 335 Ultima 500 DSO Index Export, 6-110 Export As, 6-111 General Preferences, 6-128 Export File Formats, C-1, C-2 Gould DASA Standard Format, C-9 WFT, C-6 Gould High Resolution System, 6-15 Export Menu Gould/Nicolet WFT Format, C-6 Change Folder Name, 6-112 Graphs, 6-86...
Page 336 Index Ultima 500 DSO Insert New Function, 6-43 Area, 6-73 FFT, 6-82 Count, 6-77 Graphs, 6-86 FFT Harmonic, 6-78 Histogram, 6-89 Horiz at Trigger, 6-78 Measurements, 6-62 Horiz at Vertical Cursors, 6-71 Result Math, 6-80 Individual Descriptions, 6-71 Trace Math, 6-45...
Page 337 Ultima 500 DSO Index Mouse Controls, Special Polarity, 7-33 Cursor Position, 8-9 Position, 4-6, 4-12, 4-13, 4-15, 7-2, 7-3, Right Click Copy, 8-9 7-16, 7-48 Trace Position, 8-9 Trigger, 4-12 Trigger Level Position, 8-10 X Zoom, 4-13 X Axis Zoom Control, 8-10 Position –...
Page 338 Index Ultima 500 DSO Recall Menu Auto-Setup, F-4 Recall Instrument Setup, 6-107 Data Storage, F-5 Recall Reference Trace, 6-109 Display, F-4 Recall Trace (Individual), 6-108 Engineering Scaling, F-6 Recall Traces and Setup, 6-106 Environmental Characteristics, F-6 Return To, 6-110 General Characteristics, F-7...
Page 339 Ultima 500 DSO Index Transfer Setup Menu, 6-97 Triggering Modes, Time Auto-Transfer, 6-98 A Delayed By Time Gates B, 7-45 Return To, 6-98 Frequency, 7-34 Period, 7-37 Transfer Area, 6-97 Pulse Width, 7-31 Transient / Capture Ranges, 4-7 Skew, 7-41...
Page 340 Index Ultima 500 DSO X Axis Zoom Ratio, 5-3 Zoom Bar, 4-12, 4-13 X Zoom Factor, 4-12 Zoom Display, 4-11, 6-29, 6-34 Zoom Set, 4-12, 4-13, 4-14, 4-15 Zoom trace, 4-12, 6-27, 6-28, 6-29, 6-34, Y Zoom, 4-14, 4-15 Zoom Window, 6-93...

Gould Ultima 500 User Manual

Chapter 1: Safety Messages

Chapter 2: About this Manual

Chapter 3: Introduction

Chapter 4: Using the Front Panel Controls

Chapter 6: Using the Main Menus

Chapter 7: Setting Triggers

Chapter 8: Mouse and Keyboard Control

Chapter 9: Tutorial

Chapter 10: Using the Datasentry Option

Appendix B: Windows Task Bar, Printers, and Network

Appendix C: Export File Format

Appendix D: Performance Checking

Appendix E: Service Information

Appendix F: Ultima

Quick Links

Need help?

Questions and answers

Related Manuals for Gould Ultima 500

Summary of Contents for Gould Ultima 500

Table of Contents
