AUTOMATIC TECHNOLOGY AUSTRALIA PTY LTD
Pro Series 2160v2
COMMERCIAL ROLLER
SHUTTER OPENER
OWNERS COPY
Installation Instructions
NOTE: A Photo Electric Beam
Sensor must be fitted with this
opener. Failure to comply will
void the warranty and may cause
serious personal injury and/or
property damage.
WARNING
It is vital for the safety of persons to follow all
instructions. Failure to comply with the installation
instructions and the safety warnings may result in
serious personal injury and/or property and remote
control opener damage.
Please save these instructions for future reference.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Axess Pro Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Automatic Technology Australia Axess Pro Series

  • Page 1 AUTOMATIC TECHNOLOGY AUSTRALIA PTY LTD Pro Series 2160v2 COMMERCIAL ROLLER SHUTTER OPENER NOTE: A Photo Electric Beam Sensor must be fitted with this opener. Failure to comply will void the warranty and may cause serious personal injury and/or property damage.

  • Page 3: Table Of Contents

    WARRANTY AND EXCLUSION OF LIABILITY Automatic Technology Australia Pty Ltd to the extent that such may be lawfully excluded hereby expressly disclaims all conditions or warranties, statutory or otherwise which may be implied by laws as conditions or warranties of purchase of...
  • Page 4 PLEASE READ THESE IMPORTANT SAFETY RULES Warning - It is vital for the safety of persons to follow all instructions. Failure to comply with the following Safety Rules may result in serious personal injury and/or property damage. For SAFETY protection a Photo Electric Beam MUST The opener is not showerproof - it should not be be fitted with this opener.

  • Page 5: Features

    FEATURES Thank you for purchasing the ATA Axess HOPPING CODE TRANSMITTERS EXTENSIVE OPERATING MODES Automatic Opener. This opener is The opener incorporates a hopping code V I A C O N T R O L I N P U T S A N D designed to suit commercial heavy duty remote control receiver.

  • Page 6: Product Description

    PRODUCT DESCRIPTION The ATA Axess Roller Shutter Opener consists of FIG. 1 one drive unit, Logic control box, and two PTX-4 keyring transmitters. LOGIC CONTROLLER Housed in a commercial heavy duty enclosure is a set of magnetic contactors and intelligent logic controller. A 415V three phase power is required direct connection.
  • Page 7 DRIVE UNIT INSTALLATION MOUNTING THE DRIVE UNIT The mounting plate holes are slotted for fine adjustment of the 3. Mount the base plate to door bracket either by welding in output gear position. Follow the procedure below to ensure final place or using M12 hex bolts, washers and nuts.

  • Page 8: Control Board Layout

    CONTROL BOARD LAYOUT FIG. 5 1 & 2. 24VDC output for powering accessories 3A(max) STP Input Jumper (remove when 10 is used) Lock relay output N/C contact Console Exit Button Lock relay output COM contact Console Previous Button Lock relay output N/O contact Console Down/Close Button Drive unit connections Console Up/Open Button...

  • Page 9: Wiring Diagram - Three Phase Left Hand Installation

    WIRING DIAGRAM THREE PHASE - LEFT HAND...

  • Page 10: Wiring Diagram - Three Phase Right Hand Installation

    WIRING DIAGRAM THREE PHASE - RIGHT HAND...

  • Page 11: Menu Structure

    MENU STRUCTURE...

  • Page 12: Initial Electrical Installation

    INITIAL ELECTRICAL INSTALLATION CAUTION: CABLES WHICH HAVE A GREEN/YELLOW COLOURED INSULATION ARE FOR EARTHING PURPOSES ONLY. NEVER USE THESE CABLES FOR ANY OTHER PURPOSE. STEP 1. INSTALLING ANTENNA STEP 2. SELECTING LEFT OR RIGHT HAND If the installation requires remote transmitters, an external anten- INSTALLATION.

  • Page 13: Setting Travel Limits

    SETTING TRAVEL LIMITS This section shows how to set the travel limits. The procedure can be partly completed using a transmitter. In order to use a transmitter it must first have at least one of its buttons coded to the gate controller. The function assigned to the transmitter's buttons is of no concern here as the buttons are temporally assigned to OPEN, CLOSE and SET.
  • Page 14 SETTING TRAVEL LIMITS STEP 4. SETTING CLOSE TRAVEL LIMIT FIG. 15 To CLS Limit, 1. Press CLOSE to move door to the desired CLOSE LIMIT. / / \ \ \ \ / / (Or Press button 4 on transmitter) (Fig. 15). Adjust, 2.

  • Page 15: Setting Pedestrian Position

    SETTING PEDESTRIAN POSITION FOR OPENERS WITHOUT AN ENCODER FITTED. FIG. 18 MENU 10.2 Set Pedestrian Note: Before setting the pedestrian access position the door must be in the fully closed position. As with the Setting Travel Limit procedure, a transmitter can be used to complete the pedestrian position setting procedure.

  • Page 16: Description Of Standard Operation

    DESCRIPTION OF STANDARD OPERATION This section describes the standard operation of the control board PEDESTRIAN ACCESS (PED) FUNCTION with the factory set default values. (Activated by PED terminal with N/O switch or by transmitter button with PED Function assigned). MOTOR CONTROL. The pedestrian access operation partly opens the door allow The controller drives the motor in the appropriate direction as pedestrian access but prevent vehicle access.

  • Page 17: Control Board Adjustments

    CONTROL BOARD ADJUSTMENTS The opener’s standard operation can be altered by editing various parameters. This section describes the parameters and the effect they have. Use the VIEWING AND EDITING PARAMETER PROCEDURE on Page 20 to make changes. MENU 3 - AUTO-CLOSE TIMES The auto-close modes automatically close the door after it has been operated.

  • Page 18: Menu 4 Lock Times

    CONTROL BOARD ADJUSTMENTS MENU 4 - LOCK TIMES Lock output can be programmed for both hold and pulse door motor starting. The operation of the lock can be programmed operation and can also be programmed to activate prior to the to behave differently on open cycle to that on close cycles.

  • Page 19: Menu 7 Operating Modes

    CONTROL BOARD ADJUSTMENTS MENU 7 - OPERATING MODES P.E INPUT RESPONSE MODE ACTIVITY REPORT ID The P.E input can be configured to respond in one of three modes. This parameter sets the ID of the controller that is sent with the OPEN AND CLOSE CYCLES STOP activity report.
  • Page 20 VIEWING AND EDITING PARAMETER This section illustrates how to locate, view and adjust parameters. LOCATING PARAMETERS RELOAD DEFAULT SETTING Refer to MENU STRUCTURE on Page 9 or the preceding section 1. Press NEXT/PREV buttons to display LOAD DEFAULT for CONTROL BOARD ADJUSTMENTS. Locate the required screen.

  • Page 21: Coding Transmitters

    CODING TRANSMITTER Up to 511 transmitters can be stored within the openers memory. FIG. 23 Each transmitter can be allocated an alpha-numeric ID label up to ID / SN display indicator eleven (11) characters in length and each button can be assigned to I.D Label / Serial Number Store Number one of several control functions.

  • Page 22: Transmitter Edit Procedure

    TRANSMITTER EDIT PROCEDURE EDITING TRANSMITTER SETTINGS FIG. 29 A B SMITH I I D D STEP 1. DISPLAY TRANSMITTER RECORD OSC PED LGT VAC Using one of the methods below, display the required transmitters details. PRESS STEP1. NAVIGATING TO “Edit Transmitter” MENU 1.

  • Page 23: Transmitter List Management

    TRANSMITTER MANAGEMENT The opener provides a transmitter listing facility which enables the Method 2 - Use Transmitter to go Direct to List user to find a transmitter location within memory. Once located a STEP 1 ACCESSING THE LIST MENU stored transmitter can be replaced, deleted, edited, copied or, if the 1.

  • Page 24: Code Operation (Location Empty)

    TRANSMITTERS MANAGEMENT Once the list is displayed it can be sorted by Store number, ID FIG. 42 B B SMITH I I D D Label or Serial Number. Use NEXT or PREV button to select sort- OSC PED LGT VAC ing method.

  • Page 25: Remote Code Set Procedure

    REMOTE CODE SET PROCEDURE If a transmitter is already coded into the opener, additional FIG. 47 transmitters can be coded without being in direct contact with the opener’s control panel. PRESS NOTE: Only the function of the existing transmitter button can be Existing assigned to new transmitter.

  • Page 26: Menu 8.1 Test Inputs

    DIAGNOSTIC TOOLS The controller provides several diagnostic tools from within the FIG. 50 MENU 8 diagnostics menu (menu 8) this section details the function of Diagnostics each tool and its use. NAVIGATING TO DIAGNOSTICS MENU 1. Press PREV to navigate Menu 8 (Fig. 50). 2.

  • Page 27: Menu 8.5 Service Counter

    DIAGNOSTIC TOOLS MENU 8.5 SERVICE COUNTER FIG. 56 Service Counter The opener provides a periodic service counter which can be set to (CYCLES) 60000 expire after a number of drive cycles.When expired, the opener will beep at the beginning of each drive cycle and a message will be displayed on the MAIN SCREEN (Fig.

  • Page 28: Accessories Installation

    ACCESSORIES INSTALLATION This opener does not feature an inherent obstruction FIG. 59 detection (reversing) system. For safety a PE Beam MUST be fitted. FITTING PHOTO ELECTRIC BEAM Locate the Photo Electric (P.E.) Beam in a strategic location in the gateway. ATA recommend that the sensor is placed 150mm above the floor level and as close as possible to the door opening.

  • Page 29: Trouble Shooting Guide

    TROUBLE SHOOTING GUIDE SYMPTOM POSSIBLE CAUSE REMEDY Switch on mains power. Door will not operate. Mains power not switched on. Remove obstruction. Door is obstructed. Unlock door or remove jam. Door is locked or motor jammed. Door requires service/repair by qualified Door tracks/hardware damaged.

  • Page 30: Maintenance Record

    MAINTENANCE RECOMMENDED MAINTENANCE DAILY DUTY RECOMMENDED The door and opener should be inspected and serviced at CYCLES MAINTENANCE regular intervals based on usage. The table at right indicate Over 150 every 1 month ideal maintenance schedules based on duty cycle. 100 - 150 every 2 months The following elements should be examined at each service:...

  • Page 31: Parts List

    PARTS LIST...
  • Page 32 NOTES...

  • Page 33: Warranty And Exclusion Of Liability

    1. This warranty is an addition to any non-excludable conditions or warranties that are implied into this contract by relevant statute, including the Trade Practices Act 1974 (Cth). 2. Subject to all of the matters set out below, Automatic Technology Australia Pty Ltd ("ATA") warrants: (a) the Axess Pro Series Opener for twelve (12) months, (b) all components and accessories for twelve (12) months, from the date of purchase (specified in the sales docket receipt) as free of any defects in material and workmanship.
  • Page 34 17-19 Advantage Rd, Highett, Victoria, Australia 3190 Tel: +61 3 9532 2788 Fax: +61 3 9532 2799 Web: www.ata-aust.com.au Email: sales@ata-aust.com.au © November 2005 Automatic Technology Australia Pty Ltd. All rights reserved. SecuraCode is a registered trademark of Automatic Technology Australia Pty Ltd. ®...
