Summary of Contents for Fideltronik Inigo DTC 400
- Page 1 Relay Control Card DTC 400 User’s Manual The Relay Control Card allows a UPS system to send signals about power system conditions providing galvanic separation V1.0...
- Page 2 www.fideltronikinigo.pl Overview The Relay Control Card offers users the solution for UPS status monitoring via 5 output relays. In addition, the Relay Control Card provides 1 input contact to perform UPS shutdown in battery mode. This card is compatible with UPS devices with expansion slot. Technical Specifications Relay Control Card Electrical...
- Page 3 www.fideltronikinigo.pl Internal Circuit Version DB9 connector Version terminal connectors...
- Page 4 www.fideltronikinigo.pl Relay Control Card Pin out Pin Assignment Function Pin1 UPS FAULT Pin2 SUMMARY ALARM Pin3 GND (Common for Pin4) Power GND Pin4 REMOTE SHUTDOWN Power + Vcc Pin5 COMMON (For Relays) Pin6 BYPASS / UPS OFF Pin7 BATTERY LOW Pin8 UPS ON Pin9...
- Page 5 www.fideltronikinigo.pl Hardware Installation Note: The Relay Control Card is hot-swappable and can be installed while the UPS is on. 1. Remove the two retaining screws from the expansion slot and remove the cover. 2. Install the Relay Control Card into the expansion slot. 3.
- Page 6 www.fideltronikinigo.pl V1.0...
