Summary of Contents for ZowieTek 30411 Series
- Page 1 High Definition Bonding Live Streaming Encoder Quick Start Guide Zowietek Electronics, Ltd. Revision K2.0-A2.5x Release 2020-07-28 Product 30411-XXX...
- Page 2 1. Connections LiveV200 TOP...
- Page 3 LiveV330/350 TOP Live310 TOP Live210 TOP...
- Page 4 Name Icon Description Line In Stereo audio input. SDI Input Connect up to SDI signal. SDI Loop Out Connect a SDI cable from this connector to a monitor or projector. Connect to Internal 4G LTE antenna. Connector DC Power Plug the power supply in here. The port requires a 15V DC Connector power source (center-positive).
-
Page 5: Screen Display
2. Screen Display If LAN, WIFI, 4G network are connected, the screen will display all of the network information. Description The IP address of LAN network The IP address of wireless network HDMI signal input, Display Resolution and Frame Rate of HDMI inputs SDI signal input Display No Signal when the no SDI input or SDI connection fail Display LAN when the LAN connection is successful... -
Page 6: Lan Mode
Time Power Off Hide / Display desktop Hide / Display text and icons on the LCD screen Lock / Unlock screen Video Collage Customize layout, SDI and HDMI dual-channel seamless handover, Picture in picture Menu Setting 3. Quick Start Guide Please follow following steps for quick connection guidance of the encoder. - Page 7 Step 5. After clicking the “RTMP Param” option on the left column of the web control UI, please fill in “RTMP Address” and click “Confirm” button to apply the setting. RTMP Address Step1. Please login your video streaming provider account. Step2.
- Page 8 3. On Web, click “Network”==>”Built-in WIFI”, after clicking the “scan” button, find WIFI name and connect it. 4. After clicking the “Manual Input” button, please enter WIFI “SSID” and “Password” to connect a network. If connect success, the information about the WIFI will be update after clicked “refresh” button. Built-in 4G Plug SIM card and connect antenna to encoder, this page provides users to choose whether to enable built-in 4G network.
- Page 9 APN setting：After clicking the pen icon in the red mark box on above picture, turn off “APN Auto” and fill in “APN”. Please ask your network operator or search online to find the APN of your 4G LTE network. When the APN setting is changed, don’t forget to restart the device to take effect. External 4G Plug USB 4G Dongle into the encoder, device will connect to 4G net automatically.
- Page 10 Bonding mode 1. On LCD, after clicking “Live”, you can turn on/off network bonding mode. 2. Another way, after clicking the “RTMP Param” option on the left column of the web control UI, the “Model” is selected as “Bonding”, the device will bonding multiple connected networks as stream network.
- Page 11 4. Mobile-Phone Backend Setting If you are not carrying or inconvenient for using your computer, you can also choose to configure “QR Code” button on the top your encoder by using your phone's backend settings. Please press of the device to show the QR code at first, in another way, you also can find QR Code in “Menu/Setting—QR Code”.
- Page 12 After logging in to your personal account and entering the interface as shown below, at first, please click on “active now” to bind the device to your account. Next time you can find your device in the list of personal devices. Once you registered your account, you can also login your account at xx.livevbond.com on PC to set encoder.
- Page 13 If you want to know more, you can download the user manual at this link: https://www.zowietek.com/uploads/PortableBondedEncoder/UserManual3.1.pdf...
- Page 14 ZOWIETEK ELECTRONICS, LTD. Address: 2218 HuNan Road, West Wing 17F01, Pudong, Shanghai 201204 P.R.China Tel: +86-21-5027 7371; +86-21-5027 7372 Email: Sales: sales@zowietek.com Marketing: marketing@zowietek.com Support: support@zowietek.com SALES IN USA Security Products International Sales: us@zowietek.com Global Aggregation Server Website: India: in.livevbond.com Europe: eu.livevbond.com...
