DIGITALas D-FORCE INOX ST 6000 Operating Instructions Manual

Tripod Turnstile D-FORCE INOX ST 6000
Note: Before operating this unit, please read this instruction completely.
Thank you for choosing tripod turnstile; this is a product with high technology, so please read
this manual carefully before operation. Please keep this manual for future reference.
Only trained professionals who understand electric and mechanical risk of product are
qualified to install and operate gate system so as to avoid unnecessary dangers caused by
misoperation.
All rights to improve and perfect our products are reserved. We can't promise this
manual is in full accord with the product you receive, but we will check and revise the manual
at regular interval. No further notification will be sent in the case of any modifications to the
manual.

1.Product introduction

1.1 Function Features

(1) Standard signal input port, can be connected with most of the access control board,
fingerprint device and scanner other equipment; (2) Automatic reset function, if people swipe
the authorized card, but don' t pass through within the settled time, it need to swipe card again
for entry; (3) Card-reading Recording function (4) Automatic opening after emergency fire
signal input (5) Anti following : prevent illegal passing (6) High light LED indicator ,
displaying passing status. (7) Normal open can be also controlled via external button or
manual key unlock .(8) Arm will automatically fall down when power failure

1.2 Technical parameter

Item
House
Reliability of the core
Weight
Arm length
Max thrust capacity
Driving force of arms
Driving mode
Direction of rotation
Indicator lamp
Power supply for core：
Operating Instructions
Description
304 stainless steel
3million, no fault
55Kg(bridge type)
510(mm)
60Kg
3Kg
digital
Unidirectional/ Bidirectional (controllable)
Green means passage
AC100~220V
1
