Lean
Wash
Center®
D2
Master
User Manual
serial # D2M–01 00001
Art. no EN31056
Granuldisk AB retains the right to make technical changes to the products.
No responsibility is taken for any printing errors.
www.granuldisk.com
Tel. +46 40 671 50 60

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Lean Wash Center D2 Master and is the answer not in the manual?

Questions and answers

Related Manuals for GRANULDISK Lean Wash Center D2 Master

Summary of Contents for GRANULDISK Lean Wash Center D2 Master

  • Page 1 Lean Wash Center® Master User Manual serial # D2M–01 00001 Art. no EN31056 Granuldisk AB retains the right to make technical changes to the products. No responsibility is taken for any printing errors. www.granuldisk.com Tel. +46 40 671 50 60...

  • Page 3: Table Of Contents

    Contents EC DECLARATION OF CONFORMITY FOR MACHINERY 1 General description and safety 1.1 Notes and warnings 1.2 Technical data D2 Master 1.3 SIMpel — easy access to information 2 Operating 2.1 Control panel 2.2 Start and operation 2.3 Loading washware 3 User settings 4 Daily cleaning 5 Error icons and troubleshooting...

  • Page 5: Ec Declaration Of Conformity For Machinery

    EC DECLARATION OF CONFORMITY FOR MACHINERY Original Directive 2006/42/EC, Annex II 1A Manufacturer (and where appropriate his authorised representative): Representative: Granuldisk Address: Jägershillsgatan 13, 213 75 Malmö Hereby declares that Type of machinery: Ware washing machine for com- mercial kitchens No.

  • Page 7: General Description And Safety

    This manual is your guide for the correct use of Lean Wash Center® D2 Master. Granuldisk recommends that you study the manual thor- oughly to be sure that Lean Wash Center® D2 Master is in- stalled and used correctly and safely.
  • Page 8 1 General description and safety 1.1 Notes and warnings WARNING The following fundamental rules must be observed when using this appliance: • Never use the appliance with bare feet. • Do not put your bare hands into water containing detergent. Wash the hands thoroughly under running water straightaway if by accident this happens.
  • Page 9 1.1 Notes and warnings 1 General description and safety ELECTRICAL Do not use water to extinguish fire on electrical parts. NOTE When cleaning the machine, please follow carefully the in- structions in chapter 4 Daily cleaning. Rev. 2023-05...

  • Page 10: Technical Data D2 Master

    1 General description and safety 1.2 Technical data D2 Master Technical data D2 Master General Design Hood type dishwashing machine Polypropylene dishware washing basket - Polypropylene glassware washing basket. External dimensions External dimensions H x W x D (open and table height 860 mm) 1950 mm x 655 mm (+ handle 100 mm) x 745 mm (+ handle 95 mm) (Standard machine)
  • Page 11 1.2 Technical data D2 Master 1 General description and safety Extends washing cycle by 30 EcoExchanger (option) seconds. Capacity per program 18 Dinner plates or 12 Soup plates Ø 240 mm - 25 Glasses/mugs Ø 90 18 min at 55°C inlet water Start-up time (filling and heating) temperature Water exchange time...
  • Page 12 1 General description and safety 1.2 Technical data D2 Master Drain pump 40 W 800 mm Maximum lift height drain pump DETERGENT & RINSE AID Liquid detergent and rinse aid dosing dispenser with a peristaltic pump are integrated into the machine. NOTE Lean Wash Center®...

  • Page 13: Simpel - Easy Access To Information

    1.3 SIMpel — easy access to 1 General description and safety information SIMpel — easy access to information To make it easier for the operator to find information and how to use the unit there is a QR-code on Lean Wash Center® D2 Master. The sticker is placed in the lower right corner of the hood.
  • Page 14 1.3 SIMpel — easy access to 1 General description and safety information 2 2 When you scan the QR code, you enter the following menu. (Note that the interface may vary depending on the de- vice used). See Fig. 2 Menu Fig.
  • Page 15 1.3 SIMpel — easy access to 1 General description and safety information 5. ABOUT GRANULDISK Link to Granuldisk.com 6. CONTACT INFORMATION Contact information to service partner Rev. 2023-05...

  • Page 17: Operating

    Operating Control panel 1. ON/OFF 2. MENU — to enter the User settings. 3. Arrow UP — to toggle up in the display. 4. Arrow DOWN — to toggle down in the display. 5. CONFIRM 6. If automatic hood: deactivate the hood by pressing the red button on the right side of the panel.

  • Page 18: Start And Operation

    2 Operating 2.2 Start and operation 2.2 Start and operation Switch on the main electrical switch. The display lights up and goes in OFF-mode. If automatic hood: the hood goes down to calibrate. 2 2 Press and hold the ON/OFF button in the upper left corner.
  • Page 19 2.2 Start and operation 2 Operating 4 4 Choose wash program with the buttons UP and DOWN. • Glassware 1 min • Dishware 2 min • Flatware 3 min • Utensils 8 min NOTE 30 seconds will Fig. 5 4 programs be added to each cycle if Lean Wash Cen-...
  • Page 20 2 Operating 2.2 Start and operation • Automatic hood— the hood goes up automatically. • Manual hood— lift up the hood manually. 8 8 If water change is needed, press and hold the ON/OFF button and choose by arrow down “Water change” See Fig.
  • Page 21 2.2 Start and operation 2 Operating NOTE When the unit is not used for 20 minutes (this time can be programmed from the technicians menu) it will enter Standby mode, keeping the temperatures lower to save energy. To exit the function, press any button or open the hood.

  • Page 22: Loading Washware

    2 Operating 2.3 Loading washware 2.3 Loading washware Dishware basket for dinner or soup plates (28148) Capacity: 18 dinner or 12 soup plates ø 240 mm. See Fig. 11 Dishware basket Fig. 11 Dishware basket Glassware basket for glasses and mugs (28149) Capacity: 25 glasses/mugs ø...

  • Page 23: User Settings

    User settings There are in total 6 (six) set- tings that can be changed as an operator of the machine. • Clock • Backlight • Buzzer • Language • Hood type (Auto Start) • Auto Opening (only avail- able on hood type dishwashers) Fig.
  • Page 24 3 User settings Switch off backlight Choose Backlight in the User settings menu with the CONFIRM button. Change the value (in yellow) to NO with the arrows. Confirm with the CONFIRM button. To exit the menu: press the ON/OFF button. Switch off buzzer Choose Buzzer in the User settings menu with the CONFIRM button.

  • Page 25: Daily Cleaning

    Daily cleaning Take out the tank grid (A) and remove the filter (B). See Fig. 15 Remove tank grid and filter Fig. 15 Remove tank grid and filter 2 2 Empty Lean Wash Center® D2 Master by pressing the ON/ OFF button in the upper left corner.
  • Page 26 4 Daily cleaning Emptying and cleaning Lean Wash Center® D2 Master will take about 3 minutes. 4 4 Take out the filter at the bot- tom of the tank. See Fig. 18 Remove the filter Fig. 18 Remove the filter 5 5 Flush and clean the filters and the tank grid.
  • Page 27 NOTE If Lean Wash Center D2 Master is not going to be used for quite some time you have to empty the detergent and rinse aid dispensing device to avoid crystallizations and damages to the pump.

  • Page 29: Error Icons And Troubleshooting

    Error icons and troubleshooting Error icons in the display ERROR ICONS MEANING SOLUTION Low water level in the Check the mains wash tank. water inlet. Press CONFIRM to re- set the count. If the problem persists after switching off and on again, call for technical assistance.

  • Page 30: Troubleshooting

    5 Error icons and troubleshooting 5.2 Troubleshooting 5.2 Troubleshooting PROBLEM POSSIBLE CAUSE POSSIBLE SOLUTION The mains light fails to Mains are not Check the electric switch on. connected. mains connection. The wash cycle fails to The machine has not Wait until the CONFIRM start.
  • Page 31 5.2 Troubleshooting 5 Error icons and troubleshooting The glasses and cut- The rinse aid is unsuit- Check the rinse aid lery are stained. able or is not dis- container and if it is pensed correctly. suitable for the type of mains water.

  • Page 33: Notes

    Notes Rev. 2023-05...
