Nexmosphere XT Series Product Manual

Table of content
1. General
2. Product overview
3. Functionality and API commands
3.1 Push button input
3.2 Button LED control
4. Installation requirements and guidelines
4.1 Connection Diagrams
4.2 Accessories - Push buttons
5. Settings
6. Quick test
7. Appendix
1. General
The XT Push Button interface is a 4-channel push button interface with buttonLED control. Push buttons are a proven
and robust way for users to provide input and navigate through digital content. The XT Push Button interface enables you
to connect up to 4 push buttons per X-talk channel to Nexmosphere's Xperience controllers. This document provides
explanation of the available functionalities and instructions on how to install and integrate push buttons into your digital
signage installation via the XT Push Button interface.
The information in this document is created for users who are familiar with the Nexmosphere API and are able to control a
basic setup with a Nexmosphere API controller. If this is not the case yet, please read the general documentation on the
Nexmosphere serial API first.
2. Product overview
The XT Push Button interface is available in 1 model:
Interface push buttons
Button LED control
Cable length
The XT Push Button interface is a 4-channel push
button interface with buttonLED control. Via JST-PHR-3
connectors, the XT-B4N6 can interface any push button
to the Nexmosphere platform*. Furthermore, the interface
can control 3.3V button LEDs. It can adjust the LEDs of all
four buttons simultaneously or set each button to different
lighting sequences.
*Nexmosphere also offers several push buttons with pre-assembled
cable and connector. See the Accessoires section on page 5 for more
information.
JST-PHR-3 female connectors
N e x m o s p h e r e
L e H a v r e 1 3 6
5 6 2 7 S W E i n d h o v e n • T h e N e t h e r l a n d s
XT-B4N6
✔
✔
180cm
T + 3 1 4 0 2 4 0 7 0 7 0
E s u p p o r t @ n e x m o s p h e r e . c o m
XT RANGE | PUSH BUTTON INTERFACE
XT-B4N6
1 2
XT-B4
