CERTIFICATION: SIRA09ATEX5159X AND IECEx SIR 09.0064X AND ABS 11-LD801943-PDA
II 2 G D Ex emb IIC T4 Gb Ex t IIIC T103oC Db IP66/67 T4 -20 oC to +50 oC
IMPORTANT INFORMATION
The Clarius EP Plus series of explosion protected floodlights are specialist devices, certified for use in
hazardous gas and dust operating environments.
The units must be installed in accordance with these instructions, must be correctly certified for the
specific operating environment and must be installed by suitably qualified personnel.
If you have any queries about the installation or the certification of the unit – please contact GJD for
immediate assistance and advice.
®
Clarius EP PLUS
LED FLOODLIGHT
Installation Guide
www.gjd.co.uk
info@gjd.co.uk
Unit 2 Birch Business Park, Whittle Lane, Heywood, Lancashire, OL10 2SX
CONTENT
1.
SAFETY INSTRUCTIONS
2.
INSTALLATION
3.
MAINTENANCE
4.
TECHNICAL SPECIFICATION
5.
TROUBLE SHOOTING
+44 (0) 1706 363 998
Advertisement
Table of Contents
Related Manuals for CLARIUS EP PLUS IEP-810
Summary of Contents for CLARIUS EP PLUS IEP-810
- Page 1 TROUBLE SHOOTING IMPORTANT INFORMATION The Clarius EP Plus series of explosion protected floodlights are specialist devices, certified for use in hazardous gas and dust operating environments. The units must be installed in accordance with these instructions, must be correctly certified for the specific operating environment and must be installed by suitably qualified personnel.
- Page 2 If the Clarius EP Plus unit is to be installed in areas of high vibration, please consult with GJD. The Clarius EP Plus unit housing is constructed from marine grade aluminium and polycarbonate. The end user must ensure that these materials are suitable for the atmosphere the Clarius EP Plus unit will be installed in.
- Page 3 The mounting bracket for the Clarius EP Plus floodlight is packed separately in the carton. The bolts in the side of the housing shall be removed and used to secure the bracket to the Clarius EP Plus housing. It is very important that the red fibre washers are fitted between the Clarius EP Plus housing and the mounting bracket.
- Page 4 ADDITIONAL IMPORTANT INFORMATION Note: Torque = Newton Meter (Nm) All Clarius EP Plus units have terminal blocks suitable for 4mm2 live, neutral and earth. To maintain an IP rating of 66/67 All M6 socket head cap bolts fixing the polycarbonate lid to the enclosure shall be tightened down to 2.5 Nm.
- Page 5 3. MAINTENANCE Isolate the Clarius EP Plus unit from the mains supply and allow it to cool before carrying out any maintenance work. In the unlikely event of the failure of a string of LED’s (6 or 8), the assembly must be re placed.
- Page 6 Ordering codes Clarius EP Plus Floodlight Infra Red MODEL NUMBER WAVELENGTH ANGLE DISTANCE IEP-810 850nm 150m 492ft 85ft IEP-830 850nm 262ft 137ft IEP-860 850nm 184ft 210ft IEP-810-PC 850nm 150m 492ft 85ft IEP-830-PC 850nm 262ft 137ft IEP-860-PC 850nm 184ft 210ft White Light...
