Summary of Contents for EGO 55 Series
- Page 1 product operating instruction E.G.O. Germany (E.G.O. Elektro-Gerätebau GmbH) Operating Instructions Thermostats 55.xxxxx.xxx / 56.xxxxx.xxx 90.60145.653-001-02-A E.G.O. Elektro-Gerätebau GmbH Blanc-und-Fischer-Platz 1 - 3 75038 Oberderdingen Germany...
- Page 2 product operating instruction E.G.O. Germany (E.G.O. Elektro-Gerätebau GmbH) document id.: 90.60145.653-001-02-A / state: 230 - released page 2 of 19 designation: Thermostats 55.xxxxx.xxx / 56.xxxxx.xxx...
-
Page 3: Table Of Contents
product operating instruction E.G.O. Germany (E.G.O. Elektro-Gerätebau GmbH) Table of contents About these operating instructions ................. 5 Validity ........................... 5 Handling of these operating instructions ............... 5 Revisions ........................5 Other applicable documents ..................5 Symbols and markings ....................6 Safety ......................... - Page 4 product operating instruction E.G.O. Germany (E.G.O. Elektro-Gerätebau GmbH) Mechanical installation ....................14 4.1.1 Basic information on installation ..............14 4.1.2 Sensor mounting .................... 14 4.1.3 Fasten thermostat inside the housing ............14 Regulation ........................14 4.2.1 With adjustable thermostats: set the switch-off temperature ......14 Electrical connection ....................
-
Page 5: About These Operating Instructions
product operating instruction E.G.O. Germany (E.G.O. Elektro-Gerätebau GmbH) About these operating instructions Validity These operating instructions are for the following material number range of thermostats: 55.xxxxx.xxx 56.xxxxx.xxx Handling of these operating instructions These operating instructions are part of the product and describe the intended use of the product. Read these operating instructions, especially the safety instructions, carefully before use. -
Page 6: Symbols And Markings
product operating instruction E.G.O. Germany (E.G.O. Elektro-Gerätebau GmbH) Symbols and markings Symbols Meaning Requirement of an action One-step action Measure to avoid a hazard in a warning Step within a multi-step action list Keep order ... -
Page 7: Safety
“Attention. Filler reacts with water. Danger of fire and etching“. EGO thermostats that are filled with a metal alloy with a low melting point are treated separately. The working area must be arranged to prevent any contact between the metal alloy and water, as this leads to a chemical reaction. -
Page 8: Residual Risks
product operating instruction E.G.O. Germany (E.G.O. Elektro-Gerätebau GmbH) Residual risks Unless otherwise indicated, the following residual risks apply to all types: 2.3.1 Sharp edges Packaging boxes and mechanical parts of the thermostats (e.g. housing, sensor or tab terminal) can have sharp edges. People can cut themselves into hands or fingers. Wear safety gloves. -
Page 9: Deformation
product operating instruction E.G.O. Germany (E.G.O. Elektro-Gerätebau GmbH) Knob made of insulating material: Select at least 50 N pull-off forces in accordance with IEC 60335 part 1 ff. 2.3.4 Deformation Mechanical deformations may lead to malfunctions or even destruction of the thermostat. The risk exists particularly in the following cases: ... -
Page 10: Leaking Substances
product operating instruction E.G.O. Germany (E.G.O. Elektro-Gerätebau GmbH) 2.3.9 Leaking substances Filling medium can escape from leaked sensors or capillary tubes. The filling medium can mix with food (e.g. deep fryer oil). As a result, people can suffer from adverse health effects. Lay the sensor and capillary tube protected when used in the food industry. -
Page 11: Failing Below The Minimum Switching Power
product operating instruction E.G.O. Germany (E.G.O. Elektro-Gerätebau GmbH) 2.3.12 Failing below the minimum switching power Failing below the minimum switching power may lead to faults in the switching function. Make sure that the switching capacities are not falling below the value noted in the specified ... -
Page 12: Temperatures Too High Or Too Low
product operating instruction E.G.O. Germany (E.G.O. Elektro-Gerätebau GmbH) 2.3.17 Temperatures too high or too low Exceeding the maximum permissible sensor temperature according to the type drawing may lead to malfunctions and even destruction of the thermostat. When designing the application, note and adhere to the maximum sensor temperature specified in ... -
Page 13: Transport And Storage
(Sodium-Potassium-Mixture) Hazard class: 4.3 Packing group: -- ICAO/IATA (Transport Air): Forbidden Product approvals The product approvals for EGO Thermostats and Temperature Limiters are stored in the approved technical specifications. Storage Observe the following storage conditions: –... -
Page 14: Installation And Commissioning
product operating instruction E.G.O. Germany (E.G.O. Elektro-Gerätebau GmbH) Installation and Commissioning Mechanical installation 4.1.1 Basic information on installation You can freely choose the order of assembly depending on the application. Note the following points: If the adjustment facial expressions are inaccessible: set the switch-off temperature before ... -
Page 15: Electrical Connection
product operating instruction E.G.O. Germany (E.G.O. Elektro-Gerätebau GmbH) Electrical connection 4.3.1 Basic information on the electrical connection Observe the cross-section, insulation material and circuit diagram according to the type drawing. Observe national standard information on electrical connection, such as EN 60730. ... -
Page 16: Maintenance
E.G.O. Germany (E.G.O. Elektro-Gerätebau GmbH) Maintenance EGO Thermostats cannot be repaired. A damaged thermostat has to be replaced by a completely new thermostat. document id.: 90.60145.653-001-02-A / state: 230 - released page 16 of 19 designation: Thermostats 55.xxxxx.xxx / 56.xxxxx.xxx... -
Page 17: Disposal
product operating instruction E.G.O. Germany (E.G.O. Elektro-Gerätebau GmbH) Disposal Do not dispose of the thermostat with household waste. Dispose of the thermostat in accordance with locally applicable regulations. document id.: 90.60145.653-001-02-A / state: 230 - released page 17 of 19 designation: Thermostats 55.xxxxx.xxx / 56.xxxxx.xxx... -
Page 18: Technical Data
product operating instruction E.G.O. Germany (E.G.O. Elektro-Gerätebau GmbH) Technical data For all data see type drawing and document “approved technical data”. document id.: 90.60145.653-001-02-A / state: 230 - released page 18 of 19 designation: Thermostats 55.xxxxx.xxx / 56.xxxxx.xxx... -
Page 19: Contact
product operating instruction E.G.O. Germany (E.G.O. Elektro-Gerätebau GmbH) Contact Mr.Tilo Fucik Phone: +49 7045 45 67784 E-Mail: Tilo.Fucik@egoproducts.com document id.: 90.60145.653-001-02-A / state: 230 - released page 19 of 19 designation: Thermostats 55.xxxxx.xxx / 56.xxxxx.xxx...
