Murphysofa Installa on guide
Tools & Parts that you will need that are not included:
-Step Ladder, Power Drill/Screw Driver
-Wall Anchors for your wall type: ~12 are recommended with a strength ra ng of
at least 100+ lbs each
-Consider some extra wall brackets x 3 (simple L shape)
Ma ress: Recommended 50lbs + or you might need lighter pistons.
You should have a ma ress before you start the install so you can test it. If you
have a light ma ress, please contact us before you start in case you need weaker
it gets cut off here. Should end with 'weaker pistons.
Expand Furniture Inc declines all liability caused by the incorrect assembly
of the bed or failure to mount the bed. If you fail to mount the wall bed to
the wall or correctly fasten it, we do not take responsibility for this.
1
Advertisement
Related Manuals for expand furniture Murphysofa
Summary of Contents for expand furniture Murphysofa
- Page 1 Should end with 'weaker pistons. Expand Furniture Inc declines all liability caused by the incorrect assembly of the bed or failure to mount the bed. If you fail to mount the wall bed to...
- Page 2 You will need a power drill, screw driver, wall anchors and a ladder. 2. All Hover & MurphySofa are do it yourself assembly and require wall mounts. It is up to you to determine your wall type, make sure it is safe and correctly mount the wall bed to your wall safely and properly.
- Page 3 Please check panels for damage in transit as soon as you receive the bed and well before a emp ng installa on. Panels are boxed with the visual sides facing inwards. Because of this If there is a light ding or scuff it will likely install with no visible elements.
-
Page 4: List Of Parts
LIST OF PARTS Quan ty Quan ty L=1.968inch Quan ty Quan ty L=0.984inch Quan ty Quan ty L=1.96inch Quan ty Quan ty Quan ty Quan ty L=1.181inch Quan ty Quan ty Quan ty Quan ty Quan ty Quan ty 50 2... - Page 5 Step 1 Step 2 Step 3 Step 4...
- Page 6 Step 1 Step 2 Step 3 Step 4...
- Page 7 preinstalled Step 1 Step 2 Step 4 Step 3...
- Page 8 Step 2 Step 3 Step 1...
- Page 9 Step 2 Step 3 Step 1...
- Page 11 DA+DC step 3 step 2 step 1 We recommend you pick this up with at least 2 people, do not attempt this with 1 person as it is heavy...
- Page 12 A er Rota ng: If you have trouble installing this part, or it feels too ght, try li the middle of the connected b3/b4 panels which will help them fit in.
- Page 13 Make sure to evenly distribute these bolts around the bed un l you have none le . You only need to install 3/4ths of these bolts. If you have trouble threading a hole, skip it and move to the next one (you can try this again later if you have le overs, the more that are in, the easier it will be.)
- Page 14 Raise your bed, you should have at least 2 people li ing for safety. If you have cabinets, you can build them and place them now.
- Page 15 It is important to determine the type of wall you have, you should purchase anchors /fasteners appropriate for your wall. We do not provide anchors because there are a variety of wall types from concrete, brick or drywall (with wood or steel studs) require different anchor types. You should buy heavy duty anchors that have a high weight capacity (100+ lbs per anchor) and are appropriate for your wall type.
-
Page 16: Drill Holes
Drill holes step 1 step 2 step 3 step 4... - Page 17 step 2 step 1...
- Page 18 step 2 step 1...
- Page 19 with the one side of the piston end cap already in the frame, so the piston can be rotated to connect...
- Page 20 4 inch inset: pushed inside frame Piston install The pistons do not compress by hand. They need to be placed fully extended into the bed after the frame is set in the correct position. When you install this Gas Piston make sure you push the bed frame inwards, beyond flush, so that it is inset at least 4 inches.
- Page 21 step 3 step 1 step 2...
- Page 22 There is a Styrofoam part like this in the box. If you lost it or don’t have it, use something soft to insert at the top to keep it slightly open. A cushion works well.
- Page 23 Face Panel Clips Please measure the clips to make sure they are in the right position before drilling them in. This might require some slight adjustment. You can reposition these a few times if needed if you have trouble putting on the face panels. Label DR+DF (x4+...
- Page 24 We suggest installing the face panel with 2 people. 1 Face panel at a me. step 2 step 1 step 2 step 2 step 1...
- Page 25 step 2 step 1 step 2 step 1...
- Page 26 For this part you need 2 people. A er the pistons are installed it will be hard to lower the bed. This is NORMAL! The system requires weight like a ma ress to be balanced. So this will take some pressure to lower the bed.
- Page 27 Before drilling all the screws into the panels, we suggest pu ng in only a few support screws to perform some tests before pu ng in the remaining screws. 6 screws per panel evenly distributed is good for this test. You will only use 2/3rds of the holes on the final install so please do not think you are short screws if you don’t have enough for all the holes.
- Page 28 0.79 0.79 0.24 0.24...
- Page 29 Test 1: Raise the bed up again and see how it looks and that you are happy with how it is aligned. If it is not correct the clips might need to be adjusted slightly. This can be a subjec ve process for the alignment. Test 2: Make sure the bed frame is not hanging forward.
- Page 30 Test 3: Lower the bed. Does it stay down with the mattress on it? If the answer is yes, remove the mattress and install the rest of the screws. You will only use 2/3rds of the holes on the final install so please do not think you are short screws if you don’t have enough for all the holes”...
- Page 31 After you lower your frame with the face panel on it. You can place your mattress down. This will keep the bed down. You can now install the mattress holder. Please make sure to follow the next step carefully. Do not skip securing the face panels! step 1 step 2...
- Page 33 step 1 step 2 step 3...
- Page 34 DMx6 DMx6 step 2 step 1...
