PRODUCT NAME: Marble Floor 2 Tier Towel Holder
ITEM NUMBER: WH030
ASSEMBLED DIMENSIONS : 39"H x 29"W x 9"D
PRODUCTS ARE NOT INTENDED
FOR COMMERCIAL USE.
UPDATED: 9-4-2020
Prevent accidentally discarding small parts or
hardware. Retain all carton contents until assembly
and installation are complete.
Customer Service: 800-367-2810
Online: www.ballarddesigns.com
MADE IN CHINA
Page 1 of 4
Advertisement
Summary of Contents for Ballard Designs WH030
- Page 1 Customer Service: 800-367-2810 Online: www.ballarddesigns.com PRODUCT NAME: Marble Floor 2 Tier Towel Holder ITEM NUMBER: WH030 ASSEMBLED DIMENSIONS : 39”H x 29”W x 9”D Prevent accidentally discarding small parts or hardware. Retain all carton contents until assembly and installation are complete.
- Page 2 Assemble in location for intended use. REQUIRED TOOLS: Ltr. Qty. Hardware Included Phillips Allen Key (included) Short Machine Screws -Two person assembly suggested. M6 x 30mm Remove all parts, hardware and Long Machine Screws protective packaging from carton M6 x 130mm and carefully arrange on a clean, level, padded surface.
- Page 3 Assemble in location for intended use. STEP 1: Orient Front Support Posts (J) and Back Support Posts (K) as shown then join each pair using a Support Bar (H). Insert and tighten Long Machine Screw (B) through hole in Back Support Post, through Support Bar and into Front Support Post.
- Page 4 Assemble in location for intended use. STEP 3: Set partially assembled unit on a level surface then add a Ring (F) to top of each Support Post (orient as illustrated). Add a Towel Bar (G) to each assembly, front and back. Secure in place by threading and tightening a Finial (E) into top of each Post.
