Page 1 Part No. IB022459 Jan 2023 Overview Preparation Basic Measurement User’s Manual Function Settings 6-1/2 Digit Multimeter Math Functions DME1600 System Settings Specifications...
Page 2: About Dme1600 Manuals
About DME1600 manuals Notations Used in This Manual There are two manuals for the DME1600: the User’s Manual • The DME1600 6-1/2 Digit Multimeter is also referred to as (this manual) and the Remote Interface Manual. the “DME1600.” The manuals are intended for users of the DME1600 and their •...
Page 3: Safety Symbols
Chassis (frame) terminal On (supply) Off (supply) On (supply) / standby This product is not completely disconnected from MAINS when it is in standby mode. In position of a bi-stable push control Out position of a bi-stable push control DME1600...
Page 4: Safety Precautions
• This product is calibrated before shipment. To maintain the product’s performance, we recommend periodic calibration. • Use the product within the rated input power voltage range. To have your product calibrated, contact your Kikusui agent/ • For applying power, use the power cord provided. For distributor.
Page 5: Precautions Concerning Installation Location
The product may malfunction. • Do not use the unit near highly sensitive measuring instru- ments or transceivers. The noise generated by the unit may affect them. • When installing products with casters, be sure to lock the casters. DME1600...
Page 6: Table Of Contents
Contents DC Input Resistance ........Threshold Resistance for Continuity Tests Threshold Range for Diode Tests ....Range (Auto and Manual)......About DME1600 manuals ......2 Integration Time ......... Disposal ..........2 Temperature Sensor ........Notations Used in This Manual ....2 RTD............. Safety Symbols ........3 Thermocouple ........
Page 7 Viewing the Firmware Versions....Calibration Information Display ....Scan Function (Option) ......Configuration and specifications of a scanner card (DME1600-opt01) ..Scanner card wiring......Connecting the scanner card .... Configuring the scan function.... Setting the step function..... Specifications DC characteristics ......
Page 8 Front panel DME1600 6 1/2 DIGIT MULTIMETER INPUT 4W SENSE RATIO 200V 1000V DISPLAY FUNCTION SETUP RANGE PERIOD TCOUPL 500V pk PREV TERMINALS MX + B LOCK STEP SCAN LIMITS NEXT FUSE FRONT EXTRIG HOLD MATH POWER REAR 3A 250V...
Page 9 This manual denotes key sequences that require you to press the SHIFT key as SHIFT+(the name of the key).  How to use the ESC key • Press ESC to cancel the previous operation and the DME1600 to the state that it was in before the previ- ous operation. • Press ESC to unlock the keys.
Page 10  Maximum input voltage • The LO terminal is marked with 500 Vpk max against ground. • The SENSE HI to LO terminal is marked with 200 Vpk max. • The maximum voltage from HI to LO is 1000 Vpk. DME1600...
Page 11 Display No. Name Function Indicates that the DME1600 is being con- ADRS p. 67 trolled through the GPIB interface Indicates that the DME1600 is being con- p. 67 trolled through the USB interface Indicates that the manual range is being used p.
Page 12 VM COMP p. 74 synchronizing external devices. EXT TRIG External trigger signal input. p. 73 USB port for controlling the DME1600 p. 67 remotely. A grounding terminal for connecting to a Protective con- power cord that does not have a three-prong ductor terminal plug.
Page 13: General Information
General Information This chapter gives an overview of the DME1600 and explains the options that are available for it.
Page 14: Product Overview
Product Overview The DME1600 is a robust, versatile 6-1/2 digit digital multimeter. It has a one-year accuracy of 0.0035% for 10 V range DC voltage measurements and 0.01% for 10 k range resistance measurements. At the fastest 4-1/2 digit setting, the DME1600 makes 2000 measurements per second. At the 6-1/2 digit setting, it makes 50 measurements per second.
Page 15: Options
Beep sound on and off Measurement memory Stores 2000 measured values Hold Measured value hold Initial mode For selecting the mode that the DME1600 starts in when the power switch is turned on Language Communication command language Error indicators Displays errors...
Page 16 Product Overview This page left blank intentionally. DME1600...
Page 17 Preparation This chapter describes how to unpack and prepare this product before you use it.
Page 18: Checking The Package Contents
When you receive the product, check that all accessories are included and that the accesso- ries have not been damaged during transportation. If any of the accessories are damaged or missing, contact your Kikusui agent or distributor. We recommend that all packing materials be saved, in case the product needs to be trans- ported at a later date.
Page 19: Using The Handle
Hold the left and right parts of the handle that are attached to the DME1600, and pull them outwards. Move the handle to the desired position. If you are going to carry the DME1600 by the handle, move the handle to the position shown below. When you move the DME1600 using its handle...
Page 20: Setting The Line Voltage
Setting the Line Voltage The DME1600’s AC input voltage rating is single-phase 100 Vac or 220 Vac. The frequency rating is 50 Hz/60 Hz ± 10 %. To avoid electric shock: WARNING • Before changing the line voltage setting, be sure to disconnect the DME1600 from the AC power line.
Page 21 Using a flat-blade screwdriver, pull the red fuse block out. Turn the fuse block upside down. One orientation is for 100 Vac, and the other is for 220 Vac. 100 Vac 220 Vac Insert the red fuse block, and close the voltage setting selector cap. DME1600...
Page 22: Changing The Power Line Fuse
250 mAT. The fuse rating is written on the rear panel. To avoid electric shock: WARNING • Before changing the Power Line Fuse, be sure to disconnect the DME1600 from the AC power line. To prevent damage to the DME1600, observe the following: CAUTION •...
Page 23 Changing the Power Line Fuse Using a flat-blade screwdriver, pull the red fuse block out. Change the fuse. Remove the melted fuse. Attach a new fuse. Insert the red fuse block back in, and close the voltage setting selector cap. DME1600...
Page 24: Connecting The Power Cord
Kikusui agent or distributor. • The power cord with a plug can be used to disconnect the DME1600 from the AC line in an emergency. Connect the plug to an easily accessible power outlet so that the plug can be removed from the outlet at any time.
Page 25  Turning the power switch on Push the power switch in. The power is on when the switch is in the “in” position. The DME1600 will start up with p.28 the factory default settings. If you notice strange sounds, unusual odors, fire, or smoke around or from inside the DME1600, turn the power switch off.
Page 26: Replacing The Current Input Terminal Fuses
You can replace the 3 A fuse. You can not replace the 11 A fuse because it is installed inside DME1600. If current cannot be measured even if you change the 3 A fuse, contact your Kikusui agent or distributor to request repairs.
Page 27 Replacing the Current Input Terminal Fuses Remove the current input terminal and fuse. Change the fuse. 3 A, 250 V (fast acting, high breaking capacity) Fuse Fuse holder Insert the current input terminal and fuse. While pushing the terminal, turn it counterclockwise. DME1600...
Page 28: Factory Default Settings
1 mA Rate 0.1 PLC Digits Slow 6 1/2 (1 PLC) Resistance (2-wire method) Range Auto Digits Slow 6 1/2 (10 PLC) Temperature Thermocouple Type K, °C Source Immediate Trigger Delay Auto Input resistance 10 M PLC (Power Line Cycles) DME1600...
Page 29: Basic Measurement
Basic Measurement This chapter explains the measurement features of the DME1600.
Page 30: Basic Measurement Feature Overview
The DME1600 contains the following basic measurement functions. To take measurements with the DME1600, connect test leads to the input terminals, and connect the test lead tips to the measurement points. To measure temperature, connect a thermocouple or an RTD to the input terminals.
Page 31 Use the RANGE up, down, and AUTO keys to set the range. There are two range modes: manual and auto. Connect the test lead tips to the measurement points. Read the measured value on the display. If the input signal exceeds the measurable range, an overflow message “OVLD” appears. DME1600...
Page 32: Current Measurement
AC current range (resolution) 1 Arms (1 A), 3 Arms (10 A) To prevent damage to the DME1600, observe the following: CAUTION • The maximum input current is 3 A (250 V). To avoid damage to the fuse, keep the current from exceeding the maximum input current.
Page 33 Use the RANGE up, down, and AUTO keys to set the range. There are two range modes: manual and auto. Connect the test lead tips to the measurement points. Read the measured value on the display. If the input signal exceeds the measurable range, an overflow message “OVLD” appears. DME1600...
Page 34: Resistance Measurement
500V pk TERMINALS TERMINAL switch FRONT FUSE 3A 250V REAR CAT 1000V 600V 4-wire INPUT 4W SENSE Resistor RATIO 200V 1000V Test current 500V pk TERMINALS FUSE FRONT 3A 250V REAR CAT 1000V 600V DME1600 DME1600...
Page 35 Connect the test lead tips to the measurement points as shown in the input terminal connection diagram for the 4-wire method. Read the measured value on the display. If the input signal exceeds the measurable range, an overflow message “OVLD” appears. DME1600...
Page 36: Frequency And Period Measurement
100 mVrms to 750 Vrms To avoid electric shock: WARNING • Do not apply voltages that exceed 1000 Vpeak to the input terminals. Doing so could damage the DME1600 and cause electric shock. Connecting the input terminals INPUT 4W SENSE...
Page 37: Continuity Test
If the input signal exceeds the measurable range, an overflow message “OVLD” appears. Continuity Test The DME1600 performs continuity tests using the resistance measurement’s 1 k range. The DME1600 beeps when the measured resistance is less than the threshold value. Measurement ranges and conditions...
Page 38: Diode Test
The DME1600 beeps when the measured resistance is less than the threshold value. Diode Test The DME1600 measures the diode forward voltage using a 1 mA test current. The DME1600 beeps when the measured forward voltage is within the threshold range.
Page 39 Connect the HI input terminal test lead to the diode’s anode and the LO input terminal test lead to the cathode. Press (SHIFT+CONT). Read the measured value on the display. The DME1600 beeps when the measured voltage is within the threshold range. DME1600...
Page 40: Temperature Measurement
Temperature Measurement The DME1600 supports thermocouples and RTD (Resistance Temperature Detection) p. 62 probes. The following methods are available for measuring temperature with RTDs. • 2-wire • 3-wire • 4-wire In general, RTDs have better accuracy and long-term stability than thermocouples. Before making temperature measurements, you have to set the temperature sensor type.
Page 41 Press ENTER.  Setting the displayed unit of measurement Press CONFIG. Press TCOUPL (SHIFT+TEMP). Press PREV or NEXT to select UNITS. Press ENTER. Press PREV or NEXT to select the unit. You can select °C, °F, or K. Press ENTER. DME1600...
Page 42: 2-Wire Rtd Measurement
-392 to 1562 Measurement ranges and conditions Item Factory default setting PT100 Connecting the input terminals INPUT 4W SENSE Front-panel input terminals RATIO 200V 1000V Test current 500V pk TERMINALS TERMINAL switch FUSE FRONT 3A 250V REAR CAT 1000V 600V DME1600...
Page 43 Press ENTER.  Setting the displayed unit of measurement Press CONFIG. Press TEMP. Press PREV or NEXT to select UNITS. Press ENTER. Press PREV or NEXT to select the unit. You can select °C, °F, or K. Press ENTER. DME1600...
Page 44: 3-Wire Rtd Measurement
3A 250V REAR CAT 1000V 600V Keys FUNCTION SETUP RANGE MATH TRIGGER MEMORY Procedure (setting the RTD type, displayed unit of measurement, and wiring method) Setting the RTD type CONFIG TEMP SENSOR {F100|PT385|PT 3916|USER|NTC → → → T|SPRTD|PT100 |D100} DME1600...
Page 45 Press PREV or NEXT to select the unit. You can select °C, °F, or K. Press ENTER.  Setting the wiring method Press CONFIG. Press TEMP. Press PREV or NEXT to select TRANSDUCER. Press ENTER. Press PREV or NEXT to select 4W RTD. Press ENTER. DME1600...
Page 46: 4-Wire Rtd Measurement
REAR CAT 1000V 600V Keys FUNCTION SETUP RANGE MATH TRIGGER MEMORY Procedure Do not short the SENSE-LO and the INPUT-LO terminals (see the figure above). All other p. 44 steps are the same as with the 3-wire RTD measurement. DME1600...
Page 47: Function Settings
Function Settings This chapter explains the various function settings that can be configured from the front panel.
Page 48: Function Settings Overview
Use auto zero adjustment to minimize the effects of offset on your measurements. When auto zero adjustment is enabled, the DME1600 samples the input signal as a raw value and then internally disconnects the input signal to measure the offset (the null offset). Then, the DME1600 subtracts the offset from the raw value to obtain the accurate measurement.
Page 49 To enable auto zero adjustment, select ON; otherwise select OFF. Press ENTER. Remote interface operation SENSe:ZERO:AUTO {OFF|ONCE|ON} The OFF and ONCE parameters have a similar effect. With OFF, a new offset measurement is not performed. However, with ONCE, an offset mea- surement is performed immediately. DME1600...
Page 50: Filter
Filter Filters are used to remove noise from measurement. The DME1600 has two types of filters: AC and digital. The AC filter is used only for AC voltage and AC current measurements and affects the measurement speed. The digital filter stabilizes measurement through averaging.
Page 51: Digital Filter
Then, the DME1600 flushes the stack and starts over with an empty stack. This means that in repeating average mode, the DME1600 produces a measured value each time the specified number of values are sampled.
Page 52 2 and 100. Press ENTER.  Setting the filter mode Press CONFIG. Press FILTER. Press PREV or NEXT to select MODE. Press ENTER. Press PREV or NEXT to select MOVING AVG or REPEAT AVG. Press ENTER to apply the settings. DME1600...
Page 53 Filter Remote interface operation SENSe:AVERage:TCONtrol {MOVing|REPeat} SENSe:AVERage:TCONtrol? SENSe:AVERage:COUNt {<value>|MINimum|MAXimum} SENSe:AVERage:COUNt?[MINimum|MAXimum] SENSe:AVERage:STATe {OFF|ON} SENSe:AVERage:STATe DME1600...
Page 54: Resolution Setting
Resolution Setting The resolution is the number of digits that the DME1600 can measure. You can select from the following six resolution options. • FAST 4 1/2 (for fast measurements) • SLOW 4 1/2 • FAST 5 1/2 • SLOW 5 1/2 •...
Page 55 Press PREV or NEXT to select the resolution. You can select FAST 4 1/2, SLOW 4 1/2, FAST 5 1/2, SLOW 5 1/2, FAST 6 1/2, or SLOW 6 1/2. Press ENTER. Remote interface operation CONFigure:<function> <range>,<resolution> MEASure:<function>? <range>,<resolution> SENSe:<function>:RESolution <resolution> FREQuency:APERture {0.01|0.1|1|MIN|MAX} PERiod:APERture {0.01|0.1|1|MIN|MAX} DME1600...
Page 56: Dc Input Resistance
For low input DC voltage (100 mV, 1 V, and 10 V range) measurements, you can select a large input resistance (> 10 G) to reduce the loading effect of the DME1600 input resis- tance. For 100 V DCV and 1000 V DCV measurements and other measurement functions, the input resistance is fixed at 10 M.
Page 57: Threshold Resistance For Continuity Tests
Threshold Resistance for Continuity Tests When testing continuity, the DME1600 beeps when the measured resistance is less than the threshold value. You can set the threshold value to a value between 1  and 1000 . Setup conditions The default value is 10 . The setting is returned to its factory default value Factory default settings when the power switch is turned off.
Page 58: Threshold Range For Diode Tests
Threshold Range for Diode Tests The DME1600 measures the diode forward voltage using a 1 mA test current. The DME1600 beeps when the measured forward voltage is within the threshold range. Setup conditions Threshold voltages You can set the threshold voltages to values between 0.01 V and 1.2 V.
Page 59: Range (Auto And Manual)
Range (Auto and Manual) The DME1600 can automatically select measurement ranges (this feature cannot be used in continuity tests, diode tests, and temperature measurements). You can also select the range manually to reduce the settling time. When the input signal exceeds the measurable range, an OVLD message appears on the display.
Page 60: Integration Time
“Resolution Setting.” Remote interface operation  Resolution setting CONFigure:<function> <range>, <resolution> MEASure:<function>? <range>, <resolution> SENSe:<function>:RESolution <resolution>  Integration time setting SENSe:VOLTage:DC:NPLCycles {0.02|0.1|1|10|MINimum|MAXimum} SENSe:VOLTage:DC:NPLCycles?[MINimum|MAXimum] SENSe:CURRent:DC:NPLCycles {0.02|0.1|1|10|MINimum|MAXimum} SENSe:CURRent:DC:NPLCycles?[MINimum|MAXimum] SENSe:RESistance:NPLCycles {0.02|0.1|1|10|MINimum|MAXimum} SENSe:RESistance:NPLCycles?[MINimum|MAXimum] SENSe:FRESistance:DC:NPLCycles {0.02|0.1|1|10|MINimum|MAXimum} SENSe:FRESistance:DC:NPLCycles?[MINimum|MAXimum] DME1600 DME1600...
Page 61 There is a setting called aperture time (or gate time), which is analogous to the integration time. SENSe:FREQuency:APERture {0.01|0.1|1|MINimum|MAXimum} SENSe:FREQuency:APERture?[MINimum|MAXimum] SENSe:PERiod:APERture {0.01|0.1|1|MINimum|MAXimum} SENSe:PERiod:APERture?[MINimum|MAXimum] Aperture time (or gate time) setting 0.01 s (4 1/2 digits), 0.1 s (factory default: 5 1/2 digits), or 1 s (6 1/2 digits) DME1600...
Page 62: Temperature Sensor
User Temperature Sensor The temperature sensors that you can use with the DME1600 are RTDs and thermocouples. Before making temperature measurements, you have to set the temperature sensor type. The RTDs that you can use are PT100, D100, F100, PT385, PT3916, user-defined RTD, and SPRTD.
Page 63 The ENTER key and keys for selecting the display items (PREV, NEXT, up, and down keys) have been omitted. Options are indicated as {option 1|option 2|option 3| . . . |option n}. Press CONFIG. Press TEMP. Press PREV or NEXT to select SENSOR. Press ENTER. Press PREV or NEXT to select the sensor type. Press ENTER. DME1600...
Page 64 B appears (for setting the fifth factor). Return to step 8, and enter the constant. C appears (for setting the sixth factor). Return to step 8, and enter the constant. D appears (for setting the seventh factor). When you finish entering all the constants, the menu automatically closes. DME1600...
Page 65: Thermocouple
To make the values displayed on the DME1600 the same as those on a thermometer, you have to measure the ambient temperature with a separate thermometer and set the reference junction temperature to the ambient temperature.
Page 66 Press PREV or NEXT to select SIMULATED. Press ENTER. Press PREV or NEXT to move between digits and the up and down keys to set the value. Press ENTER. Remote interface operation SENSe:UNIT {Cel|Far|K} SENSe:UNIT? SENSe:TCOuple:TYPE {E|J|K|N|R|S|T} SENSe:TCOuple:RJUNction:SIMulated {<value>|MINimum|MAXimum} DME1600...
Page 67: Selecting The Remote Interface
Selecting the Remote Interface The DME1600 has USB and GPIB remote interfaces. You can use either interface but not both at the same time. The GPIB interface is a factory option. Setup conditions The default value is USB. Factory default settings The GPIB address is 22.
Page 68: Switching Between Input Terminals
Press ENTER to enter the GPIB address. Switching between Input Terminals The DME1600 has input terminals on both the front and rear panels. When you select the rear-panel input terminals, the REAR indicator in the top area of the panel display lights.
Page 69: Triggering
Triggering The DME1600 has a variety of trigger features. For each measurement function, you can set the trigger mode, trigger source, and trigger settings.  Trigger mode You can set the trigger mode to auto, immediate, or single.  Trigger source You can set the trigger source to front panel, external trigger input, or remote interface.
Page 70: Trigger Mode
Trigger Mode On the DME1600, you can set the trigger mode to auto, immediate, or single. Auto trigger mode (front panel operation only) In auto trigger mode, the DME1600 continuously takes samples at the fastest rate possible (the rate depends on the current settings).
Page 71: Single Trigger Mode (Front Panel Operation Only)
In single trigger mode, the DME1600 takes a single measurement (or the specified number of measurements) each time you press SINGLE. When the TRIG indicator is lit on the display, the DME1600 is ready for the next trigger event. Single trigger mode can only used during front panel operation.
Page 72: Trigger Source
Trigger Source On the DME1600, you can set the trigger source to front panel, external trigger input, or remote interface. Front panel operation For auto trigger, use the AUTO TRIGGER key. For single trigger, use the SINGLE key. Keys FUNCTION...
Page 73: External Trigger Input
External trigger input You can use external trigger pulses applied to the rear-panel EXT TRIG (BNC) terminal as a trigger source. When an external trigger signal is received, the DME1600 starts a single mea- surement or the specified number of measurements.
Page 74: Triggering Through The Remote Interface
Trigger Source Triggering through the remote interface Software trigger In software triggering, a command is sent from a PC to the DME1600. The DME1600 starts measuring when it receives the command. TRIGger:SOURce BUS Internal trigger Internal trigger is the default trigger mode for remote interface operation. In internal trigger mode, the DME1600 triggers immediately when it enters the trigger-wait state.
Page 75: Other Trigger Settings
Other Trigger Settings On the DME1600, you can set the number of samples per trigger, the number of triggers per event, the measured value hold setting, the trigger delay setting for making measurements, and so on. Number of samples per trigger You can configure the DME1600 so that it samples the specified number of times (up to 50000) each time it receives a trigger.
Page 76: Number Of Triggers (Remote Interface Operation Only)
Normally, the DME1600 returns to the idle state upon receiving a trigger. You can set the number of triggers that the DME1600 receives before it returns to the idle state. You can only set this number through the remote interface.
Page 77: Trigger Delay
600 ms 3 Hz 1.5 s ACV / ACI (front panel; auto trigger 20 Hz 200 ms enabled) 200 Hz 100 ms Remote interface, external Frequency, period (front panel; auto trigger enabled) Keys FUNCTION SETUP RANGE MATH TRIGGER MEMORY DME1600...
Page 78 Press PREV or NEXT to move between digits and the up and down keys to set the value. You can set the trigger delay to a value between 0 seconds and 3600 seconds. Press ENTER. Remote interface operation TRIGger:DELay {<seconds>|MINimum|MAXimum} TRIGger:DELay:AUTO {OFF|ON} Delay setting Auto trigger delay operation setting DME1600...
Page 79: Math Functions
Remote analog control Math Functions This chapter explains the math functions.
Page 80: Math Function Overview
Math Function Overview The DME1600 can perform the math operations shown in the table below. Data that has been acquired through measurement is either stored for later use or used in mathematical opera- tions. These math functions are available to all measurement functions except for continuity and diode testing.
Page 81 ±0.2 V. • The specified measurement range is used only for the signal connected to the input terminals. And the signal on the input terminals can be any dc voltage up to 1000 V. Remote interface operation CONFigure:VOLTage:DC:RATio{<range>|MIN|MAX|DEF},{<resolution >|MIN|MAX|DEF} DME1600...
Page 82: (Percentage)
The equation is shown below. Measured value Percentage (%) = Target value The specified target value is stored. The setting is cleared when you turn the power switch off or reset the DME1600 through the remote interface. Keys RANGE FUNCTION SETUP...
Page 83: Maximum And Minimum
The function also stores the number of measured values that have been acquired since the func- tion was enabled. Whenever a new maximum or minimum value is acquired, the DME1600 beeps.
Page 84 The minimum value (MIN) appears. Press NEXT. The maximum value (MAX) appears. Press NEXT. The average value (AVERAGE) appears. Press NEXT. The number of measured values (COUNT) appears. Remote interface operation CALCulate:FUNCtion AVERage CALCulate:STATe {OFF|ON} CALCulate:STATe? CALCulate:AVERage:MINimum? CALCulate:AVERage:MAXimum? CALCulate:AVERage:AVERage? CALCulate:AVERage:COUNt? DME1600...
Page 85: Null
The MATH indicator in the top area of the display lights. The old value in the null regis- ter is replaced with the new measured value. Connect the test lead tips to the measurement points. Read the measured value on the display.  Press NULL again to disable this function. DME1600 DME1600...
Page 86: Upper And Lower Limit Test
The upper and lower limit test function tests the measured value against the specified upper and lower limits. When the measured value exceeds the upper limit or falls below the lower limit, the DME1600 beeps and displays “HI” or “LO.” The function is available to all functions except for continuity and diode testing.
Page 87 Press LIMITS (SHIFT+RATIO). The MATH indicator in the top area of the display lights. Read the measured value on the display.  Press LIMITS (SHIFT+RATIO) again to disable this function. Remote interface operation CALCulate:FUNCtion LIMitCALCulate:STATe {OFF|ON} CALCulate:STATe? CALCulate:LIMit:LOWer {<value>|MINimum|MAXimum} CALCulate:LIMit:UPPer {<value>|MINimum|MAXimum} DME1600...
Page 88: Mx+B
This function determines value Y that is linearly proportional to measured value X as defined by slope M and offset B. You can set constants M and B. Constants M and B are cleared when you turn the power switch off or reset the DME1600 through the remote interface.
Page 89 The MATH indicator in the top area of the display lights. Read the measured value on the display.  Press MX+B (SHIFT+%) again to disable this function. Remote interface operation CALCulate:FUNCtion MXB CALCulate:STATe {OFF|ON} CALCulate:STATe? CALCulate:MXB:MMFactor {<value>|MINimum|MAXimum} CALCulate:MXB:MMFactor?[MINimum|MAXimum] CALCulate:MXB:MBFactor {<value>|MINimum|MAXimum} CALCulate:MXB:MBFactor?[MINimum|MAXimum] DME1600...
Page 90: Dbm
You can set the reference resistance to a value between 50 Ω and 8 000 Ω. Even if you change the reference resistance, the stored reference value is not affected. The reference resistance is cleared when you turn the power switch off or reset the DME1600 through the remote interface.
Page 91 You can set the reference value manually or assign the first measured value to it. You can manually set the reference value to a value in the range of 0 dBm ± 200 dBm. The reference value is cleared when you turn the power switch off or reset the DME1600 through the remote interface.
Page 92 The MATH indicator in the top area of the display lights. The measured value is assigned to the relative reference level (0 dB). Read the measured value on the display.  Press dB (SHIFT+NULL) again to disable this function. Remote interface operation CALCulate:FUNCtion DB CALCulate:STATe {OFF|ON} CALCulate:STATe? CALCulate:DB:REFerence {<value>|MINimum|MAXimum} DME1600...
Page 93: System Settings
System Settings This chapter explains the system settings.
Page 94: Overview Of The System Settings
10-channel scanner option p. 105 Display The DME1600 display consists of a 13-digit, 5x7 dot matrix measurement display area and a 16-digit, 5x7 dot matrix bottom information display area. The display shows three colors (white, red, and yellow). The display also consists of top and right information display areas where a variety of status information is displayed.
Page 95: Beeper
Beeper The DME1600 beeps under certain conditions and when errors occur. If you do not want the DME1600 to beep, you can this feature off. You cannot turn off the click sounds that are pro- duced when you press keys.
Page 96 Options are indicated as {option 1|option 2|option 3| . . . |option n}. Press MENU. Press PREV or NEXT to select SYSTEM. Press ENTER. Press PREV or NEXT to select BEEP. Press ENTER. Press PREV or NEXT to select ON or OFF. Press ENTER. Remote interface operation SYSTem:BEEPer SYSTem:BEEPer:STATe {OFF|ON} DME1600...
Page 97: Measurement Memory
Measurement memory The DME1600 has a memory area that can store 2000 measured values. Measured values are stored to volatile memory in first-in, first-out order. The stored values are cleared when the power switch is turned off. The memory can be used for all measurement functions, math operations, trigger operations, and the measured value hold feature.
Page 98 (this includes math functions) and the trigger mode before you press STORE. Press STORE. The MEM indicator in the top area of the display lights. The DME1600 starts storing measured values to memory and keeps doing so until the specified number is reached.
Page 99: Hold Feature
The sensitivity band is expressed as a percentage of the measured value in the selected range. When three consecutive measurements are within the sensitivity band, the DME1600 considers the measured values to be stable. Setup conditions The default sensitivity band is 0.1 %. The setting is saved, but it is cleared Factory default setting when the power switch is turned off.
Page 100: Initial Mode
Initial Mode You can select the initial mode, which is the mode that the DME1600 starts in when the power switch is turned on. There are two modes: SAVE DATA and DEFAULT. In SAVE DATA mode, the DME1600 starts with the stored conditions for the items indicated in the table below. In DEFAULT mode, the DME1600 starts with factory default conditions.
Page 101: Language
Language The DME1600 supports two communication command languages: DEFAULT (the factory default setting) and COMPATIBLE (compatible with the 34401A multimeter by Agilent Tech- nologies). Keys FUNCTION SETUP RANGE MATH TRIGGER MEMORY Procedure MENU SYSTEM LANGUAGE {DEFAULT → → → |COMPATIBLE} The ENTER key and keys for selecting the display items (PREV, NEXT, up, and down keys) have been omitted.
Page 102: Error Indicator
Error Indicator The error indicator on the display warns you that an error has occurred on the DME1600. If a command syntax error or hardware error is found, the ERR indicator in the top area of the dis- play lights.
Page 103: Viewing The Firmware Versions
Viewing the Firmware Versions The DME1600 has three microprocessors. For each processor, you can view the installed firmware version. Keys FUNCTION SETUP RANGE MATH TRIGGER MEMORY Procedure MENU → SYSTEM → SYSTEM VER The ENTER key and keys for selecting the display items (PREV, NEXT, up, and down keys) have been omitted.
Page 104: Calibration Information Display
Calibration Information Display The DME1600 can display the previous calibration date. Keys FUNCTION SETUP RANGE MATH TRIGGER MEMORY Procedure MENU → CAL MENU → DATE The ENTER key and keys for selecting the display items (PREV, NEXT, up, and down keys) have been omitted.
Page 105: Scan Function (Option)
Scan Function (Option) Installing a scanner card option adds a scan function to the DME1600. The following three types of scanner cards are available. • 10-channel scanner card (DME1600-opt01) • 20-channel scanner card (DME1600-opt09) • 10-channel thermocouple scanner card (DME1600-opt12) With the scanner card, you can set the measurement function separately for each channel.
Page 106: Scanner Card Wiring
Auto zero adjustment off, auto gain off, auto range off, scan interval 0, line frequency 60 Hz Scanner card wiring 10-channel voltage measurement This section gives an example of a 10-channel voltage measurement.Input channels CH1 to CH10 are used. Connect OUT A to the DME1600’s rear-panel INPUT terminals. DME1600...
Page 107 This section gives an example of a 2-channel current measurement. Connect shunt resistors to R1 and R2 of the scanner card. R1 and R2 must be of the same resistance. Input channels CH1 and CH6 are used. Connect OUT A to the DME1600’s rear-panel INPUT terminals. DME1600...
Page 108: Connecting The Scanner Card
Screw the scanner card to the rear panel. If the screws are not securely fastened, it can result in erroneous measurements. Wire the DME1600’s rear-panel input terminals. Connect the scanner card’s OUT A to the DME1600’s rear-panel INPUT terminals. Connect OUT B to the DME1600’s rear-panel SENSE input terminals. 4W SENSE KIKUSUI ELECTRONICS CORP.
Page 109: Configuring The Scan Function
Select a channel from CH01 to CH10. Select “----” for channels that you are not going to use. Press ENTER. Press PREV or NEXT to select the measurement function. Select DCV, ACV, 2Ω, 4Ω, FREQ, or PERIOD. Press ENTER. Repeat steps 5 to 8 to set all the channels. DME1600...
Page 110 |CH10} CONFIG → SCAN → OPEN ALL The ENTER key and keys for selecting the display items (PREV, NEXT, up, and down keys) have been omitted. Options are indicated as {option 1|option 2|option 3| . . . |option n}. DME1600...
Page 111: Setting The Step Function
→ → |CH10} {DCV|ACV|2Ω|4 Ω |FREQ |PERIOD} The ENTER key and keys for selecting the display items (PREV, NEXT, up, and down keys) have been omitted. Options are indicated as {option 1|option 2|option 3| . . . |option n}. DME1600...
Page 112 |CH10} CONFIG → STEP → OPEN ALL The ENTER key and keys for selecting the display items (PREV, NEXT, up, and down keys) have been omitted. Options are indicated as {option 1|option 2|option 3| . . . |option n}. DME1600...
Page 113: Specifications
Remote analog control Specifications This chapter contains the specifications of the DME1600.
Page 114: Dc Characteristics
Range Resolution Test current 1 year (23 °C ± 5 °C) 1.0000 V 10 V 1 mA 0.010+0.020  Continuity test Range Resolution Test current 1 year (23 °C ± 5 °C) 1 k 10 m 1 mA 0.010+0.030 DME1600...
Page 115: Frequency And Period Characteristics
0.01 Measurement characteristics Item Specification Overrange Permits voltages that are up to 20 % over the range except when the 750 Vrms range is in use Measurement frequency The maximum frequency for the 750 Vrms range is 100 kHz. DME1600...
Page 116: Ac Characteristics
750 Vrms range is in use Measurement The maximum frequency for the 750 Vrms range is 100 kHz. frequency AC current Overrange Permits voltages that are up to 20 % over the range except measurement when the 750 Vrms range is in use DME1600...
Page 117: General Specifications
This is a Group 1 equipment. This product does not generate and/or use intentionally radio-fre- quency energy, in the form of electromagnetic radiation, inductive and/or capacitive coupling, for the treatment of material or inspection/analysis purpose. Contains the User’s Manual and the Remote Interface Manual. DME1600...
Page 118: Outline Drawing
Specifications Outline drawing 213.6 346.9 (8.41) (13.66) 88.6 (3.49) 352.2 (13.87) 252.8(9.95) 371.4 (14.62) 226.8(8.93) 107.0 (4.21) 372.6 (14.67) 226.8 371.4 (8.93) (14.62) 107.0 (4.21) 372.6 (14.67) Unit: mm (inch) DME1600...
Page 119 EXT TRIG ..............12 protective conductor terminal ........12 EXTRIG key ............... 9 RATIO key ..............9 factory default settings ..........28 READ HOLD ............99 FAST 4 1/2 ............... 54 READINGS .............. 52 FAST 5 1/2 ............... 54 DME1600...
Page 120 ..........37 threshold voltages ............38 TRANSDUCER ............45 TRIG ..............78 TYPE ..............41 UNITS ............41 up key .................9 USB ................12 USB configuration ............67 VM COMP ..............12 weight ..............117 wiring method, setting ..........45 Ω2 key ................8 Ω4 key ................8 DME1600...
Page 122 “Part No.” written on the front cover of this manual. Every effort has been made to ensure the accuracy of this manual. However, if you have any questions or find any errors or omissions, please contact your Kikusui agent or distributor.
