axing Basic SPU 21-02 Operation Instructions page 3

 Observe the safety instructions supplied with the device!
They are also available at the following Internet address:
https://download.axing.com/BAs/Sicherheitshinweise_9sprachig.pdf
 Use the device only as described in these operating instructions and in
particular in accordance with the state of the art.
If the device is used for other purposes, no warranty will be assumed!
State of the art 2020-08-31
Technical improvements, changes in design, printing- and other errors expected.
Technical data:
Type SPU 21-02 SPU 41-02
Inputs
Number 2
Frequency range 950...2200 MHz 950...2200 MHz
Isolation ≥ 20 dB
SAT inputs | SAT inputs
Subscriber ports
Number 1
Switch commands Position Position | Option
Supported DiSEqC level
Tap loss SAT typ. 4 dB
Connectors
Connector type
General
Operating temperature -20...+50°C
range (acc. to EN 60065)
Dimensions 70 × 120 × 30 mm 110 × 120 × 30 mm 110 × 120 × 50 mm
(W × H × D) appr.
Weight 0,100 kg
CE Confirmation Declaration
Hereby, AXING AG declares that the device is in compliance with Directive 2014/53/EU.
The full text of the EU declaration of conformity is available at the following internet
address: https://axing.com/en/downloads/ce/.
WEEE Nr. DE26869279 | Electrical and electronic components must not be disposed of
as residual waste, it must be disposed of separately.
Manufacturer EEA contact address
AXING AG Bechler GmbH
Gewerbehaus Moskau Am Rebberg 44
8262 Ramsen 78239 Rielasingen
SPU 82-00
4 2 × 4
950...2200 MHz
≥ 30 dB ≥ 30 dB
SPU 21-02 | SPU 41-02
1 2
SPU 82-00
Position | Option
1.0 | 2.0
typ. 4 dB typ. 4 dB
basic-line
F
DiSEqC switches
Operation instructions
0,150 kg 0,258 kg
