- Page 1 CE-5800-HVE Continuous Sealer Operation Manual 866-888-6327 sales@clevelandequipment.com 4403 Delp Street • Memphis, TN 38118 www.clevelandequipment.com...
-
Page 2: Table Of Contents
CE-5800-HVE Band Sealer Contents Preface ......................... 4 1. Product Introduction ......................5 Application ........................5 Products’ Feature ......................5 Operation Principles ....................5 Technical Specification ....................6 2. Safety ......................... 8 Preparation ........................8 Precautions on safety ....................8 Using environment ...................... 9 3. - Page 3 CE-5800-HVE Band Sealer 5.3.6 Pressure adjustment of embossing wheel ..............20 6. Standard Operation & Parameter Setting ............... 21 Preparation, adjustment and inspection before operation ........22 Parameter Setting ...................... 23 Menu ......................... 24 File Edit ........................26 Preview ........................28 Advanced ........................
-
Page 4: Preface
CE-5800-HVE Band Sealer Preface Thank you for buying the intelligent inkjet band sealer of CE-5800-HVE BAND SEALER. The Manual is suitable for the model CE-5800-HVE BAND SEALER series. This instruction manual has following content: • Instruction on the product •... -
Page 5: Product Introduction
CE-5800-HVE Band Sealer 1. Product Introduction 1.1 Application This sealer can seal small packages, with a printing control operating system adopting the Linux operating system widely used worldwide, free and open source. The system has strong stability and scalability, and can run stably for a long time. -
Page 6: Technical Specification
CE-5800-HVE Band Sealer 1.4 Technical Specification CE-5800-HVE Parameter Item (Vertical Type) Voltage(V/Hz) AC 220/50 110/60 Motor power(W) 50/100 Sealing power(W) 300×2 Sealing speed(m/min) 0~16 (0~24) Sealing width(mm) 0~300（℃） （Stepless adjustable） Temperature control range(℃) Distance from sealing center to conveyor table（mm）... - Page 7 CE-5800-HVE Band Sealer 200 pieces can be stored (each piece of printing content has a separate counting and storage Printing Content Storage function) Printing Font Adjustable (customizable printing font) External Interface Online Operation Optional (one host can control 1+N units)
-
Page 8: Safety
CE-5800-HVE Band Sealer 2. Safety 2.1 Preparation • This manual describes the transportation, storage, installation, starting, operation condition, maintenance, troubleshooting and repairing of this product. • The installation of this machine should be operated by professional workers. • Please obey this maintenance instruction •... -
Page 9: Using Environment
CE-5800-HVE Band Sealer Keep this manual properly for easy reference in the future. For example: Danger! There may be severe accidents or death if this precaution is ignored! Warning! There may be severe accidents or deaths if this precaution is ignored! -
Page 10: Conveying & Storage
CE-5800-HVE Band Sealer 3. Conveying & storage 3.1 Carton packaging configuration • Packed tightly by wad in the carton Note: The maximum layers should not be more than 5 while palletizing. • Please ensure that the wrapping film is wrapped stably on the machines. -
Page 11: Installation
CE-5800-HVE Band Sealer 4. Installation Before the operation of installation, please read this manual. By reading this manual, the things about how to install, start, and usage and maintenance of this machine can be learnt. If there are problems caused because of not referring to this manual, the manufacturer will not take any responsibility. -
Page 12: Installation Environment
CE-5800-HVE Band Sealer 4.2 Installation environment • No inflammable and explosive gas is allowed. • Environment temperature：5-30℃. If need operation under other temperature, please confirm with supplier or dealer first. • Environment pressure, standard atmospheric pressure • Assure power environment satisfy requirements (refer to nameplate). -
Page 13: Installation Steps
CE-5800-HVE Band Sealer 4.3 Installation steps Ink cartridge installation steps: Remove the cartridge clip (be sure to keep the clip), pinch the end of the cartridge, and insert the cartridge nozzle along the track into the printer. Aim the nozzle of the ink cartridge at the nozzle hole of the printer, push the ink cartridge forward, and the ink cartridge will pour down along the slope above the marbles. -
Page 14: Startup And Commissioning
CE-5800-HVE Band Sealer 5. Startup and commissioning 5.1 controlling panel Name Description Touch Screen for Inkjet Used to set the working parameters of the inkjet printer Printing Emergency Stop For emergency stop, press the machine to stop running. Printing Switch Choose to turn on or off the coding function. -
Page 15: Power On
CE-5800-HVE Band Sealer 5.2 Power on DANGER! ELECTRIC SHOCK! Please abide by safety operating regulations. • Via rotating the Power Switch to start the machine. • After the connection with the power supply, the indicator light will be on. And the touch display will show the home page, which means the machine is now in the state of standby, and the machine is ready to be operated. -
Page 16: Startup Procedure
CE-5800-HVE Band Sealer 5.2.2 Startup procedure • Connect the power and press the start switch, the indicator lights up, adjust the speed control knob, then the transmission parts run synchronously. • Fine tune printing wheel knob, make the printing wheel rotating. Adjust it to the appropriate pressure and fix the limit screw. -
Page 17: Commissioning
CE-5800-HVE Band Sealer 5.3 Commissioning 5.3.1 Replacement and adjustment of the sealing belt • Remove the safety cover, after the heating block cooling, rotate retaining washer by 90° on both upper heating block and upper cooling block to lift both two blocks, then loosen the springs on both embossing roller and pinch roller, meanwhile, remove the guiding belt, to make it ready for removing sealing belts (as below figure). -
Page 18: Forward-And-Backward Adjustment Of Conveyor Table
CE-5800-HVE Band Sealer 5.3.2 Forward-and-backward adjustment of conveyor table Loosen the adjusting knobs on both sides first, and then move the conveyor table forward or backward in the long slot along the feet. Tighten the knobs on both sides after finishing the adjustment. -
Page 19: Adjustment Of Sealing Belt Deviation
CE-5800-HVE Band Sealer 5.3.3 Adjustment of sealing belt deviation If the sealing belt deviates, the sealing belt can be adjusted by adjusting the screws in the driven wheel seat (adjusting block) (as below figure). 5.3.4 Adjustment of conveyor table height According to different materials, if it is needed to adjust the height of the conveying table, adjust the conveying table height by the adjusting knob in front of the conveyor table (as below figure), and tighten it after adjustment. -
Page 20: Adjustment Of Conveyor Belt Deviation
CE-5800-HVE Band Sealer 5.3.5 Adjustment of conveyor belt deviation If the conveyor belt deviates, the conveyor belt can be adjusted by adjusting screws in the right side of conveyor table (as below figure). Keep the conveyor belt under tension state when adjusting, and it is not allowed to adjust when the conveyor belt under relaxed state. -
Page 21: Standard Operation & Parameter Setting
CE-5800-HVE Band Sealer 6. Standard Operation & Parameter Setting TAKE CARE! INJURED! Please refer to this manual to operate this machine. It is not allowed to discharge the necessary protection cover or hull. TAKE CARE! CLAMPED! When the machine is running, it is forbidden to put hands into the... -
Page 22: Preparation, Adjustment And Inspection Before Operation
CE-5800-HVE Band Sealer 6.1 Preparation, adjustment and inspection before operation • This machine is equipped with a grounded three-hole socket. The power supply used should be well grounded to ensure safety in production. • Before use, you need to check the cartridge chip and metal sheet for residual ink. If there is ink, it needs to be cleaned or it will burn out the jetty. -
Page 23: Parameter Setting
CE-5800-HVE Band Sealer 6.2 Parameter Setting TAKE CARE! DAMAGE! Unreasonable parameter setting may damage machine or shorten machine service time. • Unreasonable parameter setting may damage the machine or shorten the service time. • Unreasonable parameter setting may cause all procedures or sealing not to be completed correctly. -
Page 24: Menu
CE-5800-HVE Band Sealer 6.3 Menu 1.The first line: display the current system time and function :Display text content length and height scale :The current print information and its file name Type:display a single file or a group of files in printing... - Page 25 CE-5800-HVE Band Sealer File selection: click to select the internal file saved in the machine Advanced options: setting of machine general and printing parameters Setting: general and printing parameters settings of the machine Start printing: After the ink cartridge is installed, click this button to print (note: do not insert or remove the ink cartridge when printing);...
-
Page 26: File Edit
CE-5800-HVE Band Sealer 6.4 File Edit Add fixed text content Add variable date and time add pictures Add barcode Add a QR code Rotate selected objects (fields or graphics) Add table Add serial number counter Add line segment Add a circle or ellipse... - Page 27 CE-5800-HVE Band Sealer Fine-tune the selected object up, down, left, and right When there are multiple field objects in the information area, switch the selected field object Click this button to save information, create new information or modify saved information...
-
Page 28: Preview
CE-5800-HVE Band Sealer 6.5 Preview 1.The file name of the saved information is displayed in the red solid line frame. You can click the file name to preview the file content, edit the file content or print the selected file... -
Page 29: Advanced
CE-5800-HVE Band Sealer 6.6 Advanced 1.System time:adjust the current system year, month, day, hour, minute, and second 2.Language:select the desired language 3.Brightness:adjust the brightness of the screen backlight 4.Buzzer:when you select the ON state, there will be a "di" sound at the beginning and end of printing; if it is not turned on, there will be no sound when printing 5.Power Saver:when the on state is selected, the machine will automatically reduce the brightness of the screen... - Page 30 CE-5800-HVE Band Sealer 1.Direction: the direction in which the font is printed, forward, reverse, forward and backward, reverse direction can be selected 2.Inkjet mode:The cartridge has two nozzles, you can choose to spray left or right 3.Trigger: electric eye 4.Speed: the faster the bag moves, the smaller the print speed value is set 5.Delay: the larger the delay, the later the printing position will be after the sensor is inducted, the smaller the...
-
Page 31: Maintenance
CE-5800-HVE Band Sealer 7. Maintenance Alarm！Electric Shock！ The power of the machine should be fully cut off before maintenance. Daily maintenance to the machine is necessary to lengthen the service life of the machine and to achieve best packing effect. If the machine is frequently used (more than four hours per day), it is suggested to do professional maintenance every three month. -
Page 32: Maintenance Period Table
CE-5800-HVE Band Sealer 7.2 Maintenance period table Schedule Contents of Maintenance 1.Use the brush to remove the substance attached to the appearance of the sealing belt and guiding belt. Daily 2.Use wet cloth to clean the appearance of the conveyor belt. -
Page 33: Troubleshooting
CE-5800-HVE Band Sealer 8. Troubleshooting 8.1 Troubleshooting Problem Reason Solution The machine does not work 1. The power is not connected. 1. Check the electric outlet. 2. The fuse is broken or high 2. Replace the fuse and high circuit resolution circuit breaker trips. - Page 34 CE-5800-HVE Band Sealer Problem Reason Solution Touch screen is out of order. 1. You need to recalibrate the 1. ① Insert the mouse into the USB port Nothing happens when you screen. on the side of the case; ② Click the mouse...
- Page 35 CE-5800-HVE Band Sealer Problem Reason Solution but can only be adjusted by adjusting the font size. In the process of inkjet 1. The printed content is 1. Whether the printed content is edited, printing, the main interface empty. and whether the printed content is visible prints count hops, but no 2.
- Page 36 CE-5800-HVE Band Sealer The jetty is burnt out 1. Live plugging ink cartridge 1. The customer must insert and remove will cause the contact piece to the ink cartridge in the case of power touch the two contacts, which failure.
-
Page 37: Motor Maintenance
CE-5800-HVE Band Sealer 8.2 Motor maintenance （1）Stop and check the machine when any abnormal occurs to motor, do not use the machine until problem is solved. （2）Dedust and clean motor regularly. Ethyl alcohol, gasoline and liquid with benzene chemicals should be avoided, otherwise it will affect the paint of motor cover. -
Page 38: Storage
CE-5800-HVE Band Sealer 9. Storage 9.1 Storage of short time • Turn off the power button, unplug the power cord, pack up the power cord. • Clean the dust. • If possible, cover it with the plastic bag to keep it from dust. -
Page 39: Electric Schematic Diagram
CE-5800-HVE Band Sealer 10. Electric schematic diagram Page 39... -
Page 40: Parts Diagrams
CE-5800-HVE Band Sealer 11. Parts Diagrams 11.1 Sealing part 1: serial name quantity unit Remark number 11271020500 Fully enclosed upper guard individual 9425100020672 wide angle belt individual 9425100020600 wide angle belt individual 11271020600 Fully enclosed lower guard individual 11111030004 Embossed wheel seat... - Page 41 CE-5800-HVE Band Sealer Page 41...
-
Page 42: Sealing Part 2
CE-5800-HVE Band Sealer 11.2 Sealing part 2 : name quantity unit Remark 11271030039 Bottom plate individual 9103101211060 driven wheel seat spring individual 11311030029 Inlet individual Compression torsion individual spring (upper) 11101020016A 11101020017AS Tablet (on) individual 11101020017BS Tablet (below) individual Compression torsion... - Page 43 CE-5800-HVE Band Sealer name quantity unit Remark 2-30 9746036400010 shaft retaining ring individual Ф10mm 2-31 11311030035 Pressure wheel individual 2-32 11311030034 Press down axle individual Page 43...
- Page 44 CE-5800-HVE Band Sealer Page 44...
-
Page 45: Sealing Part 3
CE-5800-HVE Band Sealer 11.3 Sealing part 3 serial quantity name unit Remark number Connecting shaft bearing housing 11311030026 individual 9105200601012 Deep Groove Ball Bearings individual 6001-2Z 11111030021-35 gear individual 11311030024 Intermediate gear shaft individual 9105200601982 Deep Groove Ball Bearings individual... - Page 46 CE-5800-HVE Band Sealer Page 46...
-
Page 47: Worm Gear Box Assembly
CE-5800-HVE Band Sealer 11.4 Worm gear box assembly serial name quantity unit Remark number 11111050006 Worm gear box cover II individual 9412121002512 Skeleton oil seal individual 9105200602011 Deep Groove Ball Bearings individual 6201 2Z Double shaft extension worm 11271050008 individual... - Page 48 CE-5800-HVE Band Sealer Page 48...
-
Page 49: Worm Gear Box Motor Assembly
CE-5800-HVE Band Sealer 11.5 Worm gear box motor assembly serial quantity name unit Remark number Worm gear box output gear individual cover 11311050005 11311050004-35 Worm shaft output gear individual 11311050007.31 Worm gear box spacer individual 11311050007.42 Worm gear box spacer I... - Page 50 CE-5800-HVE Band Sealer Page 50...
-
Page 51: Conveyor Table Parts
CE-5800-HVE Band Sealer 11.6 Conveyor Table Parts Serial quantity number name unit Remark 9422112180136 conveyor individual conveyor belt adjustment block 11111010009K individual 9715051105055 Equal length stud individual 9100401130520 Corrugated handle individual 9746036400012 shaft retaining ring individual Ф12mm _ 9105200602011 Deep Groove Ball Bearings... - Page 52 CE-5800-HVE Band Sealer Page 52...
-
Page 53: Chassis Components
CE-5800-HVE Band Sealer 11.7 Chassis components serial quantity name unit Remark number 11311040007S rung individual 9400101000025T2 rubber feet individual 9450101111002 rubber feet individual 11111040006BS foot (right) individual 9310101035125 switching power supply individual 9210110080042 Relay holder individual Speed control circuit board... - Page 54 CE-5800-HVE Band Sealer Page 54...
