Washing Machine
OWNER’S MANUAL
WRFM 61201 S / WRFM 61201 W
Read This Manual
Use all instructions and explanations of
the installation before use. Follow the
instructions carefully. Keep the operation
instructions handy for later use. If the
application is sold or passed on then ensure
that the new owner always receives those
operation instructions.
Advertisement
Table of Contents
Summary of Contents for Riffel WRFM 61201 S
- Page 1 Washing Machine OWNER’S MANUAL WRFM 61201 S / WRFM 61201 W Read This Manual Use all instructions and explanations of the installation before use. Follow the instructions carefully. Keep the operation instructions handy for later use. If the application is sold or passed on then ensure that the new owner always receives those operation instructions.
-
Page 2: Table Of Contents
Contents Safety Instructions Safety Instructions ..........Installation Product Description ..........Installation ............Operations Quick Start ............. Before Each Washing ..........Detergent Dispenser ..........Control Panel ............Option..............Other Functions ............Programmes............Washing Programmes Table ........Maintenances Cleaning And Care ..........Trouble Shooting ............ -
Page 3: Safety Instructions
SAFETY INSTRUCTIONS Safety Instructions For your safety,the information in this manual must be followed to minimize the risk of fire or explosion, electric shock, or to prevent property damage, personal injury or loss of life. Explanation of the symbols: ！ Warning! This combination of symbol and signal word indicates a potentially dangerous situation which may result in... - Page 4 SAFETY INSTRUCTIONS • The new hose-sets supplied with the appliance are to be used and that old hose-sets should not be reused. • Before any maintenance the device, unplug the appliance from the mains. • Always unplug the machine and turn off the water supply after use.
- Page 5 SAFETY INSTRUCTIONS • Glass door may be very hot during the operation. Keep kids and pets far away from the machine during the operation very wet rooms as well as in the rooms with explosive or caustic gas. • Remove all packages and transport bolts before using the appliance.
- Page 6 SAFETY INSTRUCTIONS • Remove all packages and transport bolts before using the appliance. Otherwise, serious damage may result. Risk of damaging appliance! • Your product is only for home use and is only designed for the textiles suitable for machine washing. •...
- Page 7 SAFETY INSTRUCTIONS • Make sure that all pockets are emptied. Sharp and rigid items such as coin,brooch,nail,screw or stone etc. may cause serious damages to this machine. • Please check whether the water inside the drum has been drained before opening its door.Please do not open the door if there is any water visible.
-
Page 8: Product Description
INSTALLATION Product Description Top cover Water supply hose Control panel Power supply cord Detergent dispenser Drum Door Service filter Drain hose Note! • The product line chart is for reference only, please refer to real product as standard. Accessories Transport Drain hose support Owner’s manual Supply hose... - Page 9 INSTALLATION Installation Installation area ！ Warning! • Stability is important to prevent the product from wandering! • Make sure that the product should not stand on the power cord. W> 20mm Before installing the machine, the location characterized as follows shall be selected: 1.Rigid, dry, and level surface 2.Avoid direct sunlight 3.Sufficient ventilation...
- Page 10 INSTALLATION Levelling the washing machine ！ Warning! • The lock nuts on all four feet must be screwed tightly against the housing. Check if the legs are closely attached to the cabinet. If not, please turn them to their original positions tighten the nuts. 2.
- Page 11 INSTALLATION Connect the other end of inlet pipe to the inlet valve at the backside of product and fasten the pipe tightly clockwise. water supply hose water Inlet valve Drain Hose ！ ！ Warning! Warning! • Do not kink or protract the drain hose. •...
-
Page 12: Operations
OPERATIONS Quick Start Caution! • Before washing, please make sure it’s installed properly. • Before washing it first time, the washing machine shall be operated in one round of the whole procedures without clothes in as follows. 1. Before Washing Main wash Softener... -
Page 13: Before Each Washing
OPERATIONS Before Each Washing • The working condition of the washer should be(0-40)℃.If used under 0℃,the inlet valve and draining system may be damaged. If the machine is placed under condition of 0℃or less, then it should be transferred to normal ambient temperature to ensure the water supply hose and drain hose are not frozen before use. -
Page 14: Detergent Dispenser
OPERATIONS Detergent Dispenser Pre wash detergent Main wash detergent Softener Dam-board Dam-board Liquid detergent Powder detergent Pull out the dispenser Caution! • Detergent only need to be added in "case I “after selecting pre-washing for machines with this function. Programme Programme Rinse&Spin Cotton... -
Page 15: Control Panel
OPERATIONS OPERATIONS Control Panel Note! • The chart is for reference only, Please refer to real product as standard. On/Off Start/Pause Product is switched on or off. Press the button to start or pause the washing cycle. Programmes Option Available according to the laundry type. This allows you to select an additional function and will light when selected. - Page 16 OPERATIONS OPERATIONS Control Panel Model:MFC120-U1203B/C14E-TW Note! • The chart is for reference only, Please refer to real product as standard. On/Off Start/Pause Product is switched on or off. Press the button to start or pause the washing cycle. Programmes Option Available according to the laundry type.
- Page 17 OPERATIONS OPERATIONS Option Pre Wash The Prewash function can get an extra wash before main wash,it is suitable for washing the dust rises to surface of the clothes;You need to put detergent into the Case (I) when select it. Extra Rinse The laundry will undergo extra rinse once after you select it.
-
Page 18: Other Functions
OPERATIONS OPERATIONS Other functions Reload This operation can be executed during the washing progress. When the drum is still rolling and there is large amount of water with high temperature in the drum. The state is unsafe and the door cannot be opened forcefully. To press [Start/Pause] for 3 sec. - Page 19 OPERATIONS OPERATIONS Spin Press the button to change the spin speed. 1000: 0-400-600-800-1000 1200: 0-400-600-800-1000-1200 1400: 0-600-800-1000-1200-1400 1600: 0-400-800-1200-1400-1600 1400(LA/AR): 0-400-800-1200-1400 Programme Default Speed(rpm) Programme Default Speed(rpm) 1400 1400 1000 1200 1400 1600 1000 1200 1400 1600 (LA20/AR) LA20/AR 800(AR) Cotton Rinse&Spin 1200...
-
Page 20: Programmes
OPERATIONS OPERATIONS Programmes Programmes are available according to the laundry type. Programmes Cotton Hard-wearing textiles, heat-resistant textiles made of cotton or linen. Synthetic Wash synthetic articles, for example: shirts, coats, blending. While washing the knitting textiles, detergent quantity shall be reduced due to its loose string construction and easily forming bubbles. -
Page 21: Washing Programmes Table
OPERATIONS OPERATIONS Washing Programmes Table Model:EU(A3)-FC60-S10/C1903E/EU(A3)-FC60-S12/C1903E/EU(A3)-FC60-S14/C1903E /EU(A3)-FC70-S12/C1903E/EU(A3)-FC70-S14/C1903E/IR(A3)-FC70-S14S/C1903E /EU(A3)-FC80-S14/C1903E/IR(A3)-FC80-S14S/C1903E/EU(A31)-FC90-S14D/C1903E Programme Load(kg) Temp. Default Time (°C) 7.0/8.0 Default 1000 1200 1400 1200 1400 1400 Cotton 2:40 2:40 2:40 2:40 2:40 2:40 Synthetic 1:40 1:40 1:40 1:40 1:40 1:40 Baby Care 1:20 1:20 1:20 1:20 1:20... - Page 22 OPERATIONS OPERATIONS Washing Programmes Table Model:EU(A33)-FC100-U16B/C1903E/EU(A33)-FC120-U14B/C1903E/MFC120-U1203B/C14E-TW /MFC120-U1401B/C14E-LA/MFC120-U1403B/C19E-AR/MFC120-U1403BS/C19E-LA20 Programme Load(kg) Temp. Default Time °C Default Default 10.0 12.0 10.0/12.0 12.0(AR) 12.0(LA) 12.0(TW) (TW) Cotton 2:40 2:40 2:40 2:40 10.0 12.0 Synthetic 1:40 1:40 2:20 2:20 Baby Care 1:20 1:20 1:20 1:20 10.0 12.0 Jeans...
- Page 23 OPERATIONS OPERATIONS Washing Programmes Table(UAE) Model:MFC60-S1203/C14E-AE(5)/MFC70-S1203/C14E-AE(5)/MFC80-S1403/C14E-AE(5)/ MFC60-U1203/C19E-EU(A3) Programme Load(kg) Default Time Temp. °C 6.0(EU) Default 1200 1200 1200 1400 Cotton 2:40 2:40 2:40 2:40 Synthetic 1:40 1:40 1:40 1:40 Baby Care 1:20 1:20 1:20 1:20 Jeans 1:45 1:45 1:45 1:45 1:13 1:13 1:13...
-
Page 24: Maintenances
MAINTENANCES Cleaning And Care ！ Warning! • Before your maintenance starts, please unplug the machine and close the tap. Cleaning The Cabinet Proper maintenance on the washing machine can extend its working life. The surface can be cleaned with diluted non-abrasive neutral detergents when necessary. - Page 25 MAINTENANCES Cleaning The Inlet Filter Note! • Inlet filter must be cleaned if there is less water. Washing the filter in the tap 1. Close the tap. 2. Remove the water supply hose from the tap. 3. clean the filter. 4.
- Page 26 MAINTENANCES Cleaning The Drain Pump Filter ！ Warning! • Be careful of the hot water! • Allow detergent solution to cool down. • Unplug the machine to avoid electrical shock before washing. • Drain pump filter can filter the yarns and small foreign matters from the washing.
-
Page 27: Trouble Shooting
MAINTENANCES Trouble Shooting The start of the appliance does not work or it stops during operation. First try to find a solution to the problem, If not, contact the service centre. Description Reason Solution Washing machine Restart after the door is closed Door is not closed properly cannot start up Check if the clothes is stuck... -
Page 28: Technical Specifications
MAINTENANCES Technical Specifications Power Supply 220-240V~,50Hz 110-127V~60Hz(LA20/TW) MAX.Current Standard Water Pressure 0.05MPa~1MPa Model Rated Power Washing Capacity Dimension Net Weight (W*D*Hmm) EU(A3)-FC60-S10/C1903E 6.0kg 595*470*850 54kg 2000W EU(A3)-FC60-S12/C1903E EU(A3)-FC60-S14/C1903E MFC60-S1203/C14E-AE(5) MFC60-U1203/C19E-EU(A3) EU(A3)-FC70-S12/C1903E 7.0kg 595*495*850 61kg 2050W EU(A3)-FC70-S14/C1903E IR(A3)-FC70-S14S/C1903E MFC70-S1203/C14E-AE(5) 2000W EU(A3)-FC80-S10/C1903E 8.0kg 595*565*850 68kg... -
Page 29: Product Fiches
MAINTENANCES Product Fiches EU(A3)-FC60-S10/C1903E Model EU(A3)-FC60-S12/C1903E EU(A3)-FC60-S14/C1903E Capacity 1000/1200/1400 rpm Spin Speed A +++ Energy efficiency class ❶ 153 kWh /annual Annual energy consumption ❷ 0.5W Power consumption of off - mode 1.0W Power consumption of Left on -mode ❸ 9240L /annual Annual water consumption ❹... - Page 30 MAINTENANCES Model EU(A3)-FC70-S12/C1903E EU(A3)-FC70-S14/C1903E IR(A3)-FC70-S14S/C1903E Capacity Spin Speed 1200/1400/1400 rpm Energy efficiency class ❶ A +++ Annual energy consumption 175 kWh /annual ❷ Power consumption of off - mode 0.5W Power consumption of Left on -mode 1.0W Annual water consumption ❸...
- Page 31 MAINTENANCES Model EU(A3)-FC80-S12/C1903E EU(A3)-FC80-S14/C1903E Capacity Spin Speed 1200/1400 rpm A +++ Energy efficiency class ❶ Annual energy consumption 196 kWh /annual ❷ 0.5W Power consumption of off - mode Power consumption of Left on -mode 1.0W Annual water consumption 11000L /annual ❸...
- Page 32 MAINTENANCES Model EU(A31)-FC90-S14D/C1903E Capacity Spin Speed 1400 rpm Energy efficiency class A +++ ❶ ❷ 196 kWh /annual Annual energy consumption Power consumption of off - mode 0.5W 1.0W Power consumption of Left on -mode Annual water consumption ❸ 11800L /annual Spin- drying efficiency class ❹...
- Page 33 MAINTENANCES Model EU(A33)-FC100-U16B/C1903E 10kg Capacity Spin Speed 1600 rpm ❶ Energy efficiency class A +++ ❷ 167 kWh /annual Annual energy consumption Power consumption of off - mode 0.5W 1.0W Power consumption of Left on -mode ❸ Annual water consumption 13000L /annual Spin- drying efficiency class ❹...
- Page 34 MAINTENANCES Model EU(A33)-FC120-U14B/C1903E 12kg Capacity Spin Speed 1600 rpm ❶ Energy efficiency class A +++ 197 kWh /annual Annual energy consumption ❷ Power consumption of off - mode 0.5W 1.0W Power consumption of Left on -mode ❸ Annual water consumption 14000L /annual ❹...
- Page 35 MAINTENANCES Model MFC60-U1203/C19E-EU(A3) Capacity Spin Speed 1200 rpm ❶ Energy efficiency class A +++ 153 kWh /annual Annual energy consumption ❷ Power consumption of off - mode 0.5W 1.0W Power consumption of Left on -mode ❸ Annual water consumption 9240L /annual ❹...
- Page 36 MAINTENANCES Note! • Programme setting for testing in accordance with applicable standard En60456. • When using the test programmes, wash the specified load using the maximum spin speed. • The actual parameters will depend on how the applicance is used,and maybe different with the parameters in above mentioned table.
