Summary of Contents for Digital Touch Systems DTS-2410C
- Page 1 User Manual for REG. DATE : 2021.12.13 REV.NO : 1.0 DTS-2410C REV. DATE : PAGE : User Manual for DTS-2410C Appendix DTS-2410C...
-
Page 2: Table Of Contents
User Manual for REV.NO : 1.0 REG. DATE : 2021.12.13 DTS-2410C REV. DATE : PAGE : Content Revision History ....................3 Recommended Use ....................4 1. Package Contents ..................5 2. Product Configuration ..................6 3. Interface Description..................7 4. OSD Control Board Description …………............8 5. - Page 3 User Manual for REV.NO : 1.0 REG. DATE : 2021.12.13 DTS-2410C REV. DATE : PAGE : Change History of Revision Revision Date Contents of Revision Change Remark Release 21.12.13 DTS-2410C...
-
Page 4: Recommended Use
User Manual for REV.NO : 1.0 REG. DATE : 2021.12.13 DTS-2410C REV. DATE : PAGE : Recommended Use FOR OPTIMUM PERFORMANCE, PLEASE NOTE THE FOLLOWING WHEN SETTING UP AND USING THE TOUCH SCREEN MONITOR. • DO NOT OPEN THE MONITOR. -
Page 5: Package Contents
User Manual for REV.NO : 1.0 REG. DATE : 2021.12.13 DTS-2410C REV. DATE : PAGE : Thank you for your selection of FHD Touch Screen Display Monitor Please take a few minutes to read this User’s manual for the best performance of this monitor. -
Page 6: Product Configuration
User Manual for REV.NO : 1.0 REG. DATE : 2021.12.13 DTS-2410C REV. DATE : PAGE : 2. Product Configuration Interface Terminal ( Attached page 7) Note ) Actual Touch Screen Monitor may differ from those in this user's drawing DTS-2410C... -
Page 7: Interface Description
User Manual for REV.NO : 1.0 REG. DATE : 2021.12.13 DTS-2410C REV. DATE : PAGE : 3. Interface Description ③ ⑦ ① ② ④ ⑤ ⑥ Name Description • Touch screen connect USB cable. USB(Touch) • Connect to PC’s USB 2.0 port •... -
Page 8: Osd Control Board Description
User Manual for REV.NO : 1.0 REG. DATE : 2021.12.13 DTS-2410C REV. DATE : PAGE : 4. OSD Control Board Description 4.1 OSD Interface Description Name Description • Indicated LED -. Red Color : Display Power On -. Green Color : Display On •... - Page 9 User Manual for REV.NO : 1.0 REG. DATE : 2021.12.13 DTS-2410C REV. DATE : PAGE : OPERATING THE MONITOR To create the best picture, your LCD monitor has been preset at the factory with the COMPLIANT TIMING shown on page ??. You are also able to adjust the picture by following the button operation shown below.
- Page 10 User Manual for REV.NO : 1.0 REG. DATE : 2021.12.13 DTS-2410C REV. DATE : PAGE : • ICON 2 : PICTURE • ICON 3 : COLOR • ICON 4 : OSD Setting DTS-2410C...
- Page 11 User Manual for REV.NO : 1.0 REG. DATE : 2021.12.13 DTS-2410C REV. DATE : PAGE : • ICON 5 : SETUP ADJUSTMENT MENU CONTENTS Item Adjust Remark Brightness 0-100 Contrast 0-100 LUMINANCE Gamma ON/OFF OFF/DCR/DBC PHASE 0~100 CLOCK 0-100 PICTURE(D-SUB Only) H.POSITION...
-
Page 12: Trouble Shooting
User Manual for REV.NO : 1.0 REG. DATE : 2021.12.13 DTS-2410C REV. DATE : PAGE : 5. Trouble shooting Phenomenon Confirmation and action • Check that the Power code is properly connected to the display. • Check that Power on/off button on the OSD •... - Page 13 User Manual for REV.NO : 1.0 REG. DATE : 2021.12.13 DTS-2410C REV. DATE : PAGE : Phenomenon Confirmation and action • Video timing outside of range Image will not adjust • Use the one-screen menu to adjust the clock setting.
-
Page 14: Specification
User Manual for REV.NO : 1.0 REG. DATE : 2021.12.13 DTS-2410C REV. DATE : PAGE : 6. Specification (1) MONITOR SPECIFICATIONS ITEMS SPECIFICATION Screen Diagonal 23.8 inch Active Display Area 527.04 x 296.46 mm Display Type Transmissive mode, Normally black Max. - Page 15 User Manual for REV.NO : 1.0 REG. DATE : 2021.12.13 DTS-2410C REV. DATE : PAGE : (3) MECHANICAL SPECIFICATIONS ITEMS SPECIFICATION Outline Dimension 585.4±1.2mm x 355.4±0.8mm x 40.5±0.3mm (HxVxD) Weight(Net/ Gross) 7.3Kg Approx./ TBD Standard Accessory HDMI Cable, USB Cable, Power Cord, Adapter...
