Page 1 2-in-1BRAD NAILER/STAPLER OPERATOR’s MANUAL MANUEL D’UTILISATION DU CLOUEUSE/AGRAFEUSE MANUAL DEL OPERADOR DEL CLAVADORA/GRAPADORA PUREPOWEREQUIPMENT...
Page 2: Table Of Contents
TABLE OF CONTENTS INTRODUCTION SAFETY OVERVIEW SPECIFICATIONS UNPACKING LOADING FASTENERS OPERATION ADJUSTING THE EXHAUST SAFETY NOSE NON-MARRING PAD DEPTH ADJUSTMENT SETTING THE AIR PRESSURE RECOMMENDED AIR HOOK UP FASTENERS MAINTENANCE ANTI-DUST CAP LUBRICATION CLEANING COLD WEATHER OPERATION TROUBLE SHOOTING CLEARING JAMS TROUBLE SHOOTING CHART WARRANTY NOTES...
Page 3: Introduction
INTRODUCTION Congratulations on your purchase of a Pure Power Equipment air tool You can be confident that this machine is constructed and tested with optimum performance and quality in mind. Reading this manual will help get you the best results for set-up, operation, maintenance and avoid personal injury or damage to your machine.
Page 4: Safety Overview
SAFETY OVERVIEW SAVE THESE INSTRUCTIONS - SAFETY RULES This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death. The safety alert symbol ( ) is used with a signal word (DANGER, CAUTION, WARNING), a pictorial and a safety message to alert you to hazards.
Page 5 SAFETY OVERVIEW WARNING - WORK AREA • Keep the work area clean and well lit. Cluttered benches and dark areas increase the risks of accidents • Do not operate the tool in explosive atmospheres, such as in the presence of flammable liquids, gases, or dust. The tool creates a spark which may ignite flammable liquids, gases or dust.
Page 6: Specifications
200 PSI, the tool may explode causing serious injury or death. • NEVER exceed the maximum recommended pressure rating of 110 PSI when operating this tool to maintain safe operation. • NEVER use any type of reactive gases such as oxygen. Explosion or fire may occur causing serious injury or death.
Page 7: Unpacking
UNPACKING • This tool arrives completely assembled in the box. • Carefully remove the tool and any accessories from the box. • Inspect the tool carefully to ensure there is no damage or missing parts. • Read the manual and operate the tool to ensure functionality. •...
Page 8: Operation
OPERATION ADJUSTING THE EXHAUST Every time the air tool is fired it will exhaust air out of the back. This tool has an adjustable exhaust to direct the air flow according to the operators preference. To adjust, turn the back cap by hand so the exhaust is pointing in the desired direction.
Page 9: Setting The Air Pressure
OPERATION SETTING THE AIR PRESSURE This tool is designed to operate between 60 and 100 PSI. Air pressure can be adjusted with the regulator on the air compressor. The air pressure will affect the depth the fastener will be set in the work piece. Adjusting the air pressure may be sufficient to achieve the desired depth of fasteners.
Page 10: Fasteners
FASTENERS FASTENER TYPE This tool can use two types of fasteners that are typically called: • 18 Gauge Brad Nails are narrow nails with small heads to minimize the chances to split wood. These nails are great for decorative molding, wood trimming, panelling or any other type intricate finish work.
Page 11: Maintenance
MAINTENANCE ANTI-DUST CAP This air tool comes with a rubber anti-dust cap installed on its air plug. Keep the air plug covered by the anti-dust cap when the tool is not in use. LUBRICATION The moving parts in the air nailer require a light application of oil to maintain best performance and lifespan.
Page 12: Trouble Shooting
TROUBLE SHOOTING CLEARING JAMS A fastener may become jammed in the firing mechanism of the tool. The jam must be cleared before the tool an be used again. Disconnect the tool from the air source. 2. Remove the fasteners from the tool. 3.
Page 13 TROUBLE SHOOTING PROBLEM CAUSE SOLUTION Air leaking at trigger O-rings in trigger valve Replace o-rings. Check operation of valve. housing are damaged. safety nose. Loose screws in housing Tighten screws. Air leaking between Damaged o-rings Replace o-rings housing and nose. Damage to bumper Replace bumper Loose screws...
Page 14 WARRANTY Pure Power Equipment warrants the original retail purchaser that this air nailer is free from defects in material and workmanship for the periods set forth below. If defects are found in Pure Power Equipment products within the limitations outlined in this warranty statement, Pure Power Equipment, at its sole discretion, will repair or replace the product free of charge.
Page 15 NOTES www.purepowerequipment.com...
Page 16 DO NOT RETURN THIS PRODUCT TO THE RETAILER CONTACT OUR CUSTOMER SERVICE if you need assistance with the assembly, operation, or if you experience a problem with your pressure washer, please call 1-866-850-6662 Monday - Friday. 8AM to 430PM PST. NE RENVOYEZ PAS CE PRODUIT AU DÉTAILLANT, CONTACTEZ NOTRE SERVICE À...
